Road View RV-300HD User Manual

Smart hd
Hide thumbs
Table of Contents

Advertisement

Quick Links

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RV-300HD and is the answer not in the manual?

Questions and answers

Related Manuals for Road View RV-300HD

Summary of Contents for Road View RV-300HD

  • Page 2: Table Of Contents

    Table of Contents What's in the Box Assembling/Disassembling Main Unit and Mount Parts Features and Instructions Cautions for Installation and Use Viewer Main Unit Installation Product Specifications...
  • Page 3 Safety Warnings Cautions The following contains important information for ensuring safety of the user and preventing potential damage or inconvenience due to improper use. Please read the following warnings and cautions thoroughly before using the product. T he safety warnings and cautions are categorized as below, depending on the level of potential risks and damages that may result from improper use. Failure to follow safety warnings may lead to serious injury or death. Warnings Failure to follow cautions may lead to injury or property damages.
  • Page 4 Safety Warnings Cautions Warnings Do not disassemble, or modify the product on your own or Before installing the product, make sure that the vehicle's install the product in a way other than intended. ignition is turned off. Improper installation, disassembly, or modification of the Installing the product while the ignition is on may result in product may cause product to malfunction. Such malfunctions electric shock or accident. are not covered under product warranty. Do not operate the product while driving.
  • Page 5 Warnings Maintain the appropriate temperature (0°C to 50°C) during use. Do not place water, beverages, chemicals, or other potentially Operating the product beyond this temperature range may harmful items near the product. It may damage the product or cause malfunctions. lower the product’s performance and/or damage the hardware. When installing the product, make sure it does not interfere Do not apply heat to the product using a furnace, microwave, with the operation of other onboard devices, such as airbags. or hair drier. Failure to do so may interrupt proper operation of such devices It may cause explosions, deformations, or defects.
  • Page 6 Cautions Keep the camera lens clean at all times. Avoid strong impact to the product. Failure to keep the camera lens clean may lower quality of It may damage the product or cause malfunctions. recordings. Be careful when you touch this product while in use. The heat generated from the product may cause burn injuries. Using the product in a vehicle with a tinted windshield may alter Prolonged continuous use of this product may generate heat the video recording. and cause burn injuries. Dramatic changes in the surroundings such as brightness or Event Recording may not be initiated if external impact is not backlight may degrade video recording quality.
  • Page 7 Cautions Check the condition of the product and recording quality on regular basis. Do not place the product near a magnet or areas with strong Make sure that the Micro SD card inserted in the product is magnetic fields. It may damage the product or cause malfunctions. working properly. If any problems are found, stop using the product and contact Customer Support. This product supports Micro SDHC cards (4 to 32 GB, class 6 To install a the product to a constant power source of your or higher).
  • Page 8 Micro SD card is an essential part. Please read the following instructions carefully. The manufacturer will not take any liability concerning loss of data or damage to Micro SD card. Please use only genuine Micro SD card provided by the Always check the correct side of the Micro SD card when manufacturer. inserting, and insert it all the way. Use of third-party Micro SD cards may cause data loss or If the Micro SD card is not inserted correctly, it may cause the damage the product.
  • Page 9 Features Highest resolution Smart HD video Set operating voltage of the black recording in its class box through battery voltage checks * Settings can be adjusted under the Settings in the Viewer program. 2-channel front and rear recording Support for multiple Parking Recording Modes (Parking Recording, Event, Motion Detection, etc...) Intuitive and simple external interface Anti-battery drain circuit design...

  • Page 10: What's In The Box

    What's in the Box The parts included in your package may not look identical with the following fi gures. And some parts can be changed without notice. Sold separately Constant power Main Unit User's manual Micro SD card cable GPS module Power port cable Micro SD card AV - OUT cable...

  • Page 11: Parts

    Parts Vehicle Mount For installing on a glass Camera Lens 2.0M Camera Security LED LED indicator for security features (blue) Menu Button MIC On/Off and Micro SD card formatting Reset Restart button Microphone Records audio Manual Turns manual recording and speaker On/Off Recording Button Rec LED Indicates recording status...
  • Page 12 AV - OUT Outputs video to external devices connector Micro SD card Slot for inserting Micro SD card slot AV-IN input For connecting rear camera connector GPS connector For connecting an external GPS antenna Power For connecting power cable Connector * The figures shown in this manual may vary from the actual product.

