Summary of Contents for Amroad ID5101

  • Page 2 AMROAD TECHNOLOGY INC.

  • Page 3: Copyright

    All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language in any form or by any means without the express written permission of Amroad Technology Inc. To obtain consent, write to the attention of Amroad Technology Inc.

  • Page 4: Table Of Contents

    CHAPTER 2 : INSTALLATION............................7 ..................................7 ACKAGE ONTENTS ..............................8 UGGESTED NSTALLATION OSITIONS ................................... 9 NSTALLING ROCEDURES CHAPTER 3 : USING THE ID5101 ..........................13 ............................13 NOWING IDEO NDOOR TATION ................................14 EDICATED UNCTION LED I ................................... 15 NDICATORS AMROAD TECHNOLOGY INC.
  • Page 5 UMBER ......................................22 NCOMING ......................................22 NDING A ..................................22 NSWER HONE INGING RFID C ....................................23 CHAPTER 4 : ID5101 GRAPHIC USER INTERFACE....................... 25 & S ................................25 AFETY ECURITY ......................................26 AFETY ......................................27 AFETY TATUS ......................................28...
  • Page 6 CONTENTS ......................................37 OMMUNITY CHAPTER 5 : SETTING UP THE ID5101 ........................39 ................................... 39 YSTEM ETTINGS ................................... 40 YSTEM ETTINGS ......................................41 IDEO ETTINGS ......................................43 UDIO ETTINGS ....................................43 ETWORK ETTINGS SIP S ....................................... 45 ETTING ....................................47...
  • Page 7 CO SENSOR ......................................78 EMERGENCY BUTTON....................................79 GAS DETECTOR......................................80 DOOR BELL BUTTON....................................81 APPENDIX B : REGULATORY INFORMATION ......................82 FCC STATEMENT ...................................... 82 FCC R ................................82 ADIATION XPOSURE TATEMENT CE DECLARATION OF CONFORMITY (EUROPE) ........................... 83 AMROAD TECHNOLOGY INC.
  • Page 8 CONTENTS AMROAD TECHNOLOGY INC.

  • Page 9: Chapter 1 : Introduction

    Gas, and Emergency Button). Once alarm is triggered, three calls will automatically be sent with Alarm Speech Announcement. ID5101 allows you to view live video (Surveillance) up to 12 cameras, so you can see what’s happening in other rooms and outside your house. Messages that include Alarm Record, Visitor Record (pictures of visitors), Call Record, and Community Notice can be read through your ID5101.

  • Page 10: Features Of Home Security

    Support PoE (Power over Ethernet, 802.3af) module (External power supply AC 48V)  Web User Interface for SI online configuration from web browser on computer  Please read this manual carefully before taking any installation action. Please contact your dealers or system integrators if you have questions. AMROAD TECHNOLOGY INC.

  • Page 11: Single Unit Application

    VIDEO INDOOR STATION Single Unit Application The diagram shows that ID5101 can connect to a variety of SIP devices such as IP video phone, video door phone, video indoor station and SIP Camera. Besides Home Security, ID5101 allows you to make video phone calls, answer door phone, and view live video through SIP camera.

  • Page 12: Community Application

    MANUAL FOR SYSTEM INTEGRATOR Community Application Figure 3: Community Application AMROAD TECHNOLOGY INC.

  • Page 13: Use Of Home Security And Sip Video Phone

    VIDEO INDOOR STATION Use of Home Security and SIP Video Phone In the diagram, ID5101 is connected to CO sensor, Gas detector, and Emergency button to guard your home safe. Besides, ICMS (Intelligent Community Management Server) may deliver messages such as Community Notice and Alarm Record to your ID5101.
  • Page 14 MANUAL FOR SYSTEM INTEGRATOR AMROAD TECHNOLOGY INC.

  • Page 15: Chapter 2 : Installation

    9. I/O Cable (3 pieces) 10. Relay Board (2 pieces) 11. Quick Installation Guide & Quick Operation Guide Please contact your dealer if any item is missing. And those accessories put in the paper tube of box. Figure 5: Package Contents AMROAD TECHNOLOGY INC.

