Page 1 ERB-3209 Elite Handheld 2D Image Barcode Reader User’s Manual Elite Reader...
Page 2 Auto Identify Data Collect Technology Inc. (“aidcti”) reserves the right to make changes in specifications and other information contained in this document without prior notice. So the reader should in all cases consult aidcti to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of aidcti.
Page 3 The user may find the following booklet helpful: “Something About Interference.” This is available at FCC local regional offices. aidcti is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by aidcti.
Page 4 CE marked and does not comply with the Low Voltage Directive. Waste Electrical and Electronic Equipment Information aidcti complies with Directive 2002/96/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL on waste electrical and electronic equipment (WEEE). This product has required the extraction and use of natural resources for its production.
Page 5: Table Of Contents
Table of Contents Chapter 1 - Getting Started About This Manual ............1-1 Unpacking Your Device..........1-1 Connecting with USB ..........1-1 Reading Techniques ........... 1-3 Resetting the Factory Defaults........1-4 USB HID Interface............1-5 Chapter 2 - Input/Output Settings Power Up Beeper ............2-1 Beep on BEL Character..........2-1 Trigger Click..............2-1...
Page 6 Reread Delay ............2-9 User-Specified Reread Delay........2-10 Centering..............2-11 No Read ..............2-12 Video Reverse............2-13 Working Orientation ..........2-14 Chapter 3 - Data Editing Prefix/Suffix Overview ..........3-1 To Add a Prefix or Suffix: ........3-1 To Clear One or All Prefixes or Suffixes....3-2 To Add a Carriage Return Suffix to All Symbologies ...........
Page 7 Miscellaneous Commands........4-6 Data Formatter.............4-7 Primary/Alternate Data Formats ........4-8 Chapter 5 - Symbologies All Symbologies ............5-2 Message Length Description ........5-2 Codabar...............5-3 Codabar Concatenation.........5-4 Code 39 ...............5-6 Full ASCII...............5-8 Code 39 Code Page ..........5-9 Interleaved 2 of 5............5-10 NEC 2 of 5 ..............5-11 Code 93 ..............5-13 Code 93 Code Page ..........5-14 Straight 2 of 5 Industrial (three-bar start/stop)...5-15...
Page 8 MSI................5-34 GS1 DataBar Omnidirectional........5-36 GS1 DataBar Limited ..........5-36 GS1 DataBar Expanded..........5-37 Codablock A.............. 5-38 Codablock F .............. 5-39 PDF417 ..............5-40 MacroPDF417 ............5-41 MicroPDF417 ............5-41 GS1 Composite Codes ..........5-42 UPC/EAN Version ..........5-42 GS1 Emulation ............
Page 9 Keyboard Function Relationships ....... 6-3 Supported Interface Keys..........6-5 ERB-3209 Elite Reader Product Specifications ..6-6 USB Cable Pinouts............6-8 Chapter 7 - Maintenance Repairs ...............7-1 Maintenance ...............7-1 Cleaning the Device..........7-1 Inspecting Cords and Connectors ......7-1 Replacing Cables............7-1 Replacing an Interface Cable .......7-2 Troubleshooting a ERB-3209 Elite Reader ....7-2...
Page 10: Chapter 1 - Getting Started
If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.
Page 11 The scanner beeps. Verify the scanner operation by scanning a bar code from the Sample Symbols in the back of this manual. The unit defaults to a USB PC Keyboard.
Page 12: Reading Techniques
Reading Techniques The scanner has a view finder that projects a bright red aiming beam that corre- sponds to the scanner’s horizontal field of view. The aiming beam should be centered over the bar code, but it can be positioned in any direction for a good read.
Page 13: Resetting The Factory Defaults
Resetting the Factory Defaults This selection erases all your settings and resets the scanner to the original factory defaults. It also disables all plugins. plugins. If you aren’t sure what programming options are in your scanner, or you’ve changed some options and want to restore the scanner to factory default settings, just scan Activate Defaults bar code.
Page 14: Usb Hid Interface
USB HID Interface Scan the following code to program the scanner for USB HID bar code scan- ners. USB HID Bar Code Scanner...
Page 15: Chapter 2 - Input/Output Settings