  • Page 13: Cautions For Installation And Use

    Cautions for Installation and Use Installation Please read the followings before you install the product. • Please read the User's Manual carefully before installing the product. • Before installing, turn off the ignition of your vehicle and remove the keys. •...

  • Page 14: Main Unit Installation

    Main Unit Installation Inserting and Removing Micro SD Card Insert the Micro SD Insert the card until you card as shown in the feel a click inside the slot. figure. Inserting Press the SD card Remove the Micro SD gently, and the tip of card completely.
  • Page 15 Recommended Installation Method To position the lens in the optimal position, it is recommended that you assemble the Main Unit and the Mount before installing the product. Recommended Installation Position If the product cannot be installed as described above, it can be installed at left or right from the mirror thanks to the product's wide viewing angle (120 degrees).
  • Page 16 Attach the Main Unit to the Clean the surface of the Mount. (Shipped attached windshield where the from factory.) product will be mounted using a dry fabric. Remove protective film Attach mount to the from the double-sided tape windshield firmly. Do not install the product on on the Mount.
  • Page 17 Adjust the the lens of the Connect the rear camera. Connect the rear camera to AV Main Unit to a proper -IN connector. angle. * Hold the Main Unit and the Mount in each hand and rotate the Main Unit. Connect the GPS module Connect the power cable, (sold separately).

  • Page 18: Assembling/Disassembling Main Unit And Mount

    Assembling/Disassembling Main Unit and Mount The Main Unit and the Mount can be disassembled as shown below. Assemble Disassemble...

  • Page 19: Features And Instructions

    Features and Instructions Please read the followings before using the product. • Do not operate the product while you are driving. • Micro SD card must be inserted in the product to record videos. • A warning will sound if SD card is removed while recording, and the video recording may be partially deleted. Power On/Off This product does not have a power button.

  • Page 20: Video Recording

    Video Recording Manual Recording Recording will start once the product is connected to a power Used to record videos manually. source and Micro SD card is inserted. Rec LED: Blue light flickers • Press ( ) to start manual Security LED: Blue light flickers recording.
  • Page 21 Recording Mode and Duration • Infinite Recording: Keeps recording in 1 minute intervals whether an accident occurs or not. 1 min. 1 min. 1 min. 1 min. 1 min. Continue_ • Event Recording: Records total of 20 seconds before and after an event (accident), 10 seconds each. A signal will sound once Event Recording has begun.
  • Page 22 Microphone/Speaker Checking GPS Reception Toggle voice recording On/Off (Factory Settings: Off) Once you connect GPS module and connect power to the product, the product will GPS signal will be detected. If GPS signal is received, an audio notification will sound and the color of MIC/GPS LED will change.
  • Page 23 Formatting Micro SD Card System Reboot This system reboot feature is used when a malfunction occurs or the device stops working. Press the Reset button with a Press and hold the button sharp object, such as a pin, and for 5 seconds or more. system will reboot.

  • Page 24: Parking Mode

    Parking Mode • The product automatically switches to Parking Mode 10 seconds after power connection to accessory power fuse is disconnected (ACC off). • Parking Mode has three recording modes: Recording Stand-by, Impact Recording, and Motion Recording. Parking Mode LED Indicator Parking Mode Rec LED Security LED Recording Stand-by Flickers (3 second intervals)
  • Page 25 Live Video Viewing You can view videos being recorded live by connecting the black box to your monitor through using a V-OUT cable (optional). (Video only / no audio) Monitor's video input AV - OUT Cable (Optional) * Connect the cable to the video VIDEO input of a monitor (sold separately).