  • Page 16: Suggested Installation Positions

    155cm according to building conditions. For more details, please refer to Diagram below. Please reserve the space for junction wiring in the wall, you may refer to the embedded box dimension as diagram below. Installation Example Figure 6: Suggested Installation Positions AMROAD TECHNOLOGY INC.

  • Page 17: Installing Procedures

    I/O cable and put it in the embedded box. And then pull out the I/O cables pass through the back plate. Figure 7: Screw the Back Plate on the wall AMROAD TECHNOLOGY INC.
  • Page 18 Connect the DC Wires and Ethernet Cable Connect the DC wire of ID5101 to Power-Connecting connector, and connect Ethernet cable to ID5101 as Figure below. Be careful when you are connecting the power wires, please check the power condition and turn off the general power switch before you start to connect the wires.
  • Page 19 Appendix: IO Circuits and Applications. There are 8 input ports and 4 output ports on the rear panel of the ID5101. Connection and applications are described more detailed in Appendix. Figure 9: Connecting DC Wires AMROAD TECHNOLOGY INC.
  • Page 20 After connecting the wires and cables properly, then screw the 2 screws that come with the package into the front panel. Please double check all the installation procedures again, then you may power on the general power switch to start the configuration procedures. Figure 10: Screw the Video Indoor Station with Back Plate AMROAD TECHNOLOGY INC.

  • Page 21: Chapter 3 : Using The Id5101

    VIDEO INDOOR STATION Chapter 3 : Using the ID5101 Knowing Your Video Indoor Station NOTE: For GUI and WEB UI, please use alphabet and numbers to enter data and don't use special symbols to avoid lossing data while saving your setting.

  • Page 22: Dedicated Function Keys

    Lighting Two lighting devices can be connected to ID5101. Press this Lighting key to turn on both lamps. The two lighting devices act in the order of “On-On”, “Off-On”, “On-Off”, “Off-Off” in turn. NOTE: The maximum current for Relay Board is 2 Amp.

  • Page 23: Led Indicators

    Alarm is disabled temporally. Normal Situation Blue Blinking Door bell is ringing while you are talking on ID5101. Flash NOTE: User can press this Flash key to switch phone calls between the phone call and door phone. No interrupting call...
  • Page 24 MEANING No unread message SpeedDial Blue Operating in SpeedDial mode Not in SpeedDial mode Lighting Blue A. Network is connected, and SIP is registered successfully. B. Sleep mode Blinking Network is disconnected, or SIP is NOT registered. AMROAD TECHNOLOGY INC.

  • Page 25: Rear Panel

    VIDEO INDOOR STATION Rear Panel Figure 13: Rear Panel – I/O Connectors AMROAD TECHNOLOGY INC.
  • Page 26 VOID sticker is broken or re oved. WARNING: “VOID” means “WARRANTY VOID IF SEAL BROKEN” Amroad shall not be responsible under warranty if the VOID sticker is broken or removed. AMROAD TECHNOLOGY INC.

  • Page 27: Dimensions

    VIDEO INDOOR STATION Dimensions Figure 14: Dimensions AMROAD TECHNOLOGY INC.

  • Page 28: Graphic User Interface

    MANUAL FOR SYSTEM INTEGRATOR Graphic User Interface Figure 15: Graphic User Interface AMROAD TECHNOLOGY INC.

  • Page 29: Making Phone Call

    Press the SpeedDial function key and then press the speed-dial number to make a  (video) phone call. NOTE: The phone number (extension number) of your ID5101 will be displayed on top-right corner of the Dial page. Figure 16: Making Phone Call Set Up the Speed-Dial Number You may use numeric keypads as shortcut keys to dial a (video) phone number rapidly.

  • Page 30: Incoming Call

    Answer soft-function to talk to the guest. Otherwise, user presses Reject soft-function key to ignore the door phone ringing. If user wants to open the gate/door during conversation, press the key pad to open it if the Electric-Door Lock has been installed. AMROAD TECHNOLOGY INC.

  • Page 31: Rfid Card

    RFID Card RFID (Rad io-Frequency IDentification) card is used to set ID5101 Security (Area A, B, C, and D) On/Off. As you know, RFID technology is also quickly becoming a popular choice in door/card access control system. Use your added RFID card to scan RFID reader to set Security (Area A, B, C, and D) On/Off.
  • Page 32 MANUAL FOR SYSTEM INTEGRATOR AMROAD TECHNOLOGY INC.