Input/Output Settings Power Up Beeper The scanner can be programmed to beep when it’s powered up. Scan the Off bar code(s) if you don’t want a power up beep. Default = Power Up Beeper On - Scanner. Power Up Beeper Off - Scanner * Power Up Beeper On - Scanner...
Page 16: Good Read And Error Indicators
Good Read and Error Indicators Beeper – Good Read The beeper may be programmed On or Off in response to a good read. Turning this option off, only turns off the beeper response to a good read indication. All error and menu beeps are still audible. Default = Beeper - Good Read On.
Page 17: Beeper Pitch - Good Read
Beeper Pitch – Good Read The beeper pitch codes modify the pitch (frequency) of the beep the scan- ner emits on a good read. Default = Medium. Low (1600 Hz) * Medium (2400 Hz) High (4200 Hz) Beeper Pitch – Error The beeper pitch codes modify the pitch (frequency) of the sound the scan- ner emits when there is a bad read or error.
Page 18: Led - Good Read
LED – Good Read The LED indicator can be programmed On or Off in response to a good read. Default = On. * LED - Good Read On LED - Good Read Off Number of Beeps – Good Read The number of beeps of a good read can be programmed from 1 - 9. The same number of beeps will be applied to the beeper and LED in response to a good read.
Page 19: Good Read Delay
Good Read Delay This sets the minimum amount of time before the scanner can read another bar code. Default = 0 ms (No Delay). * No Delay Short Delay (500 ms) Medium Delay (1,000 ms) Long Delay (1,500 ms) User-Specified Good Read Delay If you want to set your own length for the good read delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save.
Page 20: Mobile Phone Read Mode
Mobile Phone Read Mode When this mode is selected, your scanner is optimized to read bar codes from mobile phone or other LED displays. However, the speed of scanning printed bar codes may be slightly lower when this mode is enabled. Hand Held Scanning - Mobile Phone Presentation Scanning -...
Page 21: Presentation Mode
Presentation Mode Presentation Mode uses ambient light to detect bar codes. The LED dims until a bar code is presented to the scanner, then the LED brightens to read the code. If the light level in the room is not high enough, Presentation Mode may not work properly.
Page 22: Presentation Centering
Presentation Centering Use Presentation Centering to narrow the scanner’s field of view when it is in the stand to make sure the scanner reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, Presentation Centering will insure that only the desired codes are read.
Page 23 Scan Presentation Centering On, then scan one of the following bar codes to change the top, bottom, left, or right of the centering window. Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual. Scan Save. Default Presentation Centering = 40% for Top and Left, 60% for Bottom and Right.
Page 24: Reread Delay
Reread Delay This sets the time period before the scanner can read the same bar code a sec- ond time. Setting a reread delay protects against accidental rereads of the same bar code. Longer delays are effective in minimizing accidental rereads. Use shorter delays in applications where repetitive bar code scanning is required.
Page 25: User-Specified Reread Delay
User-Specified Reread Delay If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save. User-Specified Reread Delay 2-10...
Page 26: Centering
Centering Use Centering to narrow the scanner’s field of view to make sure that when the scanner is hand-held, it reads only those bar codes intended by the user. For instance, if multiple codes are placed closely together, centering will insure that only the desired codes are read.
Page 27: No Read
Scan Centering On, then scan one of the following bar codes to change the top, bottom, left, or right of the centering window. Then scan the percent you want to shift the centering window using digits on the inside back cover of this manual.
Page 28: Video Reverse
Video Reverse Video Reverse is used to allow the scanner to read bar codes that are inverted. The Video Reverse Off bar code below is an example of this type of bar code. Scan Video Reverse Only to read only inverted bar codes. Scan Video Reverse and Standard Bar Codes to read both types of codes.
Page 29: Working Orientation
