- Page 1 S105M 5-Port Fast Ethernet Switch S108M 8-Port Fast Ethernet Switch Rev:1.0.0 7107500001...
-
Page 2: Package Contents
Make sure that the box contains the above items. If any of the listed items are damaged or missing, please contact with your Chapter 1 Introduction of the Product Thank you for choosing the S105M/S108M Fast Ethernet Switch. 1.1 Overview of the Product S105M/S108M Fast Ethernet Switch provides 5/8 10/100Mbps Auto-Negotiation RJ45 ports. -
Page 3: Chapter 2 Installation
The S105M/S108M Fast Ethernet Switch provides you with a low-cost, easy-to-use, high-performance, seamless standard upgrade to improve your old network to a 100Mbps network. It will boost your network performance up to full duplex data transfer. Its wire-speed switching that forwards packets can be as fast as the speed that your network delivers those packets to them. -
Page 4: Chapter 3 Identifying External Components
Chapter 3 Identifying External Components This Chapter describes the front panel, rear panel and LED indicators of the Switch. Front Panel Figure 3-1 S105M Front Panel Figure 3-2 S108M Front Panel The Switch’s LEDs are located on the front panel:... - Page 5 It flashes when data is being transmitted or received on the connection. Rear Panel Figure 3-3 S105M Switch Rear Panel Figure 3-4 S108M Switch Rear Panel The following parts are located on the rear panel: Power: The Power socket is where you will connect the power adapter.
-
Page 6: Appendix A: Specifications
Appendix A: Specifications General IEEE802.3 10Base-T, IEEE802.3u Standards 100Base-TX, Topology Star Protocol CSMA/CD Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex) Data Transfer Rate Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex) 10Base-T: UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω... -
Page 7: Appendix B: Troubleshooting
Environmental and Physical Operating Temperature 0 ~40℃ (32 ~104℉) Storage Temperature -40 ~70℃ (-40 ~158℉) Operating Humidity 10%~90% non-condensing Storage Humidity 5%~90% non-condensing Appendix B: Troubleshooting The Power LED is not lit Check to see if the power cord is connected to the Switch properly, and make sure the power source is ON. -
Page 8: Fcc Statement
No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from MERCURY TECHNOLOGIES CO., LTD. Copyright © 2009 MERCURY TECHNOLOGIES CO., LTD. All rights reserved. http://www.mercurycom.com.cn... -
Page 9: Ce Mark Warning
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •... -
Page 10: Technical Support
Technical Support MERCURY (SHENZHEN) COMMUNICATION TECHNOLOGIES CO.,LTD. http://www.mercurycom.com.cn B301, Shenzhen Tsinghua University Research institute, Hi-tech industrial Park, Shennan Road, Shenzhen, P.R.China Supports: support@itmercury.com...
