- Page 1 SMART ™ STANDING FRAME USER MANUAL...
- Page 2 Producer's identification number in the Registration Department of Healing Products, Medical Products and Biocide Products: PL/CA01 04088/W Akces-Med. Sp. z o.o. Company introduced quality management system ISO 13485 regarding production, sales and service. The system is certified by Det Norske Veritas.
-
Page 3: Table Of Contents
CONTENTS 1. The purpose of instruction manual...................5 2. Indications for use......................5 3. General characteristics of Smart static standing frame..........6 3.1. Standard equipment....................6 3.2. Additional equipment....................6 4. Size table..........................7 5. Desription how to assembly standing frame..............8 5.1. Assembly of standing frame size 1 and 2.............8 5.2. - Page 4 The product is easy in use thanks to which family as well as hospital staff find it easy to look after patient. Furthermore, smart is equipped with the system of precautions. It is highly beneficial due to the fact that patient feels safe and comfortable regarding his upper limbs.
-
Page 5: The Purpose Of Instruction Manual
The present user manual contains basic information which is essential for proper usage, preparation, maintenance, cleaning and guarantee conditions SMART™ static standing frame. User manual should be kept in easily accessible place. It is designed for people who look after the disabled , and for both doctors as well as physiotherapists who operate the device. -
Page 6: General Characteristics Of Smart Static Standing Frame
4. Knee support with pelottes 5. Foot support with pelottes 6. Tray 3.2. Additional equipment Safety Comfort SMD_002 Aid for moving SMD_003 Soft cover for tray SMD_427 Tango Wheel patients AM_P SMD_428 Tray with edge www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 7: Size Table
Weight and dimensions of the device [cm] width [cm] length [cm] height [kg] weight 19,8 24,4 Note: Dimensional tolerance in the table is: +1/-1 cm. *Knee supports height depends on the height of the tray. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 8: Desription How To Assembly Standing Frame
DESRIPTION HOW TO ASSEMBLY STANDING FRAME 5.1 Follow these rules so as to assembly SMART™ standing frame in size 1 and 2: STEP 1. Insert posts into holes in the frame so as that mesure is placed towards the outside of the device (pic. 1, 2) - Page 9 Allen wrench; Next, unfold tray's top (fig.1) and block ź fig. 1 it by pressing top (fig.2) and tightening tray's fastenings (fig.3, fig.4). fig. 2 www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 10: Assembly Of Standing Frame Size 3 And 4
4 fig. 3 5.2. Follow these rules so as to assembly SMART™ standing frame in size 3 and 4: STEP 1. Insert transverse frame into profiles for frame (pic 7, 8). pic 7 pic 8 STEP 2. Put footplate on frame's posts with castors (pic 9). - Page 11 After successful assembly of the standing frame, the stickers can be removed. STEP 4. Tighten all screws with the aid of Allen wrench (pic 11). STEP 5. Put upper part of Smart on frame (pic 12). pic 12 pic 11 STEP 6.
- Page 12 6 fig. 7 fig. 8 www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 13: Desription How To Use Standing Frame
(fig.13). Pelvic belt can be mounted on frame at any height. Belt stabilizes buttocks and makes it possible to adapt correct position in standing frame. www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 14 6.1.4. So as to adjust the suitable height of torso braces it is necessary to loosen screws which are situated at the frame (fig. 16). Activity should be repeated for the second frame. fig. 16 www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 15: Knee Support
Regarding pelottes, they can be adjusted at any angle. fig. 19 6.2.3. Concerning size 1 and 2, knee pelottes are equipped with belts which are fastened by means of Velcro tapes (fig.20). fig. 20 www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 16: Foot Support
(fig.22). fig. 22 CAUTION! SMART™ standing frame should be used in compliance with guidelines in this user manual. Before using the product, it is highly important to prepare both patient and device. www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 17: Additional Equipment
So as to put soft cover for tray it is necessary to put it on tray and then fasten cover under top with the aid of Velcro tapes (fig.23, 24, 25). fig. 23 fig. 24 fig. 25 www.akces-med.com +48 17 864 04 77 export@akces-med.com... -
Page 18: The Use Of Standing Frame
THE USE OF STANDING FRAME CAUTION! SMART™ has to be used with compliance to guidelines included in this user manual. Remember to use the product only with someone who is trained and knowledgeable. Do not forget to prepare both product as well as patient before using SMART™! -
Page 19: How To Use Smart
8.2. How to use SMART 1. Before use it is necessary to: · Unfold the device; · Place the device on even ground; · Make sure that all parts are serviceable, correctly mounted and stable; · Block brakes; · Adjust the device to patient's measurements;... -
Page 20: Upright Position
Make sure that all belts as well as fastenings from adjustable elements are correctly adjusted and fastened. CAUTION! It is forbidden to leave the patient unattended CAUTION! Only trained staff can adjust standing frame to the patient! www.akces-med.com +48 17 864 04 77 export@akces-med.com... - Page 21 If these undesirable side-effects still occur it is necessary to contact doctor. If these side effects disappeared, remember to inform doctor so as to make decision concerning further upright position process. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
-
Page 22: Safety Rules
It is highly important to consult either doctor or physiotherapist in order to make right decision concerning the choice of SMART™ and its size. It is also essential to familiarize with the guidelines described in user manual before using the device. - Page 23 CAUTION! The weight of user should not be bigger than maximal weight described on page 7 where you will find information regarding this issue. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
- Page 24 1) AKCES-MED Sp. z. o. o sells products free from manufacturing defects or faults. 2) Manufacturer gives the purchaser 24-month guarantee from the date of purchase. All defects revealed during warranty period will be repaired free of charge. 3) All defects which appear after warranty period can be repaired only when the user will pay for it.
-
Page 25: Maintenance And Cleaning
MAINTENANCE AND CLEANING SMART™ should be kept clean and used in compliance with the manufacturer's recommendations. The device should be kept in clean, dry and ventilated room. Maintenance as well as cleaning have to be performed at least once a month. Regular cleaning and maintenance of device are indispensable to maintain its correct functionality as well as safety. - Page 26 CAUTION! In case of any damages, it is essential to contact the person who sold you the product. www.akces-med.com +48 17 864 04 77 export@akces-med.com...
- Page 28 ORTHOPAEDIC DEVICES MANUFACTURER Akces-MED Sp. z o.o. Jasionka 955B 36-002 Jasionka tel. (17) 864 04 77 www.akces-med.com e-mail: export@akces-med.com Authorised Dealer Date of issue: 16.05.2014 The last update: 06.04.2016...