Working Orientation Some bar codes are direction-sensitive. For example, KIX codes and OCR can misread when scanned sideways or upside down. Use the working orientation settings if your direction-sensitive codes will not usually be presented upright to the scanner. Default = Upright. Upright: Vertical, Top to Bottom: (Rotate CW 90°)
Page 30: Chapter 3 - Data Editing
Data Editing Prefix/Suffix Overview When a bar code is scanned, additional information is sent to the host computer along with the bar code data. This group of bar code data and additional, user-defined data is called a “message string.” The selections in this section are used to build the user-defined data into the message string.
Page 31: To Clear One Or All Prefixes Or Suffixes
symbology to which you want to apply the prefix or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”. Step 3. Scan the 2 hex digits from the Programming Chart inside the back cover of this manual or scan 9, 9 for all symbologies. Step 4.
Page 32: To Add A Carriage Return Suffix To All Symbologies
Step 1. Scan the Clear One Prefix or Clear One Suffix symbol. Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in the Symbology Chart) for the symbology from which you want to clear the prefix or suffix. Step 3.
Page 33: Suffix Selections
Suffix Selections Add Suffix Clear One Suffix Clear All Suffixes Function Code Transmit When this selection is enabled and function codes are contained within the scanned data, the scanner transmits the function code to the terminal. Charts of these function codes are provided in Supported Interface Keys.
Page 34: Intercharacter Delay
Intercharacter Delay An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each character of scanned data. Scan the Intercharacter Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.
Page 35: Interfunction Delay
Interfunction Delay An interfunction delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each segment of the message string. Scan the Interfunction Delay bar code below, then scan the num- ber of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.
Page 36: Chapter 4 - Data Formatting
Data Formatting Data Format Editor Introduction You may use the Data Format Editor to change the scanner’s output. For exam- ple, you can use the Data Format Editor to insert characters at certain points in bar code data as it is scanned. The selections in the following pages are used only if you wish to alter the output.
Page 37 you are programming. (See Primary/Alternate Data Formats further information.) Step 3. Terminal Type Refer to Terminal ID Table and locate the Terminal ID number for your PC. Scan three numeric bar codes on the inside back cover to program the scanner for your terminal ID (you must enter 3 digits). For example, scan 0 0 3 for an AT wedge.
Page 38: Other Programming Selections
Other Programming Selections Clear One Data Format This deletes one data format for one symbology. If you are clearing the primary format, scan 0 from the Programming Chart inside the back cover of this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending on the format you are clearing.
Page 39: Data Format Editor Commands
Data Format Editor Commands Send Commands Send all characters F1 Include in the output message all of the characters from the input message, starting from current cursor position, followed by an insert character. Syntax = F1xx where xx stands for the insert character’s hex value for its ASCII code.
Page 40: Move Commands
ASCII code, and xx stands for the insert character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252). Send all but the last characters E9 Include in the output message all but the last “nn” characters, starting from the current cursor position.
Page 41: Miscellaneous Commands
Search backward for a character F9 Search the input message backward for “xx” character from the current cursor position, leaving the cursor pointing to the “xx” character. Syntax = F9xx where xx stands for the search character’s hex value for its ASCII code.
Page 42: Data Formatter
Stop replacing characters E5 Terminates character replacement. Syntax = E5. Compare characters FE Compare the character in the current cursor position to the character “xx.” If characters are equal, move the cursor forward one position. Syntax = FExx where xx stands for the comparison character’s hex value for its ASCII code.
Page 43: Primary/Alternate Data Formats
