Lumens DC-A11 User Manual

Wireless flyer
Hide thumbs Also See for DC-A11:
Table of Contents

Advertisement

Quick Links

Download this manual
DC-A11
Wireless Flyer
User Manual
[Important]
To download the latest version of Quick Start
Guide, multilingual user manual, software, or
™
driver, etc., please visit Lumens
http://www.Mylumens.com/goto.htm
- 0
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-A11 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lumens DC-A11

Summary of Contents for Lumens DC-A11

  • Page 1 DC-A11 Wireless Flyer User Manual [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or ™ driver, etc., please visit Lumens http://www.Mylumens.com/goto.htm English...

  • Page 2: Table Of Contents

    SAR Warning ....................6 Revisions......................7 Chapter 2 Package Contents ................8 Chapter 3 Product Overview ................9 DC-A11 ....................9 Dongle ....................9 Settle the USB connector ..............10 Chapter 4 LED Light Indicators ..............11 Chapter 5 Installation and Connections............12 Installation flow chart ................
  • Page 3 6.2.3 MAC OS X v10.6 / 10.7 ..............37 Chapter 7 Descriptions of Major Functions ............. 39 I would like to configure DC-A11 connection settings on the Internet39 I would like to change the login password ........39 I would like to change the SSID and channel ........39 I would like to check the WPS connection settings ......

  • Page 4: Copyright Information

    Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice.

  • Page 5: Chapter 1 Safety Instructions

    Chapter 1 Safety Instructions Always follow these safety instructions when setting up and using the Wireless Flyer: 1. Do not place Wireless Flyer in tilted position. 2. Do not place the Wireless Flyer on an unstable trolley, stand or table. 3.

  • Page 6: Safety Precautions

    DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS. Warning 2: The wireless Docking unit (FCC ID: YVR-DC-A11) complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator &...

  • Page 7: En55022 (Ce Radiation) Warning

     EN55022 (CE Radiation) Warning This product is intended for use in a commercial, industrial, or educational environment. It is not intended for residential use This is a Class A product. In a domestic environment it may cause radio interference, in which case the user may be required to take adequate measures.

  • Page 8: Revisions

    Revisions English...

  • Page 9: Chapter 2 Package Contents

    Chapter 2 Package Contents Wireless USB DC-A11 Quick Start Guide Dongle for PC (To download this manual in other languages, visit Lumens web site) USB Connection AC Adapter Power Cord Cable Appearance may vary depending on country/region English...

  • Page 10: Chapter 3 Product Overview

    Chapter 3 Product Overview 3.1 DC-A11 8. LED indicator 7. Antenna 6. LAN 5. USB connector fixing hole 4. USB 1. POWER 2. WPS 3. Default 3.2 Dongle 1. WPS English...

  • Page 11: Settle The Usb Connector

    3.3 Settle the USB connector 1. Disconnect the ball chain on the USB connector holder. 2. Thread the ball chain through the connector fixing hole on DC-A11. 3. Shackle the ball chain. - 10 English...

  • Page 12: Chapter 4 Led Light Indicators

    Chapter 4 LED Light Indicators 4.1 POWER: The battery indicator lights blue. 4.2 Battery 4.2.1 Light Off: No Power 4.2.2 Blue: Full Power 4.2.3 Red: Low power 4.2.4 Flashing Blue Light: In Charge 4.3 WPS: 4.3.1 Flashing Red Light: Detecting connection 4.3.2 Blue Light: Connection established - 11 English...

  • Page 13: Chapter 5 Installation And Connections

    Chapter 5 Installation and Connections 5.1 Installation flow chart Start Install software Refer to Section 5.2 Installing application Install software for software Ladibug installation or Podium View Install Wireless LAN Utility Install hardware Refer to Sections 5.3 Install USB to 5.4 for hardware Document installation...

