Aidcti ERB-2109 User Manual

Elite bluetooth 2d bar code reader
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ERB-2109
Elite Bluetooth 2D Bar code Reader
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ERB-2109 and is the answer not in the manual?

Questions and answers

Related Manuals for Aidcti ERB-2109

Summary of Contents for Aidcti ERB-2109

  • Page 1 ERB-2109 Elite Bluetooth 2D Bar code Reader User’s Manual...
  • Page 2 No right to copy a licensed program in whole or in part has granted, except as permitted under copyright law. The user shall not modify, merge, or incorporate any form or portion of a licensed program with other program material, create a derivative work from a licensed program, or use a licensed program in a network without written permission from aidcti.

  • Page 3: Hardware Instruction

    Scan Button Battery Status LED Scanner Status LED Bluetooth / Sleep Status LED Scanner Window Buzzer Non-Slip Protective Material Protective Cover USB / Bluetooth Switch Battery Switch Mini USB Connector Hand Strap Holes Standard Threaded Socket for Tripod ERB-2109 aidcti.com...

  • Page 4: Scan Button

    USB cable plug in and the power supply is normal. Green Flash Light means Charging Now Green Solid Light means Full Charged Battery Switch Off: The Light of Power is Off. The battery is not working and charging ERB-2109 aidcti.com...

  • Page 5: Bluetooth Status Led

    Switch to USB Mode Blue Light Off While charging under Sleeping Mode, press trigger once to show the charging indicator correctly. Disconnected or No Signal - Blue Light flashing slowly Wait for pairing with the Host - Blue Light flashing rapidly aidcti.com ERB-2109...

  • Page 6: Scanner Window

    Protect the USB connector and switches to avoid the dust intake. USB / Bluetooth Switch The switch to toggle USB or Bluetooth Mode. Please use the sharp part at the backside of the Protective Cover to toggle the pin. aidcti.com ERB-2109...
  • Page 7 *It is only available for the mobile devices which supply the power to the OTG and switch the power Off Hand Strap Holes Standard Threaded Socket for Tripod The Auto-Sensing Mode is available for the scanner When this function is activating. the scanner can be attached to a standard camera tripod. ERB-2109 aidcti.com...

  • Page 8: Package Contents

    Package Contents Scanner User’s Manual USB Cable OTG Cable Hand Strap aidcti.com ERB-2109...
  • Page 9 Charging Open cover and slide the switch Battery on. While ERB-2109 is charging, no matter the switch slided to Bluetooth or USB, it keeps working. Connect this scanner and a computer with USB cable. When the Green light turns solid, it is full charged.

  • Page 10: Install Hand Strap

    • Under Bluetooth Mode: Power might be not enough. • Under USB Mode: The cable might be not connected or loose. • Under USB Mode: The power of Host is not enough. Please remove to another USB port. ERB-2109 aidcti.com...

  • Page 11: Mode Overview

    Sleeping Mode: Slide switches on Battery and Bluetooth. If the scanner keeps no Scan Button pressed within the setting time, it gets into Sleeping Mode. Each mode is available to match with the tripod if Auto-Sensing is Enable. ERB-2109 aidcti.com...
  • Page 12 This means slide the switch to USB. This means cautions. Back View Top View All LED Off: • The Power of Battery is off and the scanner does not connect with USB cable. • The Power of Battery is on but out of power. aidcti.com ERB-2109...

  • Page 13: Scan Barcode

    Barcode can not scan if the Green Aiming Light deviates center of the bar code. Adjust the position and aiming the Green light on the center of the barcode. Scan width barcode with longer distance and scan narrow barcode in short distance. Adjust the position while the Green aiming light is turning on. ERB-2109 aidcti.com...

  • Page 14: Reading Mode

    Upper Case / Lower Case No Conversion *All Upper Case All Lower Case 1103040 1103041 1103042 Terminator None 0309000 0310000-0D 0310000-0A *CRLF Space 0310000-0D0A 0310000-09 0310000-20 Reading Mode *Trigger Auto-Sensing 0302000 0302010 Auto-Sensing Sensitivity Enhanced High *Normal 0312040-5 0312040-8 0312040-11 0312040-14 ERB-2109 aidcti.com...

  • Page 15: Power Indicator

    *Off 0200020 0200030 Good Read Response *Beep Beep and vibrating 2100010 2100020 The function is available if the vibrator optioned from the factory. Time to Sleep *1 Min. 3 Min. 5 Min. 10 Min. 2300040-1 2300040-3 2300040-5 2300040-10 aidcti.com ERB-2109...

