Predator Engines 62879 Owner's Manual page 11

6. Remove the M6 x 1 6 Flange Bolts (2) that
attach the Muffler Bracket and Throttle
Assembly (69) to the Engine. See Figure L.
Muffler Bracket
Flange Bolt
Figure L
7. Remove the Muffler Bracket.
8. Unhook the Choke Rod from the
Throttle Assembly. See Figure M.
Choke Rod
Figure M
ITEM 62879
Throttle Assembly
Throttle Assembly
For technical questions, please call 1-888-866-5797.
9. Remove the Throttle Assembly and lay it back
against the Engine. Remove the Governor Springs
from hole D in the Governor Arm. See Figure N.
Governor
Arm
Figure N
10. Rotate the Choke Rod into an upward
facing position. See Figure O.
Figure O
Throttle
Assembly
Governor
Spring
Choke Rod
Page 11
