Summary of Contents for Ezon SHS-7020
-
Page 3: Product Features
The door can be opened with a card. The door can be opened with the card contained in the product package. ® SHS-7020 model accept MIFARE 13.56MHz ISO14443A type card. SHS-7120 is compatible with most HID Proximity 125KHz cards ®... -
Page 4: Table Of Contents
Table of Contents Product Features Safety Cautions Before Using the Product Product Components..............7 Outdoor Unit Parts ..............9 Indoor Unit Parts ...............10 Replacing the Battery ..............11 Using the Emergency Battery ............12 Using the Emergency Key............13 Basic Functions Opening the Door from Outside with a Password or a Card ....14 Opening the Door from Inside............15 Program Function User Group Management ............16... - Page 5 Additional Functions Setting up and Releasing the Passage Mode (Code 70/71) ....27 Setting up Current Time .............27 Setting up and Releasing the Random Security Function (Code 90~95)................28 Setting up and Releasing the Sound (Code 00~03)......29 Warning Sound/Alarm Sound ............. 30 PC Connection................32 Initialization ................32 Troubleshooting...
-
Page 6: Safety Cautions
Safety Cautions This section contains important information to ensure the user’s safety and prevent potential damage to property. Please read this section carefully and use the product accordingly. Warning, Caution and Note Explained: Warning Information given under this heading is information the user must be aware of to prevent physical harm. - Page 7 Cautions during Installation Do not install the product in the The user shall not install or repair place where the gap between the product without authorization. the door and the frame is 5mm The manufacturer does not assume the responsibility for damage to the product or more.
- Page 8 Cautions during Installationnce Please do not hang on the product or pull it. It can damage the product or cause its malfunction. Cautions during Repair or Maintenance Be sure to correctly match the Replace all batteries immediately poles (+/-) when installing the after they run out of power, and batteries.
-
Page 9: Before Using The Product
Before Using the Product Product Components Outdoor Unit Indoor Unit Cylinder Rose Latch Bolt Strike Cylinder Key Cylinder Emergency Key Retainer USB Cable Access Mgmt. User/Installation 'AA' Batteries (LR6) Card Program CD Manual... - Page 10 Allen - Wrench Indoor Unit Fastening Bolts Strike and Latch Bolts Indoor/Outdoor Unit Fastening Bolts The product components to be used may vary depending on the installation environment.
-
Page 11: Outdoor Unit Parts
Outdoor Unit Parts Keypad On Keypad Keypad Off [Wake Up] Button Card Reader USB Cable Connector Outdoor Handle Emergency Key Hole External Power Contact Name Function Description Keypad The code is entered in the program mode, or the password is input. [Wake Up] Button The keypad is lighted so that the password can be entered or input of card can be read. -
Page 12: Indoor Unit Parts
Indoor Unit Parts Battery Cover [Register] Button Indoor Handle Name Description Battery Cover It is the cover that protects batteries and the [Register] button. [Register] Button The button is used to run in program mode or to release the warning sound. -
Page 13: Replacing The Battery
Replacing the Battery 1. Battery Replacement Alarm Generation It is time to replace the battery if the low voltage warning sound is activated before the “For Elise” door is opened with a password or a card. Battery Use The actual life of the batteries can differ from the manufacturer, date of manufacturing and operating environment. -
Page 14: Using The Emergency Battery
Using the Emergency Battery 1. When Lock Fails to Operate Due to Discharged AA Batteries If the batteries are not replaced after their replacement time comes, they will be completely discharged and the doorlock will not operate. Password Entry Card Recognition The door is not opened. -
Page 15: Using The Emergency Key
Using the Emergency Key The emergency key is used when the unit stops operating due to the discharged batteries or other circuit problems. Insert the emergency key into the emergency key hole on the outdoor handle and rotates it left and right to unlock the door. - Make sure to keep or carry one or more emergency key. -
Page 16: Basic Functions
Basic Functions This section describes the ways to initialize the information registered in the doorlock, to register the password and card data, and to open or close the door. Opening the Door from Outside with a Password or a Card 1. -
Page 17: Opening The Door From Inside
3. Entering the Password (When the random security function is activated) Successful: "Too~~t” Failed: "Toot~" Touch all randomly displayed numbers and enter the password before pressing the button. - Please refer to the section for ‘Random Security Function Setup and Release’... -
Page 18: Program Function
User Group Management SHS-7020/7120 allows the registration of password and card data for each user group. Up to 250 user codes can be grouped. Either a password or card data can be registered for each user. -
Page 19: Functional Setup Or Release Summary
Functional Setup or Release Summary Setup or Release Ref. Code Function (Follow the steps in the exact sequence.) Page Press the [Initialization] button on the indoor unit. Initialization Input the current master password or '1470852369'. (Complete removal Press the [ ] button. of all passwords ※... -
Page 20: Program Mode
Program Mode The user data can be registered, changed or deleted by entering the code in the doorlock after making it the Program Mode. 1. Pressing the [Register] Button (from inside) Toot Open the battery cover of the indoor unit and press the [Register] button. -
Page 21: Changing The Master Password (Code 10)
Changing the Master Password (Code 10) A master password can be 4~12 digits. Attention must be paid to security since there is no control in doorlock configuration as well as user data registration and removal must be after authenticating the master password. Please register a new master password after initializing the doorlock. -
Page 22: Registering The User Password (Code 20)
Registering the User Password (Code 20) The user password can be 4~12 digits. Up to 250 codes can be registered, including the card registration. 1. Entering the Code in the Program Mode Toot, toot When the LED numbers 1, 2 and 3 flash after the program mode is run, press the code 20 and then the [ ] button. - Page 23 4. Registering an Additional Password (optional) Toot, toot When the LED numbers 4, 5 and 6 flash after the password is saved, repeat the steps 2 and 3 within 10 seconds to register the additional passwords. (The program mode is automatically terminated when there is no key entry within 10 seconds.) - To terminate the program mode without registering the additional password, press the [Register] button...
