Page 1: Quick Installation Guide
Wireless Outdoor N Access Point WAP-350N Quick Installation Guide Quality Service Group... - Page 2 Package Contents Brickcom Wireless Outdoor N Access Point Pole Mount Kit Water-Proof Connector Device Description <Connector View> RJ45 Connector RJ45 Connector <Bottom View> Mount Kit Assembly Screw Aperture Ventilation Holes Reset Button Ground Pad/ Washer...
- Page 3 Hardware Installation 1. Pole Mount Kit Installation 1.1 Parts Index Table Qty: 2, Hex Head Bolt, M5*16mm Qty: 2, M5 Spring Washer, 8.9mm Qty: 2, M5 Spring Washer, 8.9mm Qty: 5, M8 Spring Washer, 13.50mm Qty: 1, M8 Spring Washer, 16mm Qty: 1, Hex Head Bolt, M5*35mm Qty: 3, Hexagon Nuts, M8, 35mm Qty: 2, Hex Head Bolt, M8*100mm...
- Page 4 1.2 Setup Steps Step 1. Use a screwdriver and the supplied screws(1) and washers(2) to secure the Mount Kit-1(9) to the backside of the WAP-350N. Step 2. Attach the Mount Kit-2 (10) to the Mount Kit-1 using the supplied screws(3), washers(4,5) and nuts(7). After that, use the supplied screws(6) to tighten the Mount Kit-2.
- Page 5 2. Access Point Connection 2.1 Using a PoE Switch Connect the Access Point to a PoE switch via a single Ethernet. 2.2 Using a non-PoE Switch Connect the Access Point to a non-PoE hub using a PoE Injector. Note: For assembling the waterproof connector, please refer to the instructions included in the connector package.
- Page 6 Connecting with a Brickcom Network Camera Step 1. Follow these steps to quickly launch the camera’s web-based live view page via the Access PointComplete the installation of the Camera(s) and Access Point. Step 2. Connect the computer to the same network as the Access Point.
- Page 7 Click <Live View> to view the live video from the connected camera. 格式化: 縮排: 左: -0.32 cm Note: Because the Access Point’s default frequency is 5GHz, the Brickcom Camera need to equipped dual band WiFi connectivity.
- Page 8 Accessing the Access Point The Access Point works right out of the box with the default settings. The default SSID is Brikccom, the default wireless channel is auto and the default frequency is 5GHz. To change any of the settings, the Access Point can be configured through a web browser using the web-based utility.