  • Page 26: Viewer

    Viewer Using the Viewer Double-click on the Viewer icon ( ). Default Layout Viewer Shows the current viewer version. version Help Show Help. Full Screen Switch to full screen. Minimize Minimize the Viewer window. Exit Exit the Viewer.
  • Page 27 Opening Files Playing Recorded Videos 3 4 5 Play previous video Brightness Capture Rewind 10 seconds Capture current screen. Play Press the button once to Settings pause during playback and (Refer to page 32) to resume playback when paused. Fast forward 10 Volume seconds Click File Open. Play next video Switch Front/Rear-view Playback speed Select the drive where SD card is recognized. Playback speed can Button is disabled when only be adjusted during...
  • Page 28 Playing Recorded Videos Front-view video (Default) Invert front-view video horizontally Invert front-view video vertically GPS information (Vehicle speed) A logo is displayed when there is no GPS information available. Shows speed when GPS information is available. G-Sensor graph & Shows G-Sensor values (impact detection) in a graph. &...
  • Page 29 Playing Recorded Videos Rear-view video (Default) List of files in current folder Show list of files in the folder selected when opening a file. Invert rear-view video horizontally Invert rear-view video vertically Infinite folder Event folder Manual folder Motion folder Playlist Files are sorted sequentially with most recent files at the top.
  • Page 30 Playing Recorded Videos (Full Screen) • Click on the Full Screen button! • Double-click on the video you Hover the cursor over wish to watch in full screen! the video to bring up the Control Bar. Switches front and rear-view videos. Enlarges/reduces • Double-click on the video! video to fit the screen.
  • Page 31 Viewing GPS (location, speed) Information Brings up GPS Map window. * GPS information is available only if GPS module is installed. Shows speed. If GPS information is available If GPS information is not available...
  • Page 32 Settings Adjust the device's time settings. Time Setting "Daylight Savings Time" is a feature Time Zone for applying daylight savings time. • Select the quality of recorded videos. Video Quality • Lowering video quality results in storing more videos. • Infinite: Infinite Mode Recording •...
  • Page 33 Updating Firmware • Firmware cam be updated using Micro SD card. Copy new firmware file on the Micro SD card. Install the Micro SD card into Main Unit and connect power. Device will automatically be updated while MIC/GPS LED (red color) is flickering. Do not disconnect power while update is in progress.
  • Page 34 Micro SD Card Data Event Folder (Event) - 20 seconds of video and audio are saved as a file named yyyymmdd_hhmmss_E_x.mp4 when vibration is detected. - In Parking Mode, 20 seconds of video and audio are saved as a file named yyyymmdd_hhmmss_E_x.mp4 when vibration is detected.
  • Page 35 _System.cfg - Contains product settings information. _version.txt - Contains product's version information.
  • Page 36 Recording Capacity by Space Allocation Memory Infinite Event Motion Manual Channels Category Capacity (INFINITE) (EVENT) (MOTION) (MANUAL) Allocation 1 Channels Available Space Approx. 10GB Approx. 1.6GB Approx. 3.2GB 250MB Front Approx. 220 Approx. 105 Approx. 210 Approx. 5 Recording Time minutes recordings recordings...
  • Page 37 Resolutions by Recording Method Mode Condition Recording Status Destination Folder Front Camera Rear Camera Infinite Recording in Infinite INFINITE progress Infinite Mode (1280x720) G-Sensor impact Event Recording in EVENT detection progress G-Sensor impact Parking Event Recording EVENT detection in progress (640x480) Parking Mode Parking Event Recording (1280x720) Motion detection MOTION...

  • Page 38: Product Specifications

    Front Camera: 1280 x 720 (Max. 20 fps) [KC Certification Symbol and Number] (Rear Rear Camera: 680 x 480 (Max. 10 fps) camera sold Certification No.: KCC-REM-SDB-RV-300HD separately) Encoding H.264 (video), PCM (audio) File Format This device is registered for electronic magnetic field safety...
  • Page 39 Warranty Card Regarding Services Warranty • SD System guarantees the quality of this product as the following Product Date of Purchase Serial No. is valid according to Customer Dispute Resolution Standards (declared by Model Retailer Amount Paid for 1 year. Fair Trade Commission). • Customers are eligible to receive services from SD System or affiliated partners.
  • Page 40 MEMO...
  • Page 41 SD System Co., Ltd. / Customer Service Center 1899-3316 613 Hundai I Valley, 223-12 Sangdaiwon 1-Dong, Jungwon-Gu, Seongnam, Gyeonggi-Do, Korea...
