Summary of Contents for Road View RV-500F

  • Page 2: Table Of Contents

    Table of Contents What’s in the Box Assembling/Disassembling Main Unit and Mount Parts Features and Instructions Cautions for Installation and Use Viewer Main Unit Installation Product Specifications...
  • Page 3 Safety Warnings Cautions The following contains important information for ensuring safety of the user and preventing potential damage or inconvenience due to improper use. Please read the following warnings and cautions thoroughly before using the product. The safety warnings and cautions are categorized as below, depending on the level of potential risks and damages that may result from improper use.
  • Page 4 Warnings Do not disassemble, or modify the product on your own or Before installing the product, make sure that the vehicle's install the product in a way other than intended. ignition is turned off. Improper installation, disassembly, or modification of the product Installing the product while the ignition is on may result in electric may cause product to malfunction.
  • Page 5 Warnings Do not place water, beverages, chemicals, or other When installing the product, make sure it does not potentially harmful items near the product. interfere with the operation of other onboard devices, such as airbags. It may damage the product or cause malfunctions. Failure to do so may interrupt proper operation of such devices and cause injuries.
  • Page 6 Cautions Avoid strong impact to the product. Keep the camera lens clean at all times. It may damage the product or cause malfunctions. Failure to keep the camera lens clean may lower quality of recordings. Be careful when you touch this product while in use. The Using the product in a vehicle with a tinted windshield heat generated from the product may cause burn injuries.
  • Page 7 Cautions Do not place the product near a magnet or areas with Check the condition of the product and recording quality strong magnetic fields. on regular basis. It may damage the product or cause malfunctions. Make sure that the Micro SD card inserted in the product is working properly.
  • Page 8 Micro SD card is an essential part. Please read the following instructions carefully. The manufacturer will not take any liability concerning loss of data or damage to Micro SD card. Please use only genuine Micro SD card provided by the When purchasing or using a new Micro SD cards, make sure manufacturer.
  • Page 9 Features Various recording functions with 180° rotating Full HD (1920*1080) images at 30fps lens Functional design for easy attachment, High quality 140° wide-angle lens detachment and portability Low power consumption, Low-heat circuit Support of various recording modes design (infinite, manual, event) Easy operating instructions with voice guide...

  • Page 10: What's In The Box

    What’s in the Box The parts included in your package may not look identical with the following figures. Sold separately And some parts can be changed without notice. GPS module Main Unit User’s manual USB car cigarette jack Micro USB cable Cable clips •...
  • Page 11 Parts Vehicle Mount For installing on a glass Camera Lens For Video recording camera Front LED Indicates operating status in the front 1. MIC(RED LED): Indicates the microphone’s status (ON/OFF) 2. GPS(GREEN LED): Indicates a status of a GPS Status LED connection 3.
  • Page 12 DC-IN connector For connecting USB power cable GPS/AV OUT For the use of connecting to an external connector GPS antenna, and external video device Micro SD card slot Slot for inserting Micro SD card ※ Please insert a Micro SD card to the right direction. ※...

  • Page 13: Cautions For Installation And Use

    Cautions for Installation and Use Installation Please read the followings before you install the product. • Please read the User’s Manual carefully before installing the product. • Before installing, turn off the ignition of your vehicle and remove the keys. •...

  • Page 14: Main Unit Installation

    Main Unit Installation Inserting and Removing Micro SD Card Insert the Micro SD card Insert the card until you as shown in the figure. feel a click inside the slot. Inserting Press the SD card gently, Remove the Micro SD and the tip of the Micro card completely.
  • Page 15 Recommended Installation Method To position the lens in the optimal position, it is recommended that you assemble the Main Unit and the Mount before installing the product. Recommended Installation Position If the product cannot be installed as described above, it can be installed at left or right from the mirror thanks to the product’s wide viewing angle (140 degrees).
  • Page 16 Clean the surface of the Remove protective film from windshield where the the double-sided tape on the product will be mounted Mount. using a dry fabric. Attach mount to the Connect GPS to the exclusive windshield firmly. socket Do not install the product on GPS is sold separately.
  • Page 17 After connect to the USB Change a direction of lens on power cable, check the the main unit as you want. operating status. It should be connected to the DC-IN socket, and DC 5V power is used. Quality of video recordings may differ depending on the installed position and angle.

  • Page 18: Assembling/Disassembling Main Unit And Mount

    Assembling/Disassembling Main Unit and Mount The Main Unit and the Mount can be disassembled as shown below. Assembling Disassembling...

  • Page 19: Features And Instructions

    Features and Instructions Please read the followings before using the product. • Do not operate the product while you are driving. • Micro SD card must be inserted in the product to record videos. • A warning will sound if SD card is removed while recording, and the video recording may be partially deleted. Power On/Off This product does not have a power button.