Default = Data Formatter On, Not Required, Keep Prefix/Suffix. * Data Formatter On, Not Required, Keep Prefix/Suffix Data Format Required, Keep Prefix/Suffix Primary/Alternate Data Formats You can save up to four data formats, and switch between these formats. Your primary data format is saved under 0. Your other three formats are saved under 1, 2, and 3.
Page 44 Symbologies • All Symbologies • Interleaved 2 of 5 • Aztec Code • Korea Post • China Post (Hong Kong 2 of 5) • Matrix 2 of 5 • Chinese Sensible (Han Xin) Code • MicroPDF417 • Codabar • MSI •...
Page 45: All Symbologies
All Symbologies If you want to decode all the symbologies allowable for your scanner, scan the All Symbologies On code. If on the other hand, you want to decode only a particular symbology, scan All Symbologies Off followed by the On symbol for that particular symbology.
Page 46: Codabar
Codabar <Default All Codabar Settings> Codabar On/Off * On Codabar Start/Stop Characters Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters. Default = Don’t Transmit . Transmit * Don’t Transmit Codabar Check Character Codabar check characters are created using different “modulos.”...
Page 47: Codabar Concatenation
When Check Character is set to Validate, but Don’t Transmit , the unit will only read Codabar bar codes printed with a check character, but will not transmit the check character with the scanned data. * No Check Character Validate Modulo 16, but Don’t Transmit Validate Modulo 16 and Transmit...
Page 48: Codabar Message Length
Codabar Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Mini-mum and Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = Minimum Message Length Maximum Message Length...
Page 49: Code 39
Code 39 < Default All Code 39 Settings > Code 39 On/Off * On Code 39 Start/Stop Characters Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters. Default = Don’t Transmit.
Page 50: Code 39 Message Length
When Check Character is set to Validate and Transmit, the scanner only reads Code 39 bar codes printed with a check character, and will transmit this character at the end of the scanned data. Default = No Check Charac- ter. * No Check Character Validate, but Don’t Transmit Validate and Transmit...
Page 51: Full Ascii
acter(s), it buffers Code 39 bar codes until it reads a Code 39 bar code that does not have the append trigger. The data is then transmitted in the order in which the bar codes were read (FIFO). Default = Off. * Off Full ASCII If Full ASCII Code 39 decoding is enabled, certain character pairs within...
Page 52: Code 39 Code Page
Character pairs /M and /N decode as a minus sign and period respectively. Character pairs /P through /Y decode as 0 through 9. Full ASCII On * Full ASCII Off Code 39 Code Page Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting.
Page 53: Interleaved 2 Of 5
Interleaved 2 of 5 < Default All Interleaved 2 of 5 Settings > Interleaved 2 of 5 On/Off * On Check Digit No Check Digit indicates that the scanner reads and transmits bar code data with or without a check digit. When Check Digit is set to Validate, but Don’t Transmit, the unit only reads Interleaved 2 of 5 bar codes printed with a check digit, but will not transmit the check digit with the scanned data.
Page 54: Interleaved 2 Of 5 Message Length
Interleaved 2 of 5 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = Minimum Message Length Maximum Message Length NEC 2 of 5 <...
Page 55 When Check Digit is set to Validate and Transmit, the scanner only reads NEC 2 of 5 bar codes printed with a check digit, and will transmit this digit at the end of the scanned data. Default = No Check Digit. * No Check Digit Validate, but Don’t Transmit Validate and Transmit...
Page 56: Code 93
Code 93 < Default All Code 93 Settings > Code 93 On/Off * On Code 93 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = Minimum Message Length Maximum Message Length Code 93 Append...
Page 57: Code 93 Code Page
which the bar codes are read, deleting the first space from each. The scanner transmits the appended data when it reads a Code 93 bar code that starts with a character other than a space. Default = Off. * Off Code 93 Code Page Code pages define the mapping of character codes to characters.
Page 58: Straight 2 Of 5 Industrial (Three-Bar Start/Stop)
