0 035 66
Energy Data Logger
Installer manual
06/12-01 PC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F521 and is the answer not in the manual?

Questions and answers

Related Manuals for LEGRAND F521

Summary of Contents for LEGRAND F521

  • Page 1 0 035 66 Energy Data Logger Installer manual 06/12-01 PC...

  • Page 3: Table Of Contents

    Energy Data Logger Contents 1 Description Warnings and recommendations Main functions Legend 2 Connection Wiring diagrams 3 Configuration Procedure with Windows 2000 or XP operating system Procedure with Windows Vista or 7 operating system Procedure for Tablet and Smartphone Troubleshooting 4 Appendix Technical data...

  • Page 4: Description

    The SCS device saves the consumption values in separate energy lines. These lines can be both electric, by connecting Bus meters with 3 inputs for toroids, item F520, or a load management central unit, item F521, and non-electric, by connecting pulse counter interfaces, item 3522. The total number of lines managed cannot exceed 10.

  • Page 5: Legend

    Energy Data Logger Legend 1 - User interface LED: see table 2 - MicroSD memory card slot (optional) 3 - Connection to the SCS BUS 4 - Ethernet connection 5 - Reset key: – press and hold for 10 seconds to restart the Energy Data Logger; –...

  • Page 6: Connection

    2 Connection Wiring diagrams To put the device into operation, this must be connected following the diagrams below. Diagram with direct or crossover cable Diagram with switch Switch / router Check that your PC is set for automatic acquisition of the IP address (network parameters); then select the Energy Data Logger device among the network resources.

  • Page 7: Configuration

    Energy Data Logger 3 Configuration Procedure with Windows 2000 or XP operating system If the connection is correct, it will be possible to display the device in the My Network Places window, with the name “Energy Data Logger”. Double click on the icon to open the configuration WEB page. The Web pages can be accessed with two authority levels: “user"...
  • Page 8 3 Configuration If the device is not automatically recognised by the PC, follow the instructions below. To access the configuration page, and display the device IP address, the following parameters must be set: From the Start / Control panel menu 1 - Click "Windows Firewall".
  • Page 9 Energy Data Logger 2 - Select “Exceptions”. 3 - Enable "UPnP Framework". From the Start / Control panel menu 4 - Click “Add or Remove Programs”.
  • Page 10 3 Configuration 5 - Click “Add/Remove Windows components”. 6 - Enable “Networking services” 7 - Click “Details”.
  • Page 11 Energy Data Logger 8 - Enable "Internet Gateway Device Discovery and Control Client". 9 - Enable "UPnP User Interface". 10 - Click. 11 - Click.
  • Page 12 3 Configuration 12 - Click “Finish”. From the Start / Control panel menu 13 - Click “Administrative Tools”.
  • Page 13 Energy Data Logger 14 - Click “Services”. 15 - Set Automatic Startup Type for “Universal Plug and Play Device Host”.
  • Page 14 3 Configuration 16 - Click “Start” 17 - Click. 18 - Set Automatic Startup Type for “SSDP Discovery Service”.
  • Page 15 Energy Data Logger 19 - Click “Start”. 20 - Click.

  • Page 16: Procedure With Windows Vista Or 7 Operating System

    3 Configuration Procedure with Windows Vista or 7 operating system If the connection is correct, it will be possible to display the device in the My Network Places window, with the name “Energy Data Logger”. Double click on the icon to open the configuration WEB page. The Web pages can be accessed with two authority levels: “user"...
  • Page 17 Energy Data Logger If the device is not automatically recognised by the PC, follow the instructions below. To access the configuration page, and display the device IP address, the following parameters must be set: From the Start / Control panel menu 1 - Click "Windows Firewall".
  • Page 18 3 Configuration From the Start / Control panel menu 4 - Click “Network and Sharing Center” 5 - Click "Change advanced sharing settings" 6 - Turn on “Network discovery”...
  • Page 19 Energy Data Logger From the Start / Control panel menu 7 - Click “Administrative Tools” 8 - Click “Services”.
  • Page 20 3 Configuration 9 - Set Automatic Startup Type for item "UPnP Device Host" and ensure that it has actually been enabled. 10 - Click “Start”. 11 - Click.
  • Page 21 Energy Data Logger 12 - Set Automatic Startup Type for item “SSDP Discovery” and ensure that it has actually been enabled. 13 - Click “Start”. 14 - Click.

  • Page 22: Procedure For Tablet And Smartphone

    3 Configuration Procedure for Tablet and Smartphone If viewing the pages using a Tablet or a Smartphone, it is recommend to set fixed IP and IP mask; in alternative, use an application for the identification of UPnP devices. Troubleshooting Problem Solution Power the device by pressing and holding down the reset key until the red LED starts flashing: initialisation of the...

  • Page 23: Appendix

    Energy Data Logger 4 Appendix Technical data Power supply from BUS 18 – 27 Vdc Assorbimento 30 mA (max) Operating temperature 5 – 45 °C...
  • Page 24 : 33 5 55 06 87 87 Fax : 33 5 55 06 74 55 www.legrand.com Legrand reserves at any time the right to modify the contents of this booklet and to communicate in any form and modality, the changes brought to the same.