  • Page 20: Video Recording

    Video Recording Manual Recording Recording will start once the product is connected to a power Used to record videos manually. source and Micro SD card is inserted. • Front LED: Blue Light flickers • Press button shortly to start • Status LED: REC(Green) flickers manual recording.
  • Page 21 Recording Mode and Duration • Infinite Recording: Keeps recording in 1 minute intervals whether an accident occurs or not. 1 min. 1 min. 1 min. 1 min. 1 min. Continue_ Event Recording: Records total of 30 seconds before and after an event (accident), 15 seconds each. •...
  • Page 22 Snapshot / Micro SD card formatting Voice recorder ON/OFF (initial setting: OFF) / Speaker ON/OFF • Press button shortly (less • Press button shortly (less than 1second): Snapshot than 1second): MIC. ON/OFF • Sound: Click • Voice: ON “Sound is recording now.
  • Page 23 Checking GPS Reception Settings Once you connect GPS module and connect power to the product, User’s settings can be configured on the setting menu of the viewer. the product will GPS signal will be detected. If GPS signal is Settings that you can configure consist of Time setting, Video received, GPS LED will turn on.
  • Page 24 Updating Firmware • Firmware can be updated using Micro SD card. Copy new firmware file on the Micro SD card. Insert the Micro SD card into Main Unit and connect power. Device will automatically be updated while GPS LED(Green) is flickering. Do not disconnect power while update is in progress.
  • Page 25 Micro SD Card Data • Recorded videos can be played on the exclusive viewer. Event Folder (Event) - 30 seconds of video and audio are saved as a file named yyyymmdd_hhmmss_E.avi when vibration is detected. Infinite Recording Folder (INFINITE) - 1 minute of video and audio recorded in Infinite mode will be saved as a file named yyyymmdd_hhmmss_I.avi Manual Folder (MANUAL) - 30 seconds of video and audio are saved as a file named yyyymmdd_hhmmss_B.avi when Manual Recording button is pressed.
  • Page 26 Check real-time videos You can check a real-time video, which is being recorded, if you connect AV-OUT cable to your car monitor. (Video: O / Audio: X) Car monitor video input terminal AV-OUT cable VIDEO * Connect it to the video input socket on a car monitor <AV-OUT signal specifications>...
  • Page 27 Viewer Setting the Viewer Video from the black box can only be played back using the PC viewer. Download the viewer from the website or find it on the Micro SD card (RV-500F_Viewer_Vx.x.x.zip). See below for instructions on installing the viewer. Viewer Installation Uncompress the installation file (RV-500F_Viewer_Vx.x.x.zip).
  • Page 30 Using the Viewer Double-click on the Viewer icon ( ). Default Layout Viewer Shows the current viewer version. version Help Show Help. Full Screen Switch to full screen. Minimize Minimize the Viewer window. Exit Exit the Viewer.
  • Page 31 Opening Files Playing Recorded Videos 3 4 5 Play previous video Brightness Capture Rewind 10 seconds Capture current screen. Play Press the button once to Settings pause during playback and (Refer to page 35) to resume playback when paused. Fast forward 10 seconds Volume Play next video Switch Front/Rear-view...
  • Page 32 Playing Recorded Videos Front-view video (Default) Invert front-view video horizontally Invert front-view video vertically GPS information (Vehicle speed) A logo is displayed when there is no GPS information available. Shows speed when GPS information is available. G-Sensor graph & Shows G-Sensor values (impact detection) in a graph. &...
  • Page 33 Playing Recorded Videos List of files in current folder Show list of files in the folder selected when opening a file. Invert rear-view video horizontally Invert rear-view video vertically Infinite folder Event folder Manual folder Motion folder Playlist Files are sorted sequentially with most recent files at the top.
  • Page 34 Viewing GPS (location, speed) Information Brings up GPS Map window. Shows speed.
  • Page 35 Settings Time Setting Adjust the device’s time settings. Video Select the quality of recorded videos. Resolution Infinite: Infinite Mode Recording Mode Infinite + Event: Infinite + Event recording Higher sensitivity results in recording 3G Sensor small impacts as an event. Select the quality of recorded videos.
  • Page 36 Recording Capacity by Space Allocation Memory Infinite(60%) Event(20%) Manual(10%) Snapshot(1%) Channel Category Capacity (INFINITE) (EVENT) (MANUAL) (SNAPSHOT) Available Approx. 4.5GB Approx. 1.5G Approx. 0.75G Approx. 0.75G Space Recording Max. 80 files Max.65 files Max.32 files Max.150 files Files Recording Max. 80 Max.32 Max.15 minutes...
  • Page 37 Recording Capacity by Space Allocation Memory Infinite(60%) Event(20%) Manual(10%) Snapshot(1%) Channel Category Capacity (INFINITE) (EVENT) (MANUAL) (SNAPSHOT) Available Approx. 18GB Approx. 6G Approx. 3G Approx. 0.3G Space Recording Max.320 files Max. 260 files Max. 130 files Max. 600 files Files Recording Max.
  • Page 38 Resolutions by Recording Method Mode Condition Recording Status Destination Folder Main Camera Infinite Infinite Recording INFINITE G-Sensor impact Infinite Mode Event Recording EVENT detection (1920x1080) Press Snapshot button Snapshot Recording SNAPSHOT Press Manual Manual Recording Event Recording MANUAL Recording button...

  • Page 39: Product Specifications

    (Max. 30 fps) Encoding H.264 (Video), AAC (Audio) [Certification Symbol and Number] File Format Power Model Number: RV-500F DC 5V Tested To Comply Dimensions & Weight 117 x 31 x 31(mm) / 90g With FCC Standards FOR HOME OR OFFICE USE Operating Temperature -20˚C ~ +60˚C...
  • Page 40 • This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: • (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation •...
  • Page 41 The Roadview Lineup includes various models designed to meet the needs of today's consumers. DESIGN TREND LIFE HIGH STYLE TECHNOLOGY NEEDS...
  • Page 42 STYLISH EASY AWESOME shape color user system Modern and A joy to behold! An intuitive interface functional shape Multiple colors to choose from and numerous convenience features...
  • Page 43 Warranty Card Warranty Regarding Services is valid for 1 year. • SD System guarantees the quality of this product as the following according to Customer Dispute Resolution Standards (declared by Fair Trade Commission). • Customers are eligible to receive services from SD System or affiliated partners. Covered by Warranty Charged Service 1) Non-malfunctions...
  • Page 44 SD System Co., Ltd. Customer Service Center: +82-70-8299-5989 613, Hyundai I Valley, 31, 244, Beon-Gil, Galmachi-Ro, Jungwon-Gu, Seongnam-Si, Gyeonggi-Do, Korea www.sdsystem.com...
