trine
QUEEN OR KING BED
Thank you for purchasing the Trine Queen or King Bed.
This page lists all the contents included in the box. Please
take the time to identify the hardware as well as the
individual components to this product. As you unpack
and prepare for assembly, place the contents on a
carpeted or padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
components
1- headboard
1 - center rail
Made in Vietnam - r07
1 - footboard
3 - support
legs
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
hardware
8 - threaded
14 - large
bolts
screws
8 - half-moon
8 - hex
brackets
nuts
Missing hardware?
Please call 800.606.6387 for replacements.

tools required

hex wrench (included)
flat head screwdriver
phillips head screwdriver
(We recommend the use of hand tools instead of power tools)
2 - side rails
(1 left, 1 right)
2 - slat
assemblies
32 - small
4 - corner
screws
brackets
8 - flat
8- spring
washers
washers
Page 1 of 4

Advertisement

loading
Need help?

Need help?

Do you have a question about the Trine Queen or King Bed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CB2 Trine Queen or King Bed

  • Page 1: Tools Required

    Missing hardware? Please call 800.606.6387 for replacements. tools required Thank you for purchasing the Trine Queen or King Bed. This page lists all the contents included in the box. Please hex wrench (included) take the time to identify the hardware as well as the individual components to this product.
  • Page 2 B. Insert 2 half-moon brackets into each left and right side rails as shown. Loosely secure each side rail with 2 flat washers, 2 spring washers and 2 hex nuts, using a hex wrench. Do not fully tighten. Repeat step 2A-B for footboard. Customer Service 800.606.6252  |  Latest instructions available at www.cb2.com Made in Vietnam - r07 Page 2 of 4...
  • Page 3 A. Attach 3 support legs to center rail. Turn each leg clockwise to secure. B. Fit center rail to corresponding notch on headboard and footboard. Secure center rail with 2 large screws, using a screwdriver. Customer Service 800.606.6252  |  Latest instructions available at www.cb2.com Made in Vietnam - r07 Page 3 of 4...
  • Page 4 Attach each slat assembly with 6 large screws as shown. Assembly is now complete. cleaning & care Clean surfaces with a dry soft cloth. Do not use abrasive cleaners. Customer Service 800.606.6252  |  Latest instructions available at www.cb2.com Made in Vietnam - r07 Page 4 of 4...
