MPL024 Users Guide
This brief guide explains how to use and set up your MPL024.
1
Introduction
The MPL024 is an MPEG player designed to use with TV and Video Monitors for
playing MPEG-1/MPEG-2/MPEG-4 video and audio files.
MPEG-1, MPEG-2, MPEG-4* video
•
MPEG still picture output
•
JPEG picture
•
MP3 audio file
•
Video signals of PAL & NTSC standard
•
Composite and S-Video signal output
•
VGA output
•
Stereo audio output
•
RS-232 port
•
* DivX MPEG-4 format
.
- 1 -
1.2
Advertisement
Table of Contents
Related Manuals for TBM MPL024
Summary of Contents for TBM MPL024
- Page 1 MPL024 Users Guide This brief guide explains how to use and set up your MPL024. Introduction The MPL024 is an MPEG player designed to use with TV and Video Monitors for playing MPEG-1/MPEG-2/MPEG-4 video and audio files. MPEG-1, MPEG-2, MPEG-4* video •...
-
Page 2: System Design
System Design A typical setup of a Video Monitor display with a MPL024 looks like this: Specification Switches and Buttons connector • Remote Ext. (8 buttons connection only) -> Frontside • Power/Status LED -> Frontside • Compact Flash card slot -> Frontside •... - Page 3 (CN5) for alternative remote control buttons. B) Touch screen segments The MPL024 when connected with a LCD interface controller can output videos on to • LCD screen. Button control can be performed via touch screen for panel sizes of 6.4”, 7.9”, 10.4”, and 15”...
-
Page 4: General Notes
GeneralNotes The MPL024 is designed for use with Video Monitors and other analogue signal input displays. Here are some notes for correct use: Power Input: 12V DC, 1.2A (minimum) is required; this should be a regulated supply. • Digital Video - use MPEG-1/2* video encoded at Video-CD standard. (See “Content •... -
Page 5: System Setup
• B) POWER UP Config mode In config mode, you may need an internal 8-fold (MPL024) buttons or 8-fold segmented touch screen to operate. Holding button 8 and power on. The OSD menu screen will be shown as follow: •... -
Page 6: Auto-Loop Playback
After Track 1 is set to play, it will play to the end, than Track 2 will start playing from beginning to end, then Track 3 etc. When the MPL024 plays to the end of the last track, it will automatically jump back to the beginning of Track 1, repeating tracks 1, 2 then 3 etc. The MPL024 will play in auto-loop play mode, so long as none of the function buttons are pressed. -
Page 7: Operating Modes
Operating Instructions OPERATING MODES There are two operating modes in MPL024 – “playlist mode” and “simple play mode” 1. Playlist mode When operating in playlist mode, both project file (*.prj) and playlist file (*.pll) must be present on the Compact Flash card. These are used to control the sequence for all video tracks. -
Page 8: Operating Functions
OPERATING FUNCTIONS The following key buttons are default in “Simple Play mode”. (This operation requires button switchmount or 8-segments touch screen connection.) PLAY (Button 1) Resumes playback of videos from track 1 after STOP has been pressed. • Resumes playback of the track from the point that it has been set to PAUSE. •... -
Page 9: Usb Port
USB PORT The MPL024 USB port provides the ability to connect a USB memory stick directly and to read and write data to and from the Compact Flash card. (Please refer to Application Note for details) Connect USB memory stick of your MPL024 unit. It will show the following screen... -
Page 10: Specifications
Net Weight: 135g External ports: COM port - for barcode application. Remote Ext. - External keyboard (8 x MPL023; 16 x MPL024) - USB Host connection Video Storage CompactFlash Card – various memory capacities available Accessories: 64MB, 128MB, 256MB, 512MB, 1G, 2G, 4G For MPEG-2 video, the encoding rate is limited to 5Mb/s •... -
Page 11: Warranty
The manufacturer’s liability for damages to customer or others resulting from the use of any product supplied hereunder shall in no event exceed the purchase price of said product. Contact tbm Technologieberatung & Medienservice GmbH Schragenhofstraße 35 D-80992 München + 49 (0) 89 30 76 42 81...
