- Page 1 August 30, 2012 Ver1.12 USB3.0 CCD CAMERA ARTCAM-USB3 Series(CCD) INSTRUCTION BOOKLET 0.33 M pixels ARTCAM-424KY-USB3 Series 1.5 M pixels ARTCAM-267KY2-USB3 Series 2.0 M pixels ARTCAM-274KY2-USB3 Series 5.0 M pixels ARTCAM-655KY-USB3 Series ARTRAY CO., LTD.
-
Page 2: Table Of Contents
Contents 1. Attention ··············································· 3 2. Introduction ··········································· 6 3. Main Features ······································· 6 4. The Product ·········································· 7 5. Connect the Camera ······························ 8 6. Specifications ········································ 9 7. External Dimensions ······························ 11 8. Recommended PC ································ 13 - 2 -... -
Page 3: Attention
1. Attention ■About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide an replacement. 4．We cannot guarantee the safety of improper uses of the camera. - Page 4 ■For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own.
- Page 5 To save the environment, we do not issue warranty in printed format. Instead, all records of the warranty periods, delivery dates and the customer information are well kept in our system. For more details, please refer to the sites below: Hardware Warranty : http://www.artray.us/download/artray_warranty.pdf - 5 -...
-
Page 6: Introduction
2. Introduction ARTCAM-USB3 Series is CCD cameras for industrial use. This series adopt USB3.0 interface, so the data can be delivered to PC directly without a capture board. 3. Main Features ・USB3.0 Interface Our cameras adopt USB3.0 interface which provides a maximum transfer rate of 5 Gbps, directly to PC. -
Page 7: The Product
4. The Product 1) Camera 2) USB3.0 cable TYPE A-B connector 2m 3) Introduction Booklet 4) Viewer software/Device Driver CD <Options> 1) C Mount lens 2) 2 Measurement & Filing Software [ART-MEASURE] 3) Recording Software [ART-REC] 4) Software Development Kit [ARTCCM-SDK] - 7 -... -
Page 8: Connect The Camera
5. Connect the Camera 5-1 How to connect a camera 5-2 Shutter Speed Shutter speed can be changed on the standard viewer software ART-Viewer. The shutter speed is set directly on the sensor register, so please refer to the following formulas for the real exposure time. -
Page 9: Specifications
6. Specifications 6-1 Color Model ARTCAM-424KY-USB3 ARTCAM-267KY2-USB3 ARTCAM-274KY2-USB3 ARTCAM-655KY-USB3 Sensor Type CCD Color Image Sensor Active Pixels 659(H) x 494(V) 1392(H) x 1040(V) 1628(H) x 1236(V) 2456(H) x 2058(V) Active Imager 4.88(H) x 3.66(V)mm 6.47(H) x 4.83(V)mm 7.16(H) x 5.44(V)mm 8.47 (H) x 7.10(V)mm Size 1/3”... - Page 10 6-2 Monochrome Model ARTCAM-424KY-BW-USB3 ARTCAM-267KY2-BW-USB3 ARTCAM-274KY2-BW-USB3 ARTCAM-655KY-BW-USB3 Sensor Type CCD Monochrome Image Sensor Active Pixels 659(H) x 494(V) 1392(H) × 1040(V) 1628(H) x 1236(V) 2456(H) × 2058(V) Active Imager 4.88(H) x 3.66(V)mm 6.47(H) × 4.83(V)mm 7.16(H) x 5.44(V)mm 8.47 (H) × 7.10(V)mm Size 1/3”...
-
Page 11: External Dimensions
7. External Dimensions 7-1 C-MOUNT, CASED, USB CABLE TYPE ARTCAM-424KY-USB3/424KY-BW-USB3 ARTCAM-267KY2-USB3/267KY2-BW-USB3 ARTCAM-274KY2-USB3/274KY2-BW-USB3 - 11 -... - Page 12 7-2 C-MOUNT, CASED, USB CABLE TYPE ARTCAM-655KY-USB3/655KY-BW-USB3 - 12 -...
-
Page 13: System Requirements
*For the recommended extension cable, please contact our sales department. (TEL: +81-3389-5488) ARTRAY CO., LTD. 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan Tel : +81-3-3389-5488 Fax : +81-3-3389-5486 Email : sales@artray.us URL : www.artray. us - 13 -...