  • Page 16: Android Pairing

    Android Pairing Toggle the switch on ERB-2109 to Bluetooth mode. • Tap the on mobile devices with Android. • Swipe Bluetooth to enable Bluetooth. • Press and hold the Scan Button for 10 seconds until Bluetooth LED flashing rapidly. • Tap SEARCH FOR DEVICES on your mobile device.
  • Page 17 • Tap Google Docs • On-screen keyboard does not appear when ERB-2109 has connected. • Meanwhile, there is one small keyboard icon shown on the left corner of the screen for selecting input methods.
  • Page 18 ERB-2109 paired. • Tap Unpair • Only press and hold the Scan Button on ERB-2109 for 10 seconds and the Bluetooth LED is flashing rapidly; then it has unpaired. • Meanwhile, it could pair with the other device or switch to USB mode without pair.

  • Page 19: Ios Pairing

    Pairing Toggle the switch on ERB-2109 to Bluetooth mode. Tap the icon on mobile devices with iOS. Swipe Bluetooth to enable Bluetooth. System starts to search Bluetooth device. Press and hold the Scan Button for 10 seconds until One Spot Pairing Bluetooth LED flashing rapidly (One Spot Pairing).
  • Page 20 Toggle Keyboard When ERB-2109 has paired, on-screen keyboard disappears as iOS treats ERB-2109 a physical keyboard. Tap in on the mobile device. There is no on-screen keyboard. Double click Scan Button on ERB-2109, on-screen keyboard appears. Double click Scan Button again, on-screen keyboard is hidden.
  • Page 21 Select Forget This Device then the system asks if it is sure. Press OK to unpair this device. Only press and hold the Scan Button on ERB-2109 for 10 seconds and the Bluetooth LED is flashing rapidly; then it has unpaired.
  • Page 22 Windows 8 Pairing Toggle the switch on ERB-2109 to Bluetooth mode. Select Change PC setting then swipe Bluetooth On Click or tap Add a device on this computer. One Spot Pairing Press and hold the Scan Button for 10 seconds until Bluetooth LED flashing rapidly (One Spot Pairing).
  • Page 23 Select Yes to remove ERB-2109. Only press and hold the Scan Button on ERB-2109 for 10 seconds and the Bluetooth LED is flashing rapidly; then it has unpaired. Meanwhile, it could pair with the other device or switch to USB mode without pair.
  • Page 24 Windows 7 Pairing Toggle the switch on ERB-2109 to Bluetooth mode. • Make sure the computer or laptop you have built in Bluetooth or connected with Bluetooth Enabled Device. • Click Show hidden icons on the right bottom corner and then click Bluetooth icon.
  • Page 25 • Wait until ERB-2109 shown on the computer, and then select ERB-2109. • Waiting seconds; then the Blue LED is solid, and ERB-2109 beeps twice to indicate it has paired with this computer. The screen of it displayed Connected. • Now ERB-2109 is ready to use.
  • Page 26 • Click Show hidden icons on the right bottom corner and then tap Bluetooth icon. • Click Show Bluetooth Devices. • Select ERB-2109 connected and click Remove device. • The system asks, "Are you sure you want to remove this device?" Select Yes to remove ERB-2109.

  • Page 27: Intercharacter Delay

    Wake Up To wake ERB-2109, just press the Scan Button once. While it is waking, Red light is flashing to warm up. Red light off means warm up already. Solid Blue light means Bluetooth connected successfully. ERB-2109 is ready to use.
  • Page 28 If the battery is fully charged or given up to charge, slide Battery switch off. USB HID is still available. Caution: It is not available to set up bar code under USB HID mode. ERB-2109 must switch to Bluetooth mode to set up. ERB-2109...
  • Page 29 Mini USB Micro SUB Caution: It is not available to set up bar code under USB HID mode. ERB-2109 must switch to Bluetooth mode to set up. If OTG function is not available to this mobile device, this function can not work.

