SDBU4813,060
BU5160,000
US4851,000
K13360
Suspension list
K13258
K61115
K60148
Back panel
Base top
Side
1 pcs
1 pcs
2 pcs
2 pcs
Tip on 300R
Tip on 300L
Tip on 450L
Tip on 450R
1 pcs
1 pcs
1 pcs
1 pcs
BP00260-BP00250
Euro screw
Screw flh
Fitting bolt
Fitting house
Angle
6,3x11 mm
3,5x15 mm
5/11x24
15x11,7 mm
45x55x30x2 mm
2 pcs
20 pcs
8 pcs
2 pcs
8 pcs
23-08-2015 1
/
1 /
7
Advertisement
Related Manuals for Kvik SDBU4813,060
Summary of Contents for Kvik SDBU4813,060
- Page 1 SDBU4813,060 BU5160,000 US4851,000 K13360 Suspension list K13258 K61115 K60148 Back panel Base top Side 1 pcs 1 pcs 2 pcs 2 pcs Tip on 300R Tip on 300L Tip on 450L Tip on 450R 1 pcs 1 pcs 1 pcs...
- Page 2 SDBU4813,060 FIG. Tip on 450L / R 1 pcs Tip on 300L / R 1 pcs 23-08-2015 1...
- Page 3 SDBU4813,060 FIG. K60148 Side Euro screw 6,3x11 mm Screw flh 1 pcs 3,5x15 mm 4 pcs Screw flh 3,5x15 mm 4 pcs Tip on 300L 1 pcs Tip on 450L 1 pcs OBS !!! FIG. K60148 Side Screw flh 3,5x15 mm...
- Page 4 SDBU4813,060 FIG. Fitting bolt 5/11x24 4 pcs K60148 K60148 Side Side FIG. K13360 Suspension list K13360 Suspension list K61115 Base top OBS !!! K61115 Base top K60148 Side 23-08-2015 1...
- Page 5 SDBU4813,060 FIG. K13258 Back panel FIG. K60148 Side 23-08-2015 1...
- Page 6 SDBU4813,060 FIG. Fitting house 15x11,7 mm 8 pcs FIG. Screw flh 3,5x15 mm 4 pcs Angle 45x55x30x2 mm 2 pcs 23-08-2015 1...
- Page 7 SDBU4813,060 FIG. Adjustment 23-08-2015 1...
