Summary of Contents for Unwin HS
- Page 1 Wheelchair Accessories Unwin Wheelchair Headrest HS, HM, HL, HXL Patent No: US6761338B2...
- Page 2 Keep the manual in a safe place so that you can refer to it when necessary. If you have any questions about your equipment, please contact Unwin. Once again, thank you for placing your confidence in our products!
- Page 3 Wheelchair Headrest HR Safety Information Limitation of Use General Guidance Before Fitting the Headrest Fitting and Using the Headrest Fitting the Headrest Using the Headrest After Care Equipment Maintenance...
- Page 4 Limitation of Use This headrest is designed to be used only as indicated in the user manual. 2. Unwin cannot be held liable for any injuries sustained or damage to the wheelchair due to any modification made to this device.
- Page 5 Wheelchair Headrest HR Before fitting the headrest Horizontal position of the headrest should be set for occupant comfort within 10mm of head. 2. Height of headrest should be set to centre of occupant’s head. The height of the headrest is set by means of a fixing knob as shown in the diagram. Release of this knob allows the cushion tube to slide up or down.
-
Page 6: Fitting The Headrest
HR Wheelchair Headrest Fitting the Headrest Unfold wheelchair first, using the allen key supplied, loosen M3 bolts, to allow inner tubes to slide freely. Unfasten the M5 bolts, fit brackets onto the curved part of wheelchair push-handles, Inner tube M3 bolt then refasten M5 bolts. - Page 7 HR Wheelchair Headrest Equipment Maintenance Regularly inspect the Headrest for damage, wear or malfunction. If any problems are identified replace it immediately. 2. Upholstery should be cleaned by wiping with a damp cloth and mild detergent. Do not use bleach. The folding action should be free and there should be no interference when folding the wheelchair.
- Page 8 UNWIN Unwin House, The Horseshoe Coat Road, Martock, Somerset Phone: +44 1935 827740 E-mail: sales@unwinsafety.com...