  • Page 33: Chapter 4 : Id5101 Graphic User Interface

    Safety & Security Area On the home screen of the ID5101, you can easity see the status of Safety and Security A, B, C, and D. The status of Safety indicates three safety devices including CO Detector, Emergency Button, and Gas Detector, and it should be always green for normal situation.

  • Page 34: Safety

    It may mean that someone broke in Area B. NOTE : User can scan registered RFID card on Card Reader of ID5101 to turn Security Area A, B, C, and D On/Off. To turn on security area, system will wait about 30/60/120/180/240 seconds for you to leave the house.

  • Page 35: Safety Status

    D Rear Door – MS (Magnetic Sensor) NOTE: To set Security On/Off, please refer to the following section Security Group Figure 23: Safety ABCD - Four Security Areas To go back to previous screen, press Exit soft-function key. AMROAD TECHNOLOGY INC.

  • Page 36: Security Group

    Figure 25: Security Group Security Group page. NOTE: There are two ways to set Security On/Off on your ID5101. The first is your added RDID Card, and the second is Manual Security Group described in this section. AMROAD TECHNOLOGY INC.

  • Page 37: Card Management

    RFID card users’ information. NOTE: If you want to change your password, press Chg Password soft-function key to pop up a dialogue box. Input the password, and again enter your new password to change password. Figure 27: Card Management AMROAD TECHNOLOGY INC.

  • Page 38: Adding/Editing User Information Of Rfid Cards

    MANUAL FOR SYSTEM INTEGRATOR Adding/Editing User Information of RFID Cards The figures below are the users’ information of RFID cards that have been added to the ID5101. User may edit card information or add new RFID card. Figure 28: Add/Edit RFID Card There are two ways to add RFID card.
  • Page 39 Figure 29: ChangeIME (Input Method Editor) Two kinds of IME (Input Method Editor) are available as below. Numerical Alphabetical Figure 30: Numerical and Alphabetical IME Remember to press OK soft-function key to save the information after you finish your input. AMROAD TECHNOLOGY INC.

  • Page 40: Deleting Rfid Card

    To delete the RFID card, press [Management Delete] soft-function key to delete RFID card. Then, the prompt “Select Management Action” appears. Press Delete soft-function key again to delete the selected RFID card. Figure 31: Deleting RFID Card AMROAD TECHNOLOGY INC.

  • Page 41: Videos (Surveillance)

    Figure 33: View live video from ID5101 ID5101 also helps to guard your premises by using it to view real-time video through SIP Camera. Or, make phone call to DP101R to view video outside the door. In fact, ID5101 features also the function of video surveillance.

  • Page 42: Live Video

    NOTE: The connections with other video devices are set through WEB UI. Figure 34: View Screen Enabling remote viewing, your ID5101 needs to connect with other cameras/video door phones. Then, select the SIP Camera, Video Door Phone you want to view through, press View soft-function key to see what’s happening.

  • Page 43: Messages

    All incoming calls, dialed calls, and missing calls will be recorded here (maximum 30 calls record).  Community: This item acts like Community Notice. Community notice or Mail notice may be sent from community management or guard room. AMROAD TECHNOLOGY INC.

  • Page 44: Alarm Record

    Press Enter soft-function key to view pictures of your visitors. Figure 38: Visitor Record NOTE: To have the pictures of visitors, you must have installed Amroad Video Door Phone series as your Video Door Phone. AMROAD TECHNOLOGY INC.

  • Page 45: Call Record

    Press Enter soft-function key to view detailed information. Figure 40: Community Notice & Mail Notification NOTE: To have the function of Community Notice and Mail Info, user needs to install Amroad ICMS (Intelligent Community Management Server). AMROAD TECHNOLOGY INC.
  • Page 46 MANUAL FOR SYSTEM INTEGRATOR AMROAD TECHNOLOGY INC.

