Kikusui PLZ164WH Setup Manual

ELECRONIC LOAD PLZ-4WH Series
PLZ164WH
PLZ334WH
PLZ1004WH
The PLZ-4WH Series Electronic Load is a multifunctional system
designed to offer the highest levels of reliability and safety. The
electronic load contains a stable and high-performance current-con-
trol circuit that enables high-speed load simulations. In addition, its
CPU control feature works to improve operability and multifunctional
capability. The high-precision current settings provide you with suf-
ficient resolution. Because the electronic load comes standard with
GPIB, RS232C, and USB communication functions, it can be easily
incorporated into a wide range of test and inspection systems.
Checking the Package Contents
When you receive the product, check that all accessories are in-
cluded and that the product and accessories have not been dam-
aged during transportation. If any of the accessories are damaged
or missing, contact your Kikusui agent or distributor. We recommend
that all packing materials be saved, in case the product needs to be
transported at a later date.
Accessories
The power cord that is provided varies depending on the
destination for the product at the factory-shipment.
or
Plug: CEE7/7
Plug: NEMA5-15
Rating: 250 Vac/10 A
Rating: 125 Vac/10 A
[85-AA-0005]
[85-AA-0004]
Power cord (1 pc.)
[P2-000-228]
[Q1-500-085]
Load input terminal cover (1 pc.)
Load input terminal cover screws
(2 pc.)
Quick Reference
(Japanese 1sheet, English 1sheet)
Setup Guide
(This guide; 1 pc.)
CD-ROM (1 pc.)
PLZ-4WH
PART NO. Z1-004-970, IB021883
Oct. 2015
or
Plug: GB1002
Rating: 250 Vac/10 A
[85-10-0790]
[M1-100-012]
[M5-101-007]
[M4-100-007]
Set of screws for the load
input terminal (2 pairs)
About the Manuals
The manuals for the PLZ-4WH Series include the Setup Guide (this
guide), the Quick Reference, the User's Manual, and the Communi-
cation Interface Manual.
The manuals are intended for users of the PLZ-4WH Series Elec-
tronic Load and their instructors. Explanations are given under the
presumption that the reader has knowledge of electronics and elec-
tronic loads.
Setup Guide (This guide)
•
This guide is intended for first-time users of the product. It gives
an overview of the product, connecting procedures, safety precau-
tions, etc. Please read through and understand this guide before
operating the product.
• Quick Reference
The quick reference briefly explains the panel description and the
basic operation of the product.
User's Manual (PDF)
•
This manual provides an overview of the product, notes on usage,
and specifications and explains how to connect the product, con-
figure the product, operate the product, perform maintenance on
the product, and so on.
• Communication Interface Manual (HTML, PDF)
This manual explains the remote control feature.
Interface manual is written for readers with sufficient basic knowl-
edge of how to control instruments using a personal computer.
PDF and HTML files are included in the accompanying CDROM.
Adobe Reader 9.2 or later is required to view the PDF files. Micro-
soft Internet Explorer 9 or later is required to view the HTML files.
This manual has been prepared with the utmost care; however, if
you have any questions, or note any errors or omissions, please
contact Kikusui distributor/agent.
If you find any incorrectly arranged or missing pages in manual, they
will be replaced. If the manual gets lost or soiled, a new copy can be
provided for a fee. In either case, please contact Kikusui distributor/
agent, and provide the "Kikusui Part No." given on the cover.
After reading, always keep the manual nearby so that you may refer
to it as needed.
KIKUSUI ELECTRONICS CORP.
1-1-3, Higashiyamata, Tsuzuki-ku, Yokohama,
224-0023, Japan
TEL: +81-45-593-0200 Fax: +81-45-593-7571
http://www.kikusui.co.jp/en
Website
The newest version of the operation manual can be downloaded
from Download service of Kikusui website.
