Predator Engines 62879 Owner's Manual page 8

Fuel Tank Setup Instructions
WARNING! Fuel tank (not included) must be
CARB compliant and designed specifically for
containing gasoline or voids warranty. The tank
must be mounted to a stable mounting frame.
1. Connect a fuel hose (not included) from the
fuel tank to the Fuel Hose Connector, and
secure it in place with a hose clamp. See
Figure F. If possible, incorporate a fuel shutoff
valve (not included) on the fuel hose.
2. Connect a hose to the Fuel Vapor
Inlet on the Air Intake to contain
gasoline vapors. See Figure G.
WARNING! The end user is responsible for
complying with all applicable CARB and EPA
evaporative emissions requirements for the
fuel system. Some areas may have specific
gasoline vapor containment requirements;
comply with local, state, and federal laws.
Battery Setup Instructions
1. Equipment should include a fully charged, lead-
acid 12 volt, 36 Ah battery (not included)
2. To connect equipment solenoid to Engine
Starter, only use cables sized to match
their length according to Table A.
Cable Gauge
(lower gauge numbers
mean thicker cables)
6
4
2
Table A: Minimum Cable Diameters
3. Attach the positive cable from the positive
battery terminal to the outer terminal on the
Starter. Connect cable securely to prevent
disconnection and short circuits. See Figure H.
Page 8
Maximum
Cable Length
5'
7'
12'
For technical questions, please call 1-888-866-5797.
Fuel Hose
Connector
Figure F: Fuel Hose Connector
Air Intake
Figure G: Fuel Vapor Inlet
Starter
positive
Figure H
4. Connect the negative cable securely to one of the
engine mounting bolts. Connect cable securely
to prevent disconnection and short circuits.
5. Coat the terminals and cable ends with
a corrosion-preventive coating.
Fuel Vapor Inlet
ITEM 62879