Straight 2 of 5 Industrial (three-bar start/stop) <Default All Straight 2 of 5 Industrial Settings> Straight 2 of 5 Industrial On/Off * Off Straight 2 of 5 Industrial Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information.
Page 59: Straight 2 Of 5 Iata (Two-Bar Start/Stop)
Straight 2 of 5 IATA (two-bar start/stop) <Default All Straight 2 of 5 IATA Settings> Straight 2 of 5 IATA On/Off * Off Straight 2 of 5 IATA Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information.
Page 60: Matrix 2 Of 5
Matrix 2 of 5 <Default All Matrix 2 of 5 Settings> Matrix 2 of 5 On/Off * Off Matrix 2 of 5 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-80.
Page 61: Code 128
Code 128 <Default All Code 128 Settings> Code 128 On/Off * On ISBT 128 Concatenation In 1994 the International Society of Blood Transfusion (ISBT) ratified a standard for communicating critical blood information in a uniform manner. The use of ISBT formats requires a paid license. The ISBT 128 Application Specification describes 1) the critical data elements for labeling blood prod- ucts, 2) the current recommendation to use Code 128 due to its high degree of security and its space-efficient design, 3) a variation of Code 128...
Page 62: Code 128 Code Page
Code 128 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = Minimum Message Length Maximum Message Length Code 128 Append This function allows the scanner to append the data from several Code 128 bar codes together before transmitting them to the host computer.
Page 63: Gs1-128
GS1-128 <Default All GS1-128 Settings> GS1-128 On/Off * On GS1-128 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-80. Minimum Default = 1, Maximum Default = Minimum Message Length Maximum Message Length 5-20...
Page 64: Telepen
Telepen <Default All Telepen Settings> Telepen On/Off * Off Telepen Output Using AIM Telepen Output, the scanner reads symbols with start/stop pat- tern 1 and decodes them as standard full ASCII (start/stop pattern 1). When Original Telepen Output is selected, the scanner reads symbols with start/stop pattern 1 and decodes them as compressed numeric with optional full ASCII (start/stop pattern 2).
Page 65: Upc-A
Telepen Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-60. Minimum Default = 1, Maximum Default = Minimum Message Length Maximum Message Length UPC-A <Default All UPC-A Settings>...
Page 66 UPC-A Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not. Default = On . * On UPC-A Number System The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it.
Page 67: Upc-A/Ean-13
UPC-A Addenda Required When Required is scanned, the scanner will only read UPC-A bar codes that have addenda. You must then turn on a 2 or 5 digit addenda listed Addenda. Default = Not Required. UPC-A Required * Not Required UPC-A Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda.
Page 68: Coupon Gs1 Databar Output
Default = Off. * Off Allow Concatenation Require Concatenation Coupon GS1 DataBar Output If you scan coupons that have both UPC and GS1 DataBar codes, you may wish to scan and output only the data from the GS1 DataBar code. Scan the GS1 Output On code below to scan and output only the GS1 DataBar code data.
Page 69: Upc-E
UPC-E <Default All UPC-E Settings> UPC-E On/Off Most U.P.C. bar codes lead with the 0 number system. To read these codes, use the UPC-E On selection. * On UPC-E Expand UPC-E Expand expands the UPC-E code to the 12 digit, UPC-A format. Default = Off.
Page 70 UPC-E Addenda Required When Required is scanned, the scanner will only read UPC-E bar codes that have addenda. Default = Not Required. Required * Not Required UPC-E Addenda Separator When this feature is On, there is a space between the data from the bar code and the data from the addenda.
Page 71 UPC-E Number System The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. To prevent transmission, scan Off. Default = On. * On UPC-E Addenda This selection adds 2 or 5 digits to the end of all scanned UPC-E data.
Page 72: Ean-13
EAN-13 <Default All EAN -13 Settings> EAN-13 On/Off * On Note: If you want to convert UPC-A bar codes to EAN-13 format, scan the UPC- A Off bar code on UPC-A On/Off 5-299...
Page 73 EAN-13 Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not. Default = On. * On EAN-13 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN-13 data.
Page 74: Isbn Translate
