SO601,080
DO64,080,000
K11165
K10170
Base top
Side
K13210
Back panel
2 pcs
2 pcs
K13355
Suspension list
1 pcs
K12155
Shelf
1 pcs
2 pcs
ID21570
L06440,160
Door
ID21570
Euro screw
Push open
6,3x11 mm
2 pcs
2 pcs
4 pcs
BP00417
BP00418
Mounting plate
Hinge 107 degrees
4 pcs
4 pcs
BP00002-BP00250
Bumper
Screw flh
Screw flh
Angle
Shelf support
7x1,5 mm
3,5x15 mm
3,5x45 mm
45x55x30x2 mm
5x7 mm Plast
2 pcs
4 pcs
2 pcs
8 pcs
8 pcs
28-09-2015 1
/
1 /
8
Advertisement
Related Manuals for Kvik SO601
Summary of Contents for Kvik SO601
- Page 1 SO601,080 DO64,080,000 K11165 K10170 Base top Side K13210 Back panel 2 pcs 2 pcs K13355 Suspension list 1 pcs K12155 Shelf 1 pcs 2 pcs ID21570 L06440,160 Door ID21570 Euro screw Push open 6,3x11 mm 2 pcs 2 pcs 4 pcs...
- Page 2 SO601,080 FIG. 5-12mm DEEP K11165 Base top FIG. K11165 Base top Euro screw 6.3x11mm 4 pcs ID21570 Push open 2 pcs Adjustment 28-09-2015 1...
- Page 3 SO601,080 FIG. K13355 Suspension list K13355 Suspension list K11165 Base top OBS !!! K11165 Base top K10170 Side FIG. K13210 Back panel 28-09-2015 1...
- Page 4 SO601,080 FIG. Screw flh K10170 3,5x45 mm Side 4 pcs FIG. Screw flh 3,5x45 mm 4 pcs 28-09-2015 1...
- Page 5 SO601,080 FIG. Screw flh Angle 3,5x15 mm 45x55x30x2 mm 4 pcs 2 pcs FIG. Shelf support 5x7 mm Plast 8 pcs 28-09-2015 1...
- Page 6 SO601,080 FIG. K12155 K12155 Shelf Shelf 2 pcs K12155 Shelf FIG. Click BP00418 BP00417 Hinge 107 degrees Mounting plate 2 pcs 2 pcs L06440,160 L06440,160 Door Door 28-09-2015 1...
- Page 7 SO601,080 FIG. Left L06440,160 Door FIG. Right L06440,160 Door 28-09-2015 1...
- Page 8 SO601,080 Adjustment 28-09-2015 1...
