Low-Light SeaCam
Record product serial number below as it appears on the nameplate.
Serial #
Connector Type
Pin-outs
● Ground = Pin
● PWR = Pin
● Video = Pin
www.deepsea.com
sales@deepsea.com
®
Original Instruction
REV 10/12/15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DeepSea Power & Light SEACAM
Summary of Contents for DeepSea Power & Light SEACAM
- Page 1 Low-Light SeaCam ® Operator’s Manual ® Low-Light SeaCam Record product serial number below as it appears on the nameplate. Serial # Connector Type Pin-outs ● Ground = Pin ● PWR = Pin ● Video = Pin 4033 Ruffin Road www.deepsea.com...
-
Page 2: Specification Overview
Low-Light SeaCam Operator’s Manual ® Specification Overview Standard Connector LLSC-3085 Mechanical Specifications BH4MP/MCBH4MP Housing Aluminum 1 = DC- Titanium 2 = DC+ 3 = Video Port Optically Polished Glass Hemisphere 4 = N/C Outer Diameter 56 mm [2.20 in] (w/o crash gaurd) Overall Length 124 mm [4.88 in]... -
Page 3: Table Of Contents
Operator’s Manual Low-Light SeaCam ® Table of Contents Specification Overview Table of Contents Safety Symbols General Notes and Warnings Pre & Post Dive Inspection Operation Instructions Flooding Repair Procedure Troubleshooting RMA Procedure for Repair Warranty Information... -
Page 4: Safety Symbols
It is very important when preparing the system for de- ployment that the cable, at both the camera and topside Rinse your Low-Light SeaCam in fresh water after use ends, be carefully dressed to provide complete strain re- in saltwater. -
Page 5: Operation Instructions
Operator’s Manual Low-Light SeaCam ® come internally pressurized, which may be potential- ly dangerous. Additionally, if the power remains on IMPORTANT! DeepSea Power & Light cannot when the camera has partially flooded, it is possible be responsible for any damage incurred during for electrolytic generation of an explosive mixture of emergency field repairs. -
Page 6: Warranty Information
Low-Light SeaCam Operator’s Manual ® DeepSea Power & Light Attn: RMA #### 4033 Ruffin Road San Diego, CA 92123-1817 U.S.A Tel: (858) 576-1261 Fax: 858-576-0219 e-mail: RMA@deepsea.com Warranty Information Limited Warranty Seller warrants that the goods (except internal electronic components) sold under this contract will be free from...
