Dell Inspiron 2000 System Reference Manual

Hide thumbs Also See for Inspiron 2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Setup Manual, Manual
Dell™ Inspiron™ 2000 System Reference
Conventions
Technical Overview
Using the Computer
Installing Drivers
Technical Specifications
System Setup
Error Messages and IRQ Assignments
Passwords and Security
Ports and Connectors
Power Sources
Power Management
Removing and Replacing Parts
Information in this document is subject to change without notice.
© 1999 Dell Computer Corporation. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Computer Corporation is strictly forbidden.
Trademarks used in this text: Dell, Inspiron, and the DELL logo are trademarks of Dell Computer Corporation; Microsoft, Windows, Windows NT, and MS-DOS are registered
trademarks of Microsoft Corporation; Intel and Pentium are registered trademarks of Intel Corporation; 3Com is a registered trademark of 3Com Corporation; Adobe is a
trademark of Adobe Systems Incorporated, which may be registered in certain jurisdictions.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Computer Corporation
disclaims any proprietary interest in trademarks and trade names other than its own.
Initial release: 21 Dec 1999
Last revised: 6 Jun 2001