  • Page 30: Memory Mode

    • If you want to remove the data stored under Memory Mode, please read the bar code for getting into Memory Mode again. • The data stored in ERB-2109 only can transfer via reading the setting bar code after exiting Memory Mode. Data stored in ERB-2109 can transmit with unlimited times and at any time.
  • Page 31 Memory Mode Red light solid - When ERB-2109 gets into Memory Mode, the Red light is solid. When the bar code scans and stores in memory, the Red light is off once and on coming after one beep (opposite with non-memory mode)

  • Page 32: Auto-Sensing

    The scanning mode is below: *Trigger Auto-Sensing 0302000 0302010 Auto-Sensing Sensitivity ERB-2109 is auto-sensing the light changed under Auto-Sensing Mode. Adjust the sensitivity to make auto-sensing smoother. Adjust the sensitivity to be stronger when the ambient light becomes weak. Enhanced High *Normal...
  • Page 33 No Send Check Digit *No Add 2 0401070 0401010 0401030 0401050 EAN-13 Add 5 *Enable *Send Check Digit Add 2 0402070 0402020 0402040 0402050 *No Add 5 Disable No Send Check Digit *No Add 2 0402080 0402010 0402030 0402060 ERB-2109 aidcti.com...

  • Page 34: Interleaved 2 Of 5

    No Send Check Digit *No Send 0 *No Add 2 *No Add 5 0404010 0404030 0404090 0404050 0404070 Interleaved 2 of 5 *Enable Disable Check Digit And Send *No Check Digit 0405020 0405010 0405070 0405050 Min. Length=6 / Max. Length=80 ERB-2109 aidcti.com...
  • Page 35 Full ASCII 0408010 0408050 0408110 Min. Length=1 / Max. Length=48 Codabar *Enable Disable 0409020 0409010 Min. Length=2 / Max. Length=60 Code-93 Enable Check Digit And Send 0410020 0410070 *Disable *No Check Digit 0410010 0410050 Min. Length=1 / Max. Length=48 ERB-2109 aidcti.com...

  • Page 36: Gs1 Databar

    *Send AI(01) No Send AI(01) 0413020 0413010 0413060 0413050 Code 11 *Check Digit Check Digit (Mod 11) (Mod 11/11) Enable *Disable 0415020 0415010 0415060 0415070 Check Digit (Mod 11/9) No Check Digit 0415080 0415050 Min. Length=4 / Max. Length=48 ERB-2109 aidcti.com...

  • Page 37: Industrial 2 Of 5

    Check Digit And Send *No Check Digit 0417020 0417010 0417070 0417050 Min. Length=6 / Max. Length=48 Standard 2 of 5 Enable *Disable Check Digit And Send *No Check Digit 0418020 0418010 0418070 0418050 Min. Length=6 / Max. Length=48 ERB-2109 aidcti.com...
  • Page 38 *Disable 0419020 0419010 0419050 0419070 Min. Length=4 / Max. Length=48 *Disable Enable 0420010 0420020 No Check Digit *Check Digit Mod 10 Check Digit Mod 10/10 Check Digit Mod 10/11 0420050 0420060 0420070 0420080 Min. Length=4 / Max. Length=48 ERB-2109 aidcti.com...

  • Page 39: Data Matrix

    Disable 0502020 0502010 Min. Length=1 / Max. Length=7089 Aztec Enable *Disable *Mode 1 Mode 2 Mode 3 0503020 0503010 0503070 0503080 0503090 Min. Length=1 / Max. Length=3832 Data Matrix Disable *Enable 0504010 0504020 Min. Length=1 / Max. Length=3116 ERB-2109 aidcti.com...

  • Page 40: Hardware Tools

    0505020 Min. Length=1 / Max. Length=150 OCR-B (7 space 2) Enable *Disable 0600020 0600010 you can download OCR-B (7 space 2) TrueType font from aidcti.com web site Hardware Tools Reset To All Default Firmware Version Serial Number 2000200 2000300 0001160-2000100 ERB-2109 aidcti.com...
  • Page 41 Aztec PDF417 This is PDF417 test bar code This is Aztec test bar code Data Matrix OCR-B (7 Space 2) Ó 5 8 6 4 7 8 2 5 2 Ó This is Data Matrix test bar code ERB-2109 aidcti.com...
  • Page 42 Two Year limited warranty *3 Warranty *1 One Scan Per Second, Red Illumination On, Vibrator Off, Trigger Mode *2 OCR-B 7 Space 2 Type *3 Available in the North America and EU territories. Elsewhere 1 year limited warranty ERB-2109 aidcti.com...

  • Page 43: Fcc Rf Exposure Statement

    FCC Class B Part 15 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 44 Visit official site for this manual download and live settings www.aidcti.com Elite Reader PN: EDM88511-04 Rev A1.05.10...
