MPL020 S - CF MediaPlayer
CONTENTS
1. Package Contents....................................................
2. Introduction..........................................................
3 . Fe ature s...... ...... ......... ......... ...... ........ ......... ...... ...
4. Hardware Overview.................................................
5. Remote Control.....................................................
6. Setting Up............................................................
6 .1 S L ID E S ETU P... ...... ...... ...... ... ...... ... ...... ... ..... .
6 . 2 M U S I C S E T U P... ... ... ... ... . ... ... ... ... ... ... ... ... ... ...
6 . 3 M O V I E S E T U P... ... ... ... ... . ... ... ... ... ... ... ... ... ... ...
6.4 SLIDESHOW SETUP.........................................
6 .5 PREFE REN C E... ... ... ... ... ... .... ... ... ... ... ... ... ... ... ...
7. Using the MPL020 S...................................................
7.1 Play Picture File................................................
7.2 Play Music File.................................................
7.3 Play Movie File.................................................
7.4 File Library......................................................
7.5 Hot Key..........................................................
8. Optional Function................................................. 10
8.1 Works with Timer Function Only............................. 10
9. Optional Auxiliary Equipment.................................... 17
9.1 IR Cable.......................................................... 17
9.2 PIR Sensor...................................................... 17
9.3 Laser Scanner................................................... 17
10. Troubleshooting.................................................... 18
1
1
2
2
3
4
4
4
4
5
5
6
6
7
8
9
9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MPL020 S - CF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TBM MPL020 S - CF

Summary of Contents for TBM MPL020 S - CF

  • Page 1: Table Of Contents

    CONTENTS 1. Package Contents……………………..…………………….. 2. Introduction………………………………….……………... MPL020 S - CF MediaPlayer 3 . Fe ature s…… …… ……… ……… …… …..… ……… …… … 4. Hardware Overview…………………………….…………... 5. Remote Control…………………………………………….. USER MANUAL 6. Setting Up……………………………………..……..…….. 6 .1 S L ID E S ETU P… …… …… …… … …… … …… … ..… .

  • Page 2: Package Contents

    1. PACKAGE CONTENT 3. FEATURES Supports multiple file formats：Music, Picture and Movie. Supports CF, SD, MMC and MS (Pro) memory card. Supports Video, S-Video, VGA (640x480) and Audio output. Supports USB 2.0/ 1.1 interface. Supports Laser Scanner and PIR Sensor connectors (optional). Supports NTSC and PAL format.

  • Page 3: Remote Control

    5. REMOTE CONTROL 6. SETTING UP Press the “SETUP” button on the remote control to open the “SETUP MENU – MAIN PAGE” shown in the Power on/ off following figure. There are five groups of sub-menu Mute sound in the setup menu. Open the setup menu 、...

  • Page 4: Slideshow Setup

    6.4 SLIDESHOW SETUP SLIDESHOW MODE： ： ： ： Set the slideshow to start automatically. 7. USING THE MPL020S FOLDER REPEAT： ： ： ： Set all files (picture, music or movie) in the folder to show only once or Copy files (music, picture and movie) to the memory card first. continuously (loop).

  • Page 5: Play Music File

    7.3 PLAY MOVIE FILE 7.2 PLAY MUSIC FILE Step 1: Press the “MOVIE” button on the remote control from any menu. Step 1: Press the “MUSIC” button on the remote control from any menu. Step 2: The preview mode will show all the video files on the memory card. 、...

  • Page 6: File Library

    7.4 FILE LIBRARY 8. OPTIONAL FUNCTION Step 1： ： ： ： Press the “FILE” button on the remote control from any menu. 8.1 WORKS WITH TIMER FUNCTION ONLY The MPL020 S will power on/ off automatically at the designated time. Press the “EDIT”...
  • Page 7 8.2.2 SCHEDULE SETUP A. Basic Schedule In the “Basic Schedule” mode, you can select files that you want to play and set up the 8.2.2.1 INSTALL THE SCHEDULE SOFTWARE volume and the play times of each file. Execute “setup.exe” to install the Schedule software in the CD driver, and finish the Add：...
  • Page 8 Remove： ： ： ： Click this button to remove the file from the list. Select the file that you want to remove from the list, and press the “Remove” button B. Advance Schedule to delete. In the “Advance Schedule” mode, you can select files that you want to play, and can also set up the volume, the play times, and the initial and end time of each file.
  • Page 9 Step 3： ： ： ： Repeat the steps 1〜2 to add other files. Date Setup Error！ ！ ！ ！ There are some errors in the “Advance Schedule”. Check the date/ time of the schedule for conflict or error. Step 4： ： ： ： After finishing all setup, press the “SAVE” button, and a pop-up window will appear. Select the path, then click the “SAVE”...

  • Page 10: Optional Auxiliary Equipment

    9. OPTIONAL AUXILIARY EQUIPMENT 10. TROUBLESHOOTING 9.1 IR CABLE Situation Check Point The IR cable is an external remote control receiver. 1. Check if the power supply is connected. No Picture 2. Make sure the MPL020 S is turned on. No response from 1.

Table of Contents
