- Page 1 January 22,2008 1.5M pixels progressive USB2.0 COLOR(BW) CCD CAMERA ARTCAM-150P ARTCAM-150P -OP INSTRUCTION BOOKLET ARTRAY CO., LTD.
-
Page 2: Table Of Contents
Contents 1. Description 2. Main Features 3. List of items 4. Position of each part 5. Functions and Operation 6. Dimension 7. Timing - Trigger mode 8. Specifications... -
Page 3: Description
2. Main Features * High sensitivity and high resolution Max.resolution of 1360 1024 pixels. * Flange-back adjustment With Artray's original mechanism, flange-back is adjustable while real-time image is displayed. * Electric shutter Shutter speed can be adjusted on software screen. -
Page 4: Position Of Each Part
4. Position of Each Part 4-1 Side panel Flange-back adjustment screw Caution Do NOT remove the cover. This may break camera or cause static electricity. 4-2 Back panel (1) USB :USB2.0 interface cable (2) TRG (BNC) :External contact trigger... - Page 5 4. Position of Each Part (150P -OP) 4-3 Frame for sensor Layout 43.44 37.98 6.30 27.00 21.75 19.00 19.00 8.00 16.00 16.00 Center 32.00 43.50 43.50 11.00 11.00 38.00 19.00 19.00 16.00 16.00 21.75 21.75 7.00 27.00 37.98 1.60 1.60 For enclosure assembly, use 8 holes of 4-4 Frame for control Layout In case of using IO function, remove the back panel of camera and connect the cable to CNO5.
-
Page 6: Functions And Operation
5. Functions and operation 5-1 Selection of lens The mount of lens is C-mount. C-mount fixing screw is installed in the camera. PC monitor 5-2 Camera connection Image output connection USB2.0 Cable USB2.0 host adaptor 6.Dimension 0.5 (Adjustment) 59.3 2- 10 Focusring 1/4-20UNC USB OUT... -
Page 7: Timing - Trigger Mode
7. Timing - Trigger mode Trigger input 79.6ms(24MHz ) 2 clk delay Cam_trig Line6 Line8 Line1 Line valid PI_Hd(in) 0.65ms(24MHz ) Internal frame valid Exposure time 79.6ms(24MHz ) Internal Internal image signal Actual obtain image Image transfer 150P3 Trig Mode Timing 2. -
Page 8: Specifications
8. Specifications of camera ARTCAM-150P Image pick up device 1/2"CCD Color mothod Single-panel CCD color method Max. resoluion 1.45M pixel Lens size 1/2"format Type of CCD Inter-line model Pixel size 4.65 m x 4.65 m(7.6 x 6.2mm pixel areas) S/N ratio 50dB 0.8Lux/F1.2 Minimum illuminance of object... -
Page 9: Operating Environment
Image pick up device Comment Remark Parameter SPEC 205L,205AK Imager to 1/2" Optical size Equivalent 1434 x 1050 Total resolution 1360 x 1024 Max resolution 4.65 x 4.65um Pixel size 0.8Lux/F1.2 Minimum illuminance of object have IR cutting filter Crystal filter Physical specifications Comment Parameter... - Page 10 PCs which use south-bridge of ICH4,ICH5 and ICH6 are recommended *CPU: Pentium4 1.7GHz or higher Embedded USB2.0 port (PCI/PCMCIA USB2.0 ports are not compliant) *Memory 512MB or higher *OS Windows 2000(SP4)/XP(SP1) ARTRAY CO,. LTD. 5F Ueno bldg, 1-17-5 kouenjikita,Suginami-ku, Tokyo Japan 166-0002 Tel:(81)3(3389)5488 Fax:(81)3(3389)5486 Email: artray@artray.co.jp URL: http://www.artray.co.jp...
- Page 11 ARTRAY CO., LTD. 2007/08/27 Refer to the restrictions below when using ARTCAM/ARTCNV 1. USB host chip Use the USB host chip which is Intel authorized USB2 host controller. Make sure if you find "Intel®82801DB/DBM USB2 ENHANCED HOST CONTROLLER" on USB Controller window according to the following procedure.
