CSB200 Class B AIS
This tab displays safety related messages received from other AIS
equipped vessels in the area. The tab displays two message types:
•
Addressed Safety Related Message (VDL Message #12)
•
Broadcast Safety Related Message (VDL Message #14)
The UTC time the message was received, along with the MMSI of the
sender will be displayed along with the text contents of each message.
Commands
The commands tab provides access to software controlled features of the
CSB200 transponder. Depending on the AIS software version the
following commands may be available:
•
Configure baud rates
o Baud rates for the RS232 and RS422 (NMEA 0183)
communications ports can be set here. The default
value is 38400 & should be used where possible. The
R1.0 17
CSB200 Class B AIS
'Update' button should be clicked to send new settings to
the AIS transponder.
•
Alarm output options
By default the AIS transponder will output the status of all alarms every
minute using AIALR sentences. The unit can be optionally configured to
only output active alarms using the radio buttons. The 'Update' button
should be clicked to send new settings to the AIS transponder.
COMAR SYSTEMS LTD
Medina Court
Arctic Road
Cowes
Isle of Wight
PO31 7XD
United Kingdom
Telephone: +44 (0)1983 282400
Fax: +44 (0)1983 280402
E-Mail: techsupport@comarsystems.com
Internet: www.comarsystems.com
R1.0 18