  • Page 14: Installing Application Software

    Installing Ladibug™ or Podium View™ — in Windows XP / Vista 5.2.2 5.2.2.1 Please download the Ladibug™ or Podium View™ software after connected to the Lumens™ web site. 5.2.2.2 Click the EXE file after decompressing the downloaded file. 5.2.2.3 Select installation language.
  • Page 15 5.2.2.5 Press [Yes] to create a Ladibug or Podium View shortcut on your desktop. 5.2.2.6 Click [NO], then press [Finish] to cancel the restart. [NOTE: Please restart the computer only when the installation of Wireless LAN Utility is completed.] - 14 English...
  • Page 16 5.2.3.6 Click [Allow From Anywhere], confirm to disable the validation, and start installation. 5.2.3.7 Please download the Ladibug™ or Podium View™ software after connected to the Lumens™ web site. 5.2.3.8 Click the [Ladibug] or [Podium View] icons for installation after decompressing the downloaded file.
  • Page 17 5.2.3.10 Press [Continue]. 5.2.3.11 Press [Install]. - 16 English...
  • Page 18 5.2.3.12 Enter your name and password, and then press [OK]. 5.2.3.13 Press [Continue Installation]. - 17 English...
  • Page 19 5.2.3.14 Press [Restart] to finish the installation. - 18 English...
  • Page 20 5.2.4 Installing Wireless LAN Utility — in Windows XP / Vista 5.2.4.1 Please download the Wireless LAN Utility software after connected to the Lumens™ web site. 5.2.4.2 Click the EXE file after decompressing the downloaded file. 5.2.4.3 Select Language. 5.2.4.4 Please follow the instructions, then press [Next].
  • Page 21 5.2.5.6 Click [Allow From Anywhere], confirm to disable the validation, and start installation. 5.2.5.7 Please download the Wireless LAN Utility software after connected to the Lumens™ web site. 5.2.5.8 Press the [Installer] icon, open the installation wizard, and run the installation process by following the onscreen instructions after decompressing the downloaded file.
  • Page 22 5.2.5.9 Press [Continue]. 5.2.5.10 Select the language, and press [Continue]. - 21 English...
  • Page 23 5.2.5.11 Press [Agree]. 5.2.5.12 Press [Install]. 5.2.5.13 Enter your name and password, and then press [OK]. - 22 English...
  • Page 24 5.2.5.14 Press [Continue Installation]. 5.2.5.15 Press [Restart] to finish the installation. - 23 English...

  • Page 25: Installing Dc120

    5.3 Installing DC120 5.3.1 Installing DC120 on DC-A11 5.3.2 Installing USB connection cable on DC120 and DC-A11. connection cable - 24 English...

  • Page 26: Installing Dongle

    5.4 Installing Dongle 5.4.1 Pull out the Dongle and remove the protective film 5.4.2 Installing the Dongle into the USB port on a computer <NOTE> If the preview of Ladibug or Podium View is opened, do not unplug the Dongle directly from the computer. You should unplug the Dongle after the Ladibug or Podium View is closed.

  • Page 27: Chapter 6 Start Using

    Chapter 6 Start Using Dongle 1. Charge the unit for 3 hours before the first use. 2. Switch the Power to [ ON ] .(Note: When the unit is fully charged, indicator lights blue. 3. To start connection, please follow the steps of Section 6.1.1 Auto connection.

  • Page 28: Start Wireless Connection

    A live image is displayed when the setting is finished. Note: You are advised to confirm the local voltage/frequency before setting the POWER Frequency. For example, 60Hz is applicable for America, Taiwan, Japan, etc; 50Hz is applicable for Europe or other regions. 9.

  • Page 29: Method 1: Auto Connection

    Within 30 seconds, press and hold the WPS button of Dongle for about 5 seconds. ▼<Note> The WPS indicator of DC-A11 will now flash red, and then light blue after the connection is made. The WPS connection of a second DC-A11 at the same time may cause disturbance and lead to connection failure.
  • Page 30 The connection will start when the following window pops up. The connection will complete when the window closes.  For MAC The connection will start when the following window pops up. Press [OK] to finish the connection. - 29 English...
  • Page 31 d. Connection succeeded.  For Windows Double click the icon of Wireless LAN Utility.  For MAC The following window pops up when the connection is finished. - 30 English...

  • Page 32: Method 2: Manual Connection

    Double click the icon of Wireless LAN Utility. b. Select [Available Network] tab, double click [DC-A11] (Default). c. Click [OK]. (Remark: This step may not show up due to different OS.) d. Confirm the connection setting and click [OK] to apply the setting.
  • Page 33 e. The connection is activated if the status is [Associated]. Please click [Close] to exit. - 32 English...
  • Page 34  For MAC a. Insert Dongle, and the following window will pop up. b. Select [Available Network] tab and click [DC-A11] (Default). Then, press [Connect] to start connection. - 33 English...

