Summary of Contents for Kvik SO820

  • Page 1 SO820 Check out easy mounting of your kitchen Right Left Front without integrated handle L08050 L08040 L08060 50 cm 60 cm 40 cm 23-02-2020 1a...
  • Page 2 SO820 Check out easy mounting of your kitchen DO80,***,000 (Suspension list) (Base-top) (Side) 1 pcs (Back panel) 2 pcs 2 pcs (Suspension list) 1 pcs 1 pcs Drawer slide left K15355 BP00417 Drawer slide right Hinge 155 degrees Mounting plate...
  • Page 3 SO820 FIG. Screw flh Euro screw 3,5x15 mm 6,3x11 mm 9 pcs 6 pcs Euro screw Screw flh 6,3x11 mm 3,5x15 mm (Side) Drawer slide left 3 pcs FIG. Screw flh 3,5x15 mm Euro screw 9 pcs 6,3x11 mm 6 pcs...
  • Page 4 SO820 FIG. NB!!! (Suspension list) (Suspension list) (Base-top) (Base-top) (Side) FIG. (Back panel) 23-02-2020 1a...
  • Page 5 SO820 FIG. (Side) Screw flh 3,5x45 mm 4 pcs FIG. Screw flh 3,5x45 mm 4 pcs 23-02-2020 1a...
  • Page 6 SO820 FIG. Screw flh 3,5x15 mm 4 pcs Angle 45x55x30x2 mm 2 pcs 1 pcs FIG. ID21570 Push open Adjustment Euro screw 6,3x11 mm 2 pcs 23-02-2020 1a...
  • Page 7 SO820 FIG. Click K15355 BP00417 Hinge 155 degrees Mounting plate 2 pcs 2 pcs Bumper 7x1,5 mm L080*0 Door L080*0 Door Bumper 7x1,5 mm FIG. Right Left L080*0 L080*0 Door Door 23-02-2020 1a...
  • Page 8 SO820 Adjustment FIG. 23-02-2020 1a...
  • Page 9 SO820 Installation, please read instruction SV12224 SV12224 How to wall mount a cabinet 19-12-2019 1a 23-02-2020 1a...