  • Page 47: Chapter 5 : Setting Up The Id5101

    VIDEO INDOOR STATION Chapter 5 : Setting Up The ID5101 This chapter describes how to set up your Video Indoor Station. You may press Setting soft-function key to enter this Setting page. There are 8 major items for configuration: System Setting ...

  • Page 48: System Settings

    Use navigation keypad “∧”and “∨” keys to select preferred one, then press OK to confirm selection. Time Format You can select preferred time format at this field. There are 2 formats available: 12 hours and 24 hours system. You may use navigation keypad “∧”and “∨” keys to select preferred format. AMROAD TECHNOLOGY INC.

  • Page 49: Video Settings

    There are 4 options: White light, ellow light, Red Light and Deep red light. Please Figure 44: Video Settings select a suitabl e one to meet your room lighting nvironment. Default setting is Yellow light. AMROAD TECHNOLOGY INC.
  • Page 50 This item allows you to select the power frequency according to your local power specifications. here are 2 options: 60Hz and 50Hz. Please check with your local power company if you are not ure the correct value. AMROAD TECHNOLOGY INC.

  • Page 51: Audio Settings

    There are 11 items in this option. ITEM Description Net Type This item allows you to select type of IP address of this device. There are 3 options DHCP, Static IP and PPPoE, the Figure 46: Password Protection AMROAD TECHNOLOGY INC.
  • Page 52 DNS server address here if Static IP is selected. Secondary You may fill i n secondary DNS server address here if Static Figure 48: Network Setting-2 IP is selected. PPPoE You may fill in PPPoE account ID or name here if PPPoE is AMROAD TECHNOLOGY INC.

  • Page 53: Sip Setting

    ICMS IP The IP address of ICMS (Intelligent Community Manageme nt Server). NOTE: Your ID5101 needs to be connected to Amroad ICMS system. ICMS Port The port number of ICMS (Intelligent Community Manag ement Server). NOTE: Your ID5101 needs to be connected to Amroad ICMS system.
  • Page 54 Initial of Registration Time. This item is a parameter of SIP service. You may fill in the effective registration period of SIP service here. You have to contact your service provider to get correct setting. Default setting is 3600 seconds. AMROAD TECHNOLOGY INC.

  • Page 55: Streaming Setting

    Description Bandwidth You may select preferred bandwidth for video and audio streaming. There are 4 options: 128Kbps, 256Kbps, 384Kbps, and 512Kbps. Please check which bandwidth is suitable for you with your service provider. Figure 51: Streaming Setting AMROAD TECHNOLOGY INC.

  • Page 56: Services Setting

    Voice Mail box UnCondition To select “Enable” or “Disable” for UnCondition Forward Forward CFU Number All the phone calls will be forwarded to the number if UnCondition Forward is enabled. Busy Forward To enable/disable Busy Forward function AMROAD TECHNOLOGY INC.

  • Page 57: Screen Saver Setting

    4 options: 1 minute, 3 minutes, 5 minutes and Never. LCD Off You may select screen off executing period here. There are 6 options: 5 Minutes, 10 Minutes, 30 Minutes, 1 Hour 2 Hou rs and Never. Figure 54: Service Setting-2 AMROAD TECHNOLOGY INC.
  • Page 58 MANUAL FOR SYSTEM INTEGRATOR Figure 55: Screen Saver - Cl AMROAD TECHNOLOGY INC.

  • Page 59: Chapter 6 : Configuring Via Web Ui

    VIDEO INDOOR STATION Chapter 6 : Configuring via Web UI This chapter describes how to configure your ID5101 with Web User Interface. It contains advanced settings that may help you to solve certain compatibility issues with your services. This UI also provide remote management capability to service provider.

  • Page 60: System

    PC by pressing “Sync with PC” button. Date Format You can select preferred date format at this field. There are 3 formats available: YYYY/MM/DD, MM/DD/YYYY and DD/MM/YYYY. Figure 57: System – Basic AMROAD TECHNOLOGY INC.
  • Page 61 You may use your preferred NTP server by input new address here. Address Calibration You may sel ect when that y ou wish to do this NTP calibr ation. Schedule Save Click this bu tton to save your se tting. AMROAD TECHNOLOGY INC.
  • Page 62 NOTE：For PPPoE connection mode, we suggest that bandwidth-128kbps would have better video quality. C. Static IP: you have to input IP address, Subnet Mask, Default Gateway, Primary DNS and Secondary DNS data. Save Click this button to save your setting. AMROAD TECHNOLOGY INC.