  • Page 35: Change The Ssid

    c. Connection succeeded. 6.1.3 Change the SSID 6.1.3.1 Open the Internet Explorer webpage browser, and enter [192.168.2.1] (default) in the address bar. 6.1.3.2 Enter the Login Name [Admin]. 6.1.3.3 Enter the Password ([Admin] by default), and click the [Login] button. 6.1.3.4 Enter the [Basic] page.

  • Page 36: Change The Setting Of Firewall

    6.2 Change the setting of firewall 6.2.1 Windows XP 6.2.1.1 Select [Console] in [Start] menu. 6.2.1.2 Click [Information Security Center], and then click [Windows Firewall]. [Remark] Click [Windows Firewall] in the traditional view of [Console]. 6.2.1.3 In [Windows Firewall Setting] window, click the tab [Exceptions]. 6.2.1.4 Be sure to select Ladibug/Podium View under [Programs and Services], and then click [OK].

  • Page 37: Windows 7

    6.2.1.7 Exit [Windows Firewall Setting], and start to use the software. 6.2.2 Windows 7 6.2.2.1 Select [Console] in [Start] menu. 6.2.2.2 Click [System and Security], and then click [Allow a program through Windows Firewall]. [Remark] Click [Windows Firewall] in the icon view of [Console]. 6.2.2.3 Select [Change settings] in [Allowed programs and features] window.

  • Page 38: Mac Os X V10.6 / 10.7

    6.2.2.6 Select Ladibug/Podium View, and then click [Add]. If it was not listed, please click [Browse], select Ladibug/Podium View program, and then click [Enable]. [Remark] Ladibug/Podium View may be displayed in the form of Ladibug.exe/Podium View.exe. 6.2.2.7 Click [OK] in [Allowed Program] window. 6.2.2.8 Close [Windows Firewall Setting] window.
  • Page 39 6.2.3.6 Click [Advanced] at the lower right corner. 6.2.3.7 Select [Automatically allow signed software to receive incoming connections]. 6.2.3.8 Change Ladibug/Podium View in the list to [Allow incoming connections]. If the software name was not listed, please click [+] to add new programs to the list, and start to use the software.

  • Page 40: Chapter 7 Descriptions Of Major Functions

    <NOTE 1> Close the Ladibug or Podium View before you modify any settings. [Note 2] After setting, please turn off the DC-A11 power supply and restart to apply the settings I would like to configure DC-A11 connection settings on the Internet 7.1.1 Open the Internet Explorer webpage browser, and enter [192.168.2.1]...

  • Page 41: I Would Like To Check The Wps Connection Settings

    7.4.3 Click [Apply]. [Note] Auto connection is available for WPS function. I would like to update the firmware 7.5.1 Please visit Lumens™ web site: http://www.Mylumens.com/goto.htm to download the updated firmware file. 7.5.2 Click the [Firmware] button to enter the [Firmware] page.

  • Page 42: I Want To Enable The Encryption Mode

    I Want to enable the encryption mode 7.6.1 Set up encryption 7.6.1.1 Use WEP encryption 1. Enter [Basic] Page. 2. [Encryption Type]: Select an encryption mode. It is recommended that you set up your password with [WEP] Type. 3. WEP Key 1~4: Select one and enter a passphrase. 1.
  • Page 43 7.6.1.2 Use WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK Mixed encryption 1. Enter the [Basic] page 2. [Encryption Type]: Select an encryption type [WPA-PSK/WPA2-PSK] 3. [WPA Cipher Suite]: Select a format [TKIP/CCMP] 4. [WPA Passphrase]: Set up a password 1. To use ASCII: Enter 8 to 63 characters (0-9 and A-Z only) 2.
  • Page 44 7.6.2.1 WEP encryption  For Windows 1. Double click the Wireless LAN Utility icon. 2. Select [Available Network] tab and click [DC-A11] (Default SSID name). 3. Settings: A. Enter a Network Key A1. To use ASCII: Please check [ASCII] and enter a corresponding passphrase A2.
  • Page 45 Connection is successfully encrypted - 44 English...
  • Page 46  For MAC 1. Double click the Wireless Network Utility icon. 2. Select [Available Network] tab and click [DC-A11] (Default SSID name). Press Connect. 3. Settings: A. Enter a network key A1. To use ASCII: Please check [ASCII] and enter a corresponding passphrase.
  • Page 47 Connection is successfully encrypted - 46 English...
  • Page 48  For Windows 1. Double click the Wireless LAN Utility icon. 2. Select [Available Network] tab and click [DC-A11] (default). 3. Please enter a corresponding passphrase in the [Network key] and [Confirm network key] column. 4. Press [OK] to apply your changes.
  • Page 49 Successfully connected - 48 English...
  • Page 50  For MAC 1. Double click the Wireless Network Utility icon. 2. Select [Available Network] tab and click [DC-A11] (Default SSID name). Press Connect. 3. Please enter a corresponding passphrase in the [Network key] and [Confirm network key]. 4. Press [OK] to apply your changes.
  • Page 51 Connection is successfully encrypted - 50 English...

