LED Multi SeaCam
Operator's Manual
4033 Ruffin Road
San Diego, CA
T:
(858) 576-1261
92123- 1817 USA
F:
(858) 576-0219
LED Multi-SeaCam
Record product serial number below as it appears on the nameplate.
Serial #
Connector Type
Pin-outs
● Ground = Pin
● PWR = Pin
● Video = Pin
www.deepsea.com
sales@deepsea.com
®
®
Original Instruction
REV 08/15/17
Advertisement
Table of Contents
Related Manuals for DeepSea Power & Light LED Multi SeaCam
Summary of Contents for DeepSea Power & Light LED Multi SeaCam
-
Page 1: Recording Form For Machine Serial Number
LED Multi SeaCam ® Operator’s Manual ® LED Multi-SeaCam Record product serial number below as it appears on the nameplate. Serial # Connector Type Pin-outs ● Ground = Pin ● PWR = Pin ● Video = Pin 4033 Ruffin Road www.deepsea.com... -
Page 2: Specification Overview
Operator’s Manual LED Multi SeaCam ® Specification Overview Standard Connector LEDMSC-1055 LEDMSC-1065 LEDMSC-2065 Mechanical Specifications BH4MP Housing Titanium Port Sapphire 1 = Ground 2 = Power Outer 47.4 mm [1.86 in.] 3 = Video Diameter 4 = Not Used Overall Length 106.5 mm [4.19 in.]... -
Page 3: Table Of Contents
Operator’s Manual LED Multi SeaCam ® Table of Contents Recording Form for Machine Serial Number Specification Overview Table of Contents Safety Symbols General Notes and Warnings Pre & Post Dive Inspection Operation Procedures Operation Instruction LED Ring Operation Flooding Repair Procedure... -
Page 4: Safety Symbols
Be sure to verify pin-out orientation before use. Rinse your LED Multi SeaCam in fresh water after use It is very important when preparing the system for de- in saltwater. ployment that the cable, at both the camera and topside... -
Page 5: Led Ring Operation
Operator’s Manual LED Multi SeaCam ® respective jacks on the power supply. 3. Plug the BNC connector on the topside of the 1. Immediately turn off the power to the unit. cable into the monitor or VCR video-in jack (a 2. -
Page 6: Rma Procedure For Repair
Operator’s Manual LED Multi SeaCam ® RMA Procedure for Repair for parts which have been proved defective and does not include any other costs such as the cost of removal of the defective part, installation, labor, or consequen- Should it be necessary to return your camera to the...