  • Page 63: System Login Id

    Figure 59: System Login ID System Reboot When user needs to r oot his ID5101 remotely, just click “Reb oot” button on this webpage to start this action. After confirm rebooting, Web UI will back to the home page, but the video Indoor station may take 10~30 seconds to restart its system.

  • Page 64: Video Settings

    The default value of Start Port Number is 9000 u may select a start port number and set a range from that port. The range is between 4 and 64511. The default value of range is 100. Save Click this button to save your setting. AMROAD TECHNOLOGY INC.

  • Page 65: Audio Setting

    (-23db). (Acceptable value -20~-32) (Based on the environment of the installed location.) You may enable or disable Voice-Active-Detection function here. The ID5101 will detect background noise and send silence packet to the other end if this feature is enabled.
  • Page 66 MANUAL FOR SYSTEM INTEGRATOR enabled. Speaker Volume This item allows you to select volume of speaker. There are 10 levels, 0 ~ 9. Save Click this button to save your setting. AMROAD TECHNOLOGY INC.

  • Page 67: Sip Settings

    “Enable” the service to communicate in SIP mode. elect “Disable” the service to communicate in Peer-to-Peer mode. NOTE: For Peer-to-Peer mode, both devices (ID5101 and remote device) need to select Disable in the dropdown menu. And, fill in each other’s IP address.
  • Page 68 If you want to disable this feature, please fill in "0" sec. SIP TOS You may enable Tag-of-Service of SIP protocol here. RTP TOS You may enable Tag-of-Service of RTP protocol here. Save Click this button to save your setting. AMROAD TECHNOLOGY INC.

  • Page 69: Safety & Security

    DO1~DO3 are for Lighting, Lighting, Alarm. (DO4 is reserved). ITEM Description Device Name In the drop-down menu, sel ect the device name at your ID5101’s GPIO port is connected to. Triggered By For 8 Input ports only, user may select “Positive” or “Negative”. Figure 64: Device Setting En/Disable Select “Enable”...

  • Page 70: Alarm Notice

    System will wait to enable Safety (DI1-DI4) for user to leave house. DI1~4 Postpone After Select the time period- 30/60/120/180/240 seconds from drop-down menu. Alarm (DI1~4) System will wait to start alarm when any safety device (DI1~DI4) is triggered. . Triggered AMROAD TECHNOLOGY INC.
  • Page 71 SMS Setting SMS Account Enter the account of NOTE: The SMS(s) will be sent via TW SMS. For more detailed information, please contact Amroad for more information. SMS Password Enter the password of SMS account. Serial number for AR Enter a specific AR Serial Number for sending S MS, and user does not need to en AMROAD TECHNOLOGY INC.
  • Page 72 MANUAL FOR SYSTEM INTEGRATOR above account and password. NOTE: For more detailed information, please contact Amroad. Send To The first cell phone number to receive alarm SMS Send To The second cell phone number to receive alarm SMS Send To...

  • Page 73: Surveillance

    12 cameras/video phones’ location and call number t o view live v ideo to pay more care to your house and guard your home safe. After completing installation and setting, ID5101 lets you view live video and you will know what’s happening. Item Description...

  • Page 74: Upgrade

    MANUAL FOR SYSTEM INTEGRATOR Upgr The Upgrade function all ows you to upgrade firmware of the ID5101 Video Ind oor Station). Th e ways to upgrade the firmware are via Web UI. The Upgrade here goes through Web UI. There are...

  • Page 75: Config

    Figure 68: Configuration File through the Export File option. Upload After selecting the configuration file, you can press Upload button to start the importing. AMROAD TECHNOLOGY INC.

