- Page 1 DC-A11 Wireless Docking with AW-NU120 Dongle User Manual [Important] Please visit Lumens http://www.lumens.com.tw/goto.htm download the latest software, drivers, and documentation English...
-
Page 2: Table Of Contents
Available Network................24 Status....................24 Statistics ................... 25 Wi-Fi Protected Setup (WPS)............25 Chapter 7 Descriptions of Major Functions............. 26 I would like to configure DC-A11 connection settings on the Internet26 English... - Page 3 I would like to change the login password........26 I would like to change the SSID and Channel........26 I would like to check the WPS connection settings ......27 I would like to update the firmware........... 27 ...
-
Page 4: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 5: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Always follow these safety instructions when setting up and using the Wireless Flyer: 1. Do not place Wireless Flyer in tilted position. 2. Do not place the Wireless Flyer on an unstable trolley, stand or table. 3. -
Page 6: Safety Precautions
Safety Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Note Risk of Electric Shock Note: To reduce the risk of electric shock. Do not remove cover (or back). No user-serviceable parts inside. -
Page 7: En55022 (Ce Radiation) Warning
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. EN55022 (CE Radiation) Warning This product is intended for use in a commercial, industrial, or educational environment. It is not intended for residential use This is a Class A product. -
Page 8: Chapter 2 Package Contents
Chapter 2 Package Contents DC-A11 Quick Start Guide To download this manual in other languages, visit Lumens website Dongle AC Adapter Power Cord Appearance may vary depending on country/region USB Connection Cable English... -
Page 9: Chapter 3 Product Overview
8. USB connector fixing hole 4. USB 1.POWER 2.WPS 3.Default Settle the USB connector 1. Disconnect the ball chain on the USB connector holder. 2. Thread the ball chain through the connector fixing hole on DC-A11. 3. Shackle the ball chain. English... -
Page 10: Chapter 4 Installation And Connections
Chapter 4 Installation and Connections 4.1 Installing DC-120 Connection Cable English... -
Page 11: Installing Dongle
4.2 Installing Dongle 4.2.1 Pull out the Dongle and remove the protective film 4.2.2 Installing the Dongle into the USB port on a computer [Note] If the preview of Ladibug is opened, do not unplug the Dongle directly from the computer. You should unplug the Dongle after the Ladibug is closed. -
Page 12: Connect To A Computer By Using A Wireless Usb Dongle
4.3 Connect to a computer by using a wireless USB Dongle Dongle Computer 4.4 Use a network cable to connect to a computer Computer English Computer... -
Page 13: Installing Application Software
Windows XP SP2 and above 4.5.2 Installing Ladibug [ Note: Please be sure to install the Ladibug™ from the DC-A11 CD. ] 4.5.2.1 Insert the software CD into your computer. 4.5.2.2 The software installation program will automatically launch. Please select [ Install Ladibug ] to begin installation. - Page 14 4.5.2.3 Please follow the instructions, then press [ Next ]. English...
- Page 15 4.5.2.4 Press [ Yes ] to create a Ladibug™ shortcut on your desktop. 4.5.2.5 Continue to install the [ Lumens Wireless DC1 ] . English...
- Page 16 4.5.2.6 Click [ NO ], then press [ Finish ] to cancel the restart. [NOTE: Please restart the computer only when the installation of Wireless LAN Utility is completed.] 4.5.3 Installing Wireless LAN Utility [NOTE] This utility doesn’t support MAC OS. 4.5.3.1 Please select [ Wireless LAN Utility ] to begin installation.
- Page 17 4.5.3.4 Please click the [ Finish ] button to restart your computer. English...
- Page 18 4.5.3.5 Setup the utility 4.5.3.5.1 Auto connection a. Power on. b. Press the WPS buttons on DC-A11 and the Dongle. (Whatever the order, but the action must be within 30 seconds.) (Note: If the WPS button on the wireless Dongle cannot be used, open the Wireless LAN Utility and go to the [Wi-Fi Protected Setup] page.
- Page 19 c. The connection will start when the following window pops up. The connection will complete when the window closes. d. Double click the icon of Wireless LAN Utility. English...
- Page 20 4.5.3.5.2 Manual connection a. Double click the icon of Wireless LAN Utility. b. Select [ Available Network ] tab, double click [ DC-A11 ] (Default). c. Click [ OK ]. (Remark: This step may not show up due to different OS.)
- Page 21 d. The connection is activated if the status is [ Associated ]. Please click [ Close ] to exit. English...
-
Page 22: Chapter 5 Start Using
2. Please make sure you have installed Ladibug™ and Wireless LAN Utility. Please refer to 4.5 Installing application software 3. Switch the Power to [ ON ]. 4. Select the DC-A11 wireless network by using Dongle or internal wireless connection. 5. Double click on icon to activate Ladibug software. -
Page 23: Chapter 6 Function Menu
Chapter 6 Function Menu 6.1 General After starting the utility, the general page pops up. The [ General ] tab provides the information of your current wireless network connection. You may click the [ Renew IP ] button to refresh the information. Functions Status Check if the device is connected to target... -
Page 24: Profile
6.2 Profile The [ Profile ] tab lists the preferred connections. You can click the buttons beside to configure each connection. Functions To add a connection profile. To remove a connection profile. Remove To modify the configurations for a profile. Edit To make a copy of a profile. -
Page 25: Available Network
6.3 Available Network The [ Available Network ] tab lists the reachable wireless network. Functions To rescan available Wireless Networks. Refresh To add an available Wireless Networks to your Add to Profile profile list. 6.4 Status The [ Status ] tab shows the current connection status. English... -
Page 26: Statistics
An easy and secure setup solution for Wi-Fi network. Functions Choose your AP for PIN Code connection. Pin Input Config Search for available network connection. Push Button Config [Note] Please also push the WPS button on DC-A11 for connection. English... -
Page 27: Chapter 7 Descriptions Of Major Functions
Chapter 7 Descriptions of Major Functions 7.1 I would like to configure DC-A11 connection settings on the Internet 7.1.1 Open the Internet Explorer webpage browser, and enter [192.168.2.1] in the address bar. 7.1.2 Enter the Login Name [ Admin ]. -
Page 28: I Would Like To Check The Wps Connection Settings
[ Disable ]. 7.4.3 Click [ Apply ] 7.5 I would like to update the firmware 7.5.1 Please visit Lumens website: http://www.lumens.com.tw/goto.htm to download the updated firmware file. 7.5.2 Click the [ Firmware ] button to enter the [ Firmware ] page. -
Page 29: Chapter 8 Led Light Indicators
Chapter 8 LED Light Indicators 8.1 POWER：The battery indicator lights blue. ： 8.2 Battery 8.2.1 Light Off : No Power 8.2.2 Blue : Full Power 8.2.3 Red : Low power 8.2.4 Flashing Blue Light : In Charge 8.3 WPS： 8.3.1 Flashing Red Light : Detecting connection 8.3.2 Blue Light : Connection established English... -
Page 30: Chapter 9 Troubleshooting
Chapter 9 Troubleshooting This chapter describes problems you may encounter while using DC-A11. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact our distributors or service center. - Page 31 4. Make sure that DC-A11 network connection is correctly configured. Please refer to 4.5.3.5 Setup the utility. 5. Use of two or more DC-A11 devices in the same place might interfere the wireless signals. It is advised to change the frequency channel of either one DC-A11 device to a different one in order to avoid signal interference.
