BUTTONS
Time, Alarm
with Snooze,
& Calendar
Indoor/Outdoor
Temperature +
Trends
5 Volt
Adapter
Model: 616-146v2
Atomic Projection Alarm
with Indoor and Outdoor Temperature
Snooze/Backlight
2 "AAA"
Batteries
www.lacrossetechnology.com/support
USB Charge
Port, 1 Amp
Model: 616-146v2
Quick Setup Guide
DC: 090116
Projection
Arm
Rotates 180°
TX141v2
Outdoor
Sensor
2 "AA"
Batteries
Page | 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for La Crosse Technology 616-146v2
Summary of Contents for La Crosse Technology 616-146v2
-
Page 1: Quick Setup Guide
Model: 616-146v2 Quick Setup Guide DC: 090116 Atomic Projection Alarm with Indoor and Outdoor Temperature Snooze/Backlight BUTTONS Time, Alarm Projection with Snooze, & Calendar Rotates 180° Indoor/Outdoor Temperature + Trends TX141v2 Outdoor Sensor 2 “AA” USB Charge Batteries Port, 1 Amp... -
Page 2: Get Started
Note: Day of the week sets automatically. Press the SET/°F/°C button to exit, or wait 20 seconds without pressing buttons to return to the normal time display. FAHRENHEIT/CELSIUS Press the SET/°F/°C button to select Fahrenheit or Celsius temperature display. Model: 616-146v2 www.lacrossetechnology.com/support Page | 2... -
Page 3: Set Time Alarm
Battery Power: Press and release the SNOOZE/LIGHT button to show the projection for 10 seconds. A/C Power: Projection is displayed constantly unless turned off. Note: Projection will not display constantly when operating on battery power. Model: 616-146v2 www.lacrossetechnology.com/support Page | 3... -
Page 4: Usb Charge Port
If the icon is displayed in Outdoor Temperature section, replace batteries in the outdoor sensor. If the icon is displayed in Indoor Temperature section, replace batteries in the projection clock. Battery Icon Model: 616-146v2 www.lacrossetechnology.com/support Page | 4... -
Page 5: Temperature Trend Indicators
After 15 minutes, return to Step 1 under Get Started. POSITION OUTDOOR SENSOR Mount the outdoor sensor on a North-facing wall or in any well shaded area. Under an eave or deck rail is preferred. Model: 616-146v2 www.lacrossetechnology.com/support Page | 5... -
Page 6: Position Projection Alarm
Be aware of electrical wires and plumbing within a wall. This will interfere with RF (radio frequency) signal reception. WARRANTY AND SUPPORT La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship. -
Page 7: Specifications
Alkaline and Lithium batteries Dimensions: 5.23” L x 1.96” W x 4.33” H Projection Alarm: (133 x 50 x 110 mm) 1.57" x 0.79" x 5.12" TX141v2 Sensor : (40 x 20 x 130mm) Model: 616-146v2 www.lacrossetechnology.com/support Page | 7... -
Page 8: Fcc Statement
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions:(1) This device may not cause interference; and(2) This device must accept any interference, including interference that may cause undesired operation of the device. Model: 616-146v2 www.lacrossetechnology.com/support Page | 8...