  • Page 76: Ar Aps

    MANUAL FOR SYSTEM INTEGRATOR Export File You can also use Export File to back up ID5101 settings on your phone. Download Press Download button to export, and you are prompt ed to click “Open” or “Save” for NewConfiguration.xml. If you click Save, the configuration file will be saved into a local directory.
  • Page 77 VIDEO INDOOR STATION Item Description APS_Server: This allows you to upgrade firmware of ID5101 through network. For example, APS_Server: https://rc.amroad.com. tw/aps/TaServlet/indoorstation.php Save Click this button to save your setting. AMROAD TECHNOLOGY INC.
  • Page 78 MANUAL FOR SYSTEM INTEGRATOR AMROAD TECHNOLOGY INC. MROAD TECHNOLOGY INC.

  • Page 79: Appendix A : Io Circuit & Applications

    VIDEO INDOOR STATION Appendix A : IO Circuit & Applications The ID5101, Video Indoo r Station, provides 8x Inputs ports and 4x Outputs ports for your h ome to set up Home Security and convenience; you may refer the following examples for each application.

  • Page 80: Gpio Connectors And Wire Color

    MANUAL FOR SYSTEM INTEGRATOR GPIO Connectors and Wire Color Before you begin to connect other devices to the ID5101, the I/O cables and their colors for GPIO connectors are illustrated as figure left. AMROAD TECHNOLOGY INC.

  • Page 81: Lighting Control (Photo)

    VIDEO INDOOR STATION LIGHTING CONTROL (Photo) The illustration (photo) shows u how to use first GPIO connector and wire to connect two Relay Boards for Lighting Control. AMROAD TECHNOLOGY INC.

  • Page 82: Lighting Control (Diagram)

    MANUAL FOR SYSTEM INTEGRATOR LIGHTING CONTROL (Diagram) The illustration (diagram) shows you how to use first row of the GPIO connector and wire to connect two Relay Boards for Lighting Control. AMROAD TECHNOLOGY INC.

  • Page 83: Alarm (Photo)

    VIDEO INDOOR STATION ALARM (Photo) The illustration (photo) shows you how to use firs t GPIO connector and wire to connect D C Power, and Relay Board for ALAR M system. AMROAD TECHNOLOGY INC.

  • Page 84: Alarm (Diagram)

    MANUAL FOR SYSTEM INTEGRATOR ALARM (Diagram) The illustration (diagram) shows you how to use first row of the GPIO connector and wire to connect DC power, and Relay Board for ALARM system. AMROAD TECHNOLOGY INC.

  • Page 85: Magnetic Switch (Diagram And Photo)

    Both Magnetic Switch diagram and photo show you how to use second row of the GPIO connector to connect with Magnetic Switches, and you can connect up to four magnetic switches accordingly based on the diagram or photo NOTE: The second GPIO connector is used to connect up to four Magnetic Switches. AMROAD TECHNOLOGY INC.

  • Page 86: Co Sensor

    GPIO connector to connect CO Sensor, and you can connect your C Sensor based on the diagram or photo. NOTE: The third GPIO connector is used to connect CO Sensor, Emergency Button, Gas Detector and Door Bell Button. AMROAD TECHNOLOGY INC.

  • Page 87: Emergency Button

    GPIO connector is used to connect the NO wire. TE: In the above diagram, there is a LED in the Emergency Button. Green wire is COM, as VCC is for the LED i n the Emergency Button. AMROAD TECHNOLOGY INC.

  • Page 88: Gas Detector

    3 GPIO connector to connect Gas Detector. The gray wire on the third-row GPIO connector is used to connect the NO wire. Besides, Gas Detector needs to connect an external AC Power. AMROAD TECHNOLOGY INC.

  • Page 89: Door Bell Button

    Door bell button. The blue wire on the third-row GPIO connector is used to connect to Door Bell Button. NOTE: The third GPIO connector is used to connect CO Sensor, Emergency Button, Gas Detector, and Door Bell Button. AMROAD TECHNOLOGY INC.

  • Page 90: Appendix B : Regulatory Information

    This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. “Changes or modifications are not expressly approved by the manufacturer could void the user's authority to operate the equipment.” AMROAD TECHNOLOGY INC.

  • Page 91: Ce Declaration Of Conformity (Europe)

    100 mW equivalent isotropic radiated power (EIRP) are considered as not compliant with the abo ve mentioned directive and are not allowed for use within the European community and countries that have adopted the European R&TTE directive 1999/5/EC. AMROAD TECHNOLOGY INC.