-
Page 24: Registering The Temporary Password (Code 30)
Registering the Temporary Password (Code 30) A temporary password can be registered for one time use. The registered temporary user code and password are deleted after a single use. - A temporary password cannot be in the administrator group. Therefore, the temporary password should be registered in the user code 11 ~ 250. - A temporary password can be used only once. -
Page 25: Registering The User Card (Code 40)
4. Entering an Additional Temporary Password (optional) When the LED numbers 4, 5 and 6 flash after the password is saved, repeat the steps 2 and 3 within 10 seconds to register the additional passwords. (The program mode is automatically terminated when there is no key entry within 10 seconds.) Registering the User Card (Code 40) Either the card enclosed in the product package or ISO 14443 A Type can be registered. - Page 26 3. Placing the Card Too~~t, toot, toot When the LED numbers 7, 8 and 9 flash, place the card to the card reader on the outdoor unit. The card is registered after the sound of ‘Too~~t, toot, toot’. - The unit turns into the user code entry standby mode. 4.
-
Page 27: User Code Activation/Deactivation/Deletion (Code 50~55)
User Code Activation/Deactivation/ Deletion (Code 50~55) It is the function to activate/deactivate/delete the registered user codes individually or in groups. It temporarily allows or disallows the entrance of a particular user or group. 1. Entering the Code in the Program Mode Success: "Too~~t"... -
Page 28: Entrance Control Setup (Code 60~63)
Entrance Control Setup (Code 60~63) The entrance control can be set up or released to the registered user codes individually or in a group. 1. Entering the Code in the program mode Success: "Too~~t" Failure: "Toot~" When the LED numbers 1, 2 and 3 flash after the program mode is run, press one of the following codes and then press the [ ] button. -
Page 29: Additional Functions
Additional Functions Setting up and Releasing the Passage Mode (Code 70/71) The Passage function allows free entrance and exit of the people by maintaining the door unlocked. It is a convenient when the free access is needed. Entering the code in the program mode Valid Entry: "Too~~t"... -
Page 30: Setting Up And Releasing The Random Security Function (Code 90~95)
Setting up and Releasing the Random Security Function (Code 90~95) It lights up a series of random numbers on keypad so that the lighted numbers must be all touched before the password is entered. The feature can enhance the doorlock security. -
Page 31: Setting Up And Releasing The Sound (Code 00~03)
Setting up and Releasing the Sound (Code 00~03) This function allows setting up the sound activated when the keypad is pressed or the door is locked or unlocked. Setting up the sound function Default setting is to activate all sound levels (3 sound level setting). When the LED numbers 1, 2 and 3 flash after the program mode is operated, enter the code 00~03 and then press the [ ] button. -
Page 32: Warning Sound/Alarm Sound
Warning Sound/Alarm Sound Warning Sound Activated (prevention of mischief behavior) It is a function of activating the warning sound and deactivating the unit in case the doorlock is improperly operated from outside. Password and Card Authentication Error Toot~ toot~ (Activated 20 times) Case of using invalid master password, user password or card for 5 times in a row (A warning sound is activated, and the doorlock becomes deactivated for 3 minutes. - Page 33 Releasing the Alarm It is the function of activating the emergency alarm when the outdoor unit of the installed doorlock is forcefully separated. Intrusion Detection Operation Toot~, toot~, toot~ If the outdoor unit is forcefully separated, the alarm sound “toot~, toot~, toot~” is continuously activated.
-
Page 34: Pc Connection
PC Connection Connect the USB cable (A-B Type) to the USB adapter on the outdoor unit and turn the unit into the PC registration mode. In this mode, all user data registered in the doorlock can be downloaded or uploaded. Outdoor unit Initialization All registered administrator and user data are deleted, and the unit is reset default... -
Page 35: Troubleshooting
Troubleshooting Check the following first if the product does not operate properly. Contact the nearest service center if the problem remains unsolved. Power Problem Resolution Reference - Check if the batteries are OK or if they are inserted with the poles in the right places. No power is supplied. - Page 36 Passage Mode Problem Resolution Reference - Check if the Passage mode is set up. The mode is set if the door is locked when the handle on the outdoor unit is turned without any keypad entry. The doorlock is not - The doorlock is improperly installed if it is not Page 27 automatically locked.
-
Page 37: User Code Registration Table
User Code Registration Table User Code Password (4~12 digits) User Name... -
Page 38: Product Specification
Product Specification Item Specifications When using a battery This product accepts 1.5V AA Size battery only(5EA, 7.5V) Voltage When using an external power supply This product accepts our genuine accessory, SHT-PS1250X. For more product information, please contact Seoul Commtech. Emergency Power 9V Battery (6LF22) (Separately purchased) Source Operation Method... -
Page 41: Product Warranty
Product Warranty...