EAN-13 Addenda Separator When this feature is On, there is a space between the data from the bar code and the data from the addenda. When turned Off, there is no space. Default = On. * On Note: If you want to enable or disable EAN13 with Extended Coupon Code, refer to UPC-A/EAN-13 with Extended Coupon Code.
Page 75: Ean-8
EAN-8 <Default All EAN-8 Settings> EAN-8 On/Off * On EAN-8 Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not. Default = On. * On 5-32...
Page 76 EAN-8 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN-8 data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On * 2 Digit Addenda Off 5 Digit Addenda On * 5 Digit Addenda Off EAN-8 Addenda Required When Required is scanned, the scanner will only read EAN-8 bar...
Page 77: Msi
<Default All MSI Settings> MSI On/Off * Off MSI Check Character Different types of check characters are used with MSI bar codes. You can program the scanner to read MSI bar codes with Type 10 check charac- ters. Default = Validate Type 10, but Don’t Transmit. When Check Character is set to Validate Type 10/11 and Transmit, the scanner will only read MSI bar codes printed with the specified type check character(s), and will transmit the character(s) at the end of the scanned...
Page 78: Msi Message Length
When Check Character is set to Validate Type 10/11, but Don’t Transmit, the unit will only read MSI bar codes printed with the specified type check character(s), but will not transmit the check character(s) with the scanned data. * Validate Type 10, but Don’t Transmit Validate Type 10 and Transmit Validate 2 Type 10 Characters,...
Page 79: Gs1 Databar Omnidirectional
GS1 DataBar Omnidirectional < Default All GS1 DataBar Omnidirectional Settings > GS1 DataBar Omnidirectional On/Off * On GS1 DataBar Limited < Default All GS1 DataBar Limited Settings > GS1 DataBar Limited On/Off * On 5-36...
Page 80: Gs1 Databar Expanded
GS1 DataBar Expanded < Default All GS1 DataBar Expanded Settings > GS1 DataBar Expanded On/Off * On GS1 DataBar Expanded Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 4-74.
Page 81: Codablock A
Codablock A <Default All Codablock A Settings> Codablock A On/Off * Off Codablock A Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-600. Minimum Default = 1, Maximum Default = 600.
Page 82: Codablock F
Codablock F <Default All Codablock F Settings> Codablock F On/Off * Off Codablock F Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-2048. Minimum Default = 1, Maximum Default = 2048.
Page 83: Pdf417
PDF417 < Default All PDF417 Settings > PDF417 On/Off * On PDF417 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-2750. Minimum Default = 1, Maximum Default = 2750.
Page 84: Macropdf417
MacroPDF417 MacroPDF417 is an implementation of PDF417 capable of encoding very large amounts of data into multiple PDF417 bar codes. When this selection is enabled, these multiple bar codes are assembled into a single data string. Default = On. * On MicroPDF417 <...
Page 85: Gs1 Composite Codes
MicroPDF417 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-366. Minimum Default = 1, Maximum Default = 366. Minimum Message Length Maximum Message Length GS1 Composite Codes Linear codes are combined with a unique 2D composite component to form a new class called GS1 Composite symbology.
Page 86: Gs1 Emulation
GS1 Composite Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-2435. Minimum Default = 1, Maximum Default = 2435. Minimum Message Length Maximum Message Length GS1 Emulation The scanner can automatically format the output from any GS1 data carrier to...
Page 87: Tcif Linked Code 39 (Tlc39)
Default = GS1 Emulation Off . GS1-128 Emulation GS1 DataBar Emulation GS1 Code Expansion Off EAN8 to EAN13 Conversion * GS1 Emulation Off TCIF Linked Code 39 (TLC39) This code is a composite code since it has a Code 39 linear component and a MicroPDF417 stacked code component.
Page 88: Qr Code
QR Code < Default All QR Code Settings > QR Code On/Off This selection applies to both QR Code and Micro QR Code. * On QR Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information.
Page 89: Qr Code Page
information encoded in those bar codes. Once the proper number of codes is reached, the data is output in the order specified in the bar codes. Default = On. * On QR Code Page QR Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting.
Page 90: Data Matrix