  • Page 52: I Want To Cancel The Encryption Mode

    I Want to cancel the encryption mode 7.7.1 Setup 1. Enter [Basic] page. 2. [Encryption Type]: Select [None]. 3. Press [Apply] to apply your changes. 7.7.2 Connecting (Without encryption) Please refer to Method 1 or Method 2 of 6.1 Start wireless connection for reconnection.

  • Page 53: Chapter 8 Administration Menu

    Chapter 8 Administration Menu Wireless LAN Utility 8.1.1 General After starting the utility, the general page pops up. The [General] tab provides the information of your current wireless network connection. You may click the [Renew IP] button to refresh the information. Functions Status Check if the device is connected to target network.

  • Page 54: Profile

    8.1.2 Profile The [Profile] tab lists the preferred connections. You can click the buttons beside to configure each connection. Button Functions Profile Name Name of the profile. In the list, icon indicates the connected communication equipment. SSID The SSID of the profile To add a connection profile.

  • Page 55: Available Network

    8.1.3 Available Network The [Available Network] tab lists the reachable wireless network. Functions Refresh To rescan available wireless networks. Add to Profile To connect and add an available connection profile. 8.1.4 Status The Status page shows current equipment status, including the name of manufacturer, firmware version and the current network settings.

  • Page 56: Statistics

    Pin Input Config To select the PIN Code in your AP for WPS connection. Search the base station with WPS function for Push Button Config available network connection. [Note] Please also push the WPS button on DC-A11 for connection. - 55 English...

  • Page 57: Webpage Administration

    Webpage administration 8.2.1 Wireless 8.2.1.1 Basic After you enter the webpage, the [Basic] page displays. You can check and modify the current setting of the DC-A11. Function Descriptions SSID SSID Channel To select any of channels 1 to 14. Encryption Type...

  • Page 58: System

    8.2.1.3 Advanced Advance Function Descriptions Channel Width Band-width mode ShortGI Enable or disable the Short GI (Guard Interval) 8.2.2 System 8.2.2.1 LAN Network setting page Function Descriptions IP address setting Subnet Mask Netmask Available address range DHCP Server Address Range - 57 English...
  • Page 59 8.2.2.2 Admin Administration page for change of webpage password Function Descriptions Login Name Webpage administration account New Password New password Retype Password Re-type password for confirmation. 8.2.2.3 Firmware You can update the software, return to the default value and restart the machine on this page.

  • Page 60: Chapter 9 Troubleshooting

    Chapter 9 Troubleshooting This chapter describes problems you may encounter while using DC-A11. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact our distributors or service center.
  • Page 61 5. Use of two or more DC-A11 devices in the same place might interfere the wireless signals. It is advised to change the frequency channel of either one DC-A11 device to a different one in order to avoid signal interference.
  • Page 62 2. You do not have to reset the configurations DC-A11 or Dongle? when the Dongle is changed. Password missing. Please hold the [Reset] button on DC-A11 for 5 Failure to login the seconds to reset all configurations to factory default admin page.
  • Page 63 Select Connect to a network option in the “Network and Sharing Center” window, and access points found in your wireless environment will appear for your selection. Select DC-A11 from the Dongle wireless network connection (Realtek RTL819ISU Wireless LAN 802.11n USB 2.0 Network Adapter) and click Connect.
