- Page 1 WWW.BRICKCOM.COM | EXPERT IN IP SURVEIL LANCE May 17, 2011 Quick Installation Guide for WCB-100Ap Confidential © Brickcom Corporation, All Rights Reserved.
-
Page 2: Ethernet Cable
| EXPERT IN IP SURVEIL LANCE Things to Have Before You Start • Brickcom WCB-100Ap – Username/Password: admin/admin • Brickcom DWRT-600N Wi-Fi Simultaneous Dual-Band Router – Default IP address: 192.168.1.1 • Wi-Fi Antenna • Brickcom Software Kit – Download page: http://www.brickcom.com.tw/support/download.php •... - Page 3 WCB-100Ap Camera Hardware Power LED Network Link LED Micro SD Card Slot Internet LED Lens & Focus WPS LED Privacy Mask LED Speaker Wi-Fi WPS Button Microphone PIR Sensor Privacy Button White Light LED Confidential © Brickcom Corporation, All Rights Reserved.
-
Page 4: Ethernet Port
WWW.BRICKCOM.COM | EXPERT IN IP SURVEIL LANCE WCB-100Ap Camera Hardware Ethernet Port DC Power In (12V 1A) Reset Button Stand Confidential © Brickcom Corporation, All Rights Reserved. - Page 5 | EXPERT IN IP SURVEIL LANCE DWRT-600N Hardware Wi-Fi Simultaneous Dual-Band Router: DWRT-600N • LED Indicators DC Power In WPS Button (12V 1.5A) USB Port Reset Button LAN Ethernet Ports WAN Ethernet Port Confidential © Brickcom Corporation, All Rights Reserved.
-
Page 6: Set Up Wi-Fi Connection
LED indicators will go off, then release it. This process takes around 60 seconds. – To reset the WCB-100Ap to the factory default, press the Reset button for 10 seconds and then release it. This process takes around 90 seconds. - Page 7 Set Up Wi-Fi Connection Using WPS • Step 1: Power on the DWRT-600N and the WCB-100Ap. Wait for 1 minute for both devices to be up and running. Step 2: Press the WPS button of the DWRT-600N. The WPS LED will be blinking.
- Page 8 Brickcom Software Kit • Includes EasyConfig, PC-NVR, User Manual, Quick Guide, etc. • Language Support: English, Spanish, French, Deutsche, Japanese, Chinese, etc. • Comes in a CD with the Brickcom IP camera. The CD supports Auto Run. • Click Install to install the Brickcom Software Kit to your PC.
- Page 9 WWW.BRICKCOM.COM | EXPERT IN IP SURVEIL LANCE EasyConfig • Use EasyConfig to discover and access the Brickcom IP camera. – Simple Mode allows the user to find the camera, connect to it and do the live view in just a few mouse clicks! –...
- Page 10 WWW.BRICKCOM.COM | EXPERT IN IP SURVEIL LANCE PC-NVR (BRC-64) • Brickcom’s free-bundled 64-channel recording software. No license fee. Included in the Brickcom Software Kit. The user manual is also included. • Supports Windows XP, Vista and 7. • • Supports simultaneous live view, recording and playback.
- Page 11 Next Next Next Choose Simple Mode Choose the camera and click Next and click Next Choose Back to set up more cameras Choose Live View First-Time ActiveX Player Installation Username: admin Password: admin Confidential © Brickcom Corporation, All Rights Reserved.
- Page 12 | EXPERT IN IP SURVEIL LANCE Notes • If the image is blurry, please adjust the focus of the WCB-100Ap. • The wireless distance between the DWRT-600N and WCB-100Ap is typically 60~90ft indoors, and up to 200ft in the line-of-sight situation. The actual distance varies with the environment.
- Page 13 Brickcom, Your Best Partner. Thank You © Brickcom Technology Inc., All Rights Reserved. This document is for planning purposes only, and is not intended to modify or supplement any specifications or warranties relating to products of Brickcom Technology. Brickcom may make Confidential ©...