Data Matrix < Default All Data Matrix Settings > Data Matrix On/Off * On Data Matrix Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-3116. Minimum Default = 1, Maximum Default = 3116.
Page 91: Data Matrix Code Page
mined by information encoded in those bar codes. Once the proper num- ber of codes is reached, the data is output in the order specified in the bar codes. Default = On. * On Data Matrix Code Page Data Matrix Code pages define the mapping of character codes to charac- ters.
Page 92: Aztec Code
Aztec Code < Default All Aztec Code Settings > Aztec Code On/Off * On Aztec Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-3832. Minimum Default = 1, Maximum Default = 3832.
Page 93: Aztec Code Page
ter(s), it buffers the number of Aztec bar codes determined by information encoded in those bar codes. Once the proper number of codes is reached, the data is output in the order specified in the bar codes. Default = Off. * Off Aztec Code Page Aztec Code pages define the mapping of character codes to characters.
Page 94: Chinese Sensible (Han Xin) Code
Chinese Sensible (Han Xin) Code < Default All Han Xin Settings > Han Xin Code On/Off * Off Han Xin Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 1-7833.
Page 95 China Post (Hong Kong 2 of 5) On/Off * Off China Post (Hong Kong 2 of 5) Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maxi-mum Default = 80.
Page 96: Korea Post
Korea Post <Default All Korea Post Settings> Korea Post * Off Korea Post Message Length Scan the bar codes below to change the message length. Refer to Message Length Description for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maxi-mum Default = 48.
Page 97: Chapter 6 - Utilities
Utilities To Add a Test Code I.D. Prefix to All Symbologies This selection allows you to turn on transmission of a Code I.D. before the decoded symbology. (See the Symbology Chart) for the single character code that identifies each symbology.) This action first clears all current prefixes, then programs a Code I.D.
Page 98: Show Data Format
Show Data Format Scan the bar code below to show current data format settings. DFMBK3?. Data Format Settings Test Menu When you scan the Test Menu On code, then scan a programming code in this manual, the scanner displays the content of a programming code. The pro- gramming function will still occur, but in addition, the content of that program- ming code is output to the terminal.
Page 99: Keyboard Function Relationships
Keyboard Function Relationships The following Keyboard Function Code, Hex/ASCII Value, and Full ASCII “CTRL”+ relationships apply to all terminals that can be used with the scanner. Function Code HEX/ASCII Value Full ASCII “CTRL” +...
Page 100 The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ), apply to US only. The following chart indicates the equivalents of these five characters for different countries. Country Codes United States Belgium < Scandinavia <...
Page 101: Supported Interface Keys
Supported Interface Keys IBM PC/AT and Compatibles, Apple Mac/iMac ASCII USB PC Supported Keys Keyboard Reserved Reserved Enter (KP) Enter/Numpad Enter Cap Lock CAPS ALT make ALT make ALT break ALT break CTRL make CNTRL make CTRL break CNTRL break CR/Enter RETURN Reserved...
Page 102 ERB-3209 Scanner Product Specifications Parameter Specification Mechanical Height 3.35 inches (85mm) Length 6.7 inches (170mm) Width 2.6 inches (66mm) Weight 4.2 ounces (119g) Electrical Input Voltage 4 to 5.5VDC Operating Power 2W; 400 mA (typical) @ 5VDC Standby Power .45W; 90 mA (typical) @ 5VDC...
Page 103 Parameter Specification 6.7 mil PDF417 25mm - 90mm (0.99 - 3.54 in.) 10mil Data Matrix 25mm - 95mm (0.99 - 3.74 in.) 20mil QR Code 15mm~ - 195mm (0.59 - 7.67 in.) Guaranteed Performance 5 mil Code 39 50mm - 84mm (1.97 - 3.3 in.) 13 mil UPC-A 34mm - 200mm (1.34 - 7.87 in.)
Page 104: Usb Cable Pinouts
Serial Output 10 Pin RJ41 Modular Plug - connects to the base Cable shield Cable select Supply ground Transmit data Receive data - serial data to scanner +5V power USB Cable Pinouts...
Page 105: Chapter 7 - Maintenance
Maintenance Repairs Repairs and/or upgrades are not to be performed on this product. These ser- vices are to be performed only by an authorized service center (see Customer Support). Maintenance Your device provides reliable and efficient operation with a minimum of care. Although specific maintenance is not required, the following periodic checks ensure dependable operation: Cleaning the Device...
Page 106: Replacing An Interface Cable
• Order replacement cables from aidcti or from an authorized distributor. • When ordering a replacement cable, specify the cable part number of the original interface cable. Replacing an Interface Cable 1. Turn the power to the host system OFF.
Page 107 • You need to program a suffix. Programming a suffix enables the scanner to output the bar code data plus the key you need (such as “CR”) to enter the data into your application. Refer to Prefix/Suffix Overview beginning on page 4-1 for further information. Does the scanner read the bar code incorrectly? If the scanner reads a bar code, but the data is not displayed correctly on the host screen:...
Page 108: Chapter 8 - Customer Support
This warranty shall extend from the time of shipment for the duration published by aidcti for the product at the time of purchase ("Warranty Period"). Any defective product must be returned (at purchaser’s expense) during the Warranty Period to aidcti factory or authorized service center for inspection.
Page 109 UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT WITH NEW OR REFURBISHED PARTS. IN NO EVENT SHALL AIDCTI BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSE-QUENTIAL DAMAGES, AND, IN NO EVENT, SHALL ANY LIABILITY OF AIDCTI ARISING IN CONNECTION WITH ANY PRODUCT...
Page 110: Appendix A - Reference Charts
Reference Charts Symbology Chart Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) All Symbologies (0x99) Australian Post A (0x41) ]z m Aztec Code 0-9, A-C z (0x7A) Batch Mode Quantity 5 (0x35) British Post B (0x42) Canadian Post C (0x43) China Post...
Page 111 Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) EAN-8 with Add-On D (0x44) GS1 Composite ]e m y (0x79) GS1 DataBar ]e m y (0x79) GS1 DataBar Limited ]e m { (0x7B) ]e m GS1 DataBar Omnidirectional y (0x79) ]e m GS1 DataBar Expanded...
Page 112 Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) TCIF Linked Code 39 (TLC39) T (0x54) Telepen ]B m t (0x54) UPC-A c (0x63) UPC-A with Add-On c (0x63) UPC-A with Extended c (0x63) Coupon Code UPC-E E (0x45) UPC-E with Add-On...
Page 113: Ascii Conversion Chart (Code Page 1252
ASCII Conversion Chart (Code Page 1252 Note: This table applies to U.S. style keyboards. Certain characters may differ depending on your Country Code/PC regional settings. Non-Printable Characters DEC HEX Character (Code) DEC HEX Character (Code) NULL DATA LINK ESCAPE (DLE) START OF HEADING DEVICE CONTROL 1 (DC1) (SOH)
Page 114 Printable Characters (Continued) DEC HEX Character DEC HEX Character DEC HEX Character < > <DEL> Extended ASCII Characters DEC HEX Character DEC HEX Character DEC HEX Character € € « Ö ¬ × ‚ Ø ƒ ® Ù „ ¯ Ú...
Page 115: Code Page Mapping Of Printed Bar Codes
Extended ASCII Characters (Continued) DEC HEX Character DEC HEX Character DEC HEX Character Œ · â ¸ ã Ž ¹ ä º å » æ ‘ ¼ ç ’ ½ è “ ¾ é ” ¿ ê • À ë –...
Page 116: Sample Symbols
Sample Symbols UPC-A Interleaved 2 of 5 0 123456 7890 1234567890 Code 128 EAN-13 Code 128 Code 39 9 780330 290951 Codabar BC321 Code 93 A13579B Straight 2 of 5 Industrial 123456-9$ 123456...
Page 117 Sample Symbols Matrix 2 of 5 6543210 GS1 DataBar PDF417 (01)00123456789012 Car Registration Data Matrix QR Code Test Symbol Numbers 4-CB (4-State Customer Bar Code) 01,234,567094,987654321,01234567891 ID-tag (UPU 4-State) J18CUSA8E6N062315014880T...
Page 118 Sample Symbols Aztec Micro PDF417 Package Label MaxiCode Test Message Test Message Postnet Zip Code...
Page 119: Programming Chart
Programming Chart...
Page 120 Programming Chart Save Discard Reset Note: If you make an error while scanning the letters or digits (before scanning Save), scan Discard, scan the correct letters or digits, and Save again.
Page 121 Auto Identify Data Collect Technology Inc. 337 N Vineyard Ave Ontario CA 91764 ERB3209-UM Rev B 01/15...

Aidcti ERB-3209 User Manual

Chapter 1 - Getting Started

Chapter 2 - Input/Output Settings

Chapter 3 - Data Editing

Chapter 4 - Data Formatting

Chapter 5 - Symbologies

Chapter 6 - Utilities

Chapter 7 - Maintenance

Chapter 8 - Customer Support

Appendix A - Reference Charts

Quick Links

Need help?

Questions and answers

Related Manuals for Aidcti ERB-3209

Summary of Contents for Aidcti ERB-3209

Table of Contents
