Aviosys IP Video 9100B User Manual

Hide thumbs Also See for IP Video 9100B:
Table of Contents

Advertisement

Quick Links

IP Video 9100
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP Video 9100B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aviosys IP Video 9100B

Summary of Contents for Aviosys IP Video 9100B

  • Page 1 IP Video 9100 User Guide...

  • Page 2: User Guide

    IP VIDEO 9100 USER MANUAL User Guide IP Video 9100 Manual version: 2.1 Date: June. 30, 2004 - 1 - VER. 2.10,...
  • Page 3 Caution: Any changes or modifications not approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for FCC and CE. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in commercial environment.

  • Page 4: Table Of Contents

    IP VIDEO 9100 USER MANUAL Table of Contents 1. PRODUCT OVERVIEW....................4 ...................... FEATURES 2. PHYSICAL DESCRIPTION ..................5 ........................SPECIFICATION ..................SYSTEM MINIMUM REQUIRNMENT 3. PANEL DESCRIPTION…………………………………………………………………6 ……………………………………………………………………………… FRONT PANEL ……………………………………………………………………………….. BACK PANEL 4. INSTALLATION………………………………………………………………………..7 ........................PREPERATION ....................HARDWARE INSTALLATION SOFTW ....................

  • Page 5: Product Overview

    1. Product Overview IP video 9100 has an IP digital web server inside. With this great gadget you can put up 4 different sources with only one set of IP, for example (live security observing, online education, TV shows, video games and etc) make remote locations immediately accessible through standard web browsers.

  • Page 6: Physical Description

    IP VIDEO 9100 USER MANUAL 2. Physical Description BOX CONTENT IP Video 9100 package content： IP Video 9100 1 x RJ 45 internet line 1 x DC Power adopter (5V, 110~220V) 2 x Composite Cable (RCA jacks) 1 x CD (a. IP Editor program b. User Manual book) 1 x Quick Installation Guide Minimum Requirement ≥300MHz Intel Pentium II and above...

  • Page 7: Panel Description

    3. Panel Description Side Panel: 4 Video Input Back Panel: from left to right: 1. Reset Button 2. DC Power - 5V, 110 ~ 240. 3. Power On / Off 4. Network - RJ 45 5. Video Out - 6 -...

  • Page 8: Installation

    IP VIDEO 9100 USER MANUAL 4. Installation Before using IP Video 9100, follow bellow: Before installation: Reconfirm your package content Prepare a Hub for Internet monitor Electricity 110 ~ 240 V Hardware installation 1. Plug in IP Video 9100 Power 2.
  • Page 9 SOFTWARE INSTALLER After connecting the power and RJ 45 line, following the steps below to install the software. Step 1: Install IP KAM by executes Setup.exe in the CD; choose setup language and the install shield Wizard will help finish the program. - 8 -...
  • Page 10 IP VIDEO 9100 USER MANUAL - 9 - VER. 2.10,...
  • Page 11 Step 2: Then you can see shortcut icon “IP KamVid 1070 “on desktop, click this icon. Note: Be sure that the power is turn on and the RJ45 line is properly connected. Step 3: The KIPEDIT program will detect all the active IP9000s or IP9100s in the same local Ethernet, and display the findings in the window.
  • Page 12 IP VIDEO 9100 USER MANUAL Step 4: Click the one you want to set, its name, IP will be displayed below. You can change its name (please use numbers or letter) or IP (please set in the same subnet as your PC) in the text windows.
  • Page 13 2. For those software that only supported old VFM driver, such as Vidcap and netmeeting, please click install VFM device, then you can get the captured images from IP9000 (you should be the administrator at the first install process) 3. For those not totally compatible with VFM, such as QQ and POPO, you should click remove device button first, then click install VFM device, then you can get the captured images from IP9000.
  • Page 14 IP VIDEO 9100 USER MANUAL 3. Then My WEBCAM will jump up. Please go to “file “ “Preference” “Camera Setting” to select your prefer video to transfer. 4. You can type in appointed IP address (No matter Real IP or Dynamic IP) and confirm by click “Add”...

  • Page 15: Internet Set Up

    5. Network Set up From our Network set up, users can view live video from any where in the world, with just a computer. Click on Network set up: this area is authorized by administrator only. 1. Still IP: Provided by ISP, with this IP you can connect this address from any where in the world.
  • Page 16 IP VIDEO 9100 USER MANUAL 2-1 Enter your user name, password, mail server, mail name (pass word), sender e-mail, and receiver e-mail. 2-2 Choose Save & Dial Now, by using PPPoE it can automatically dial to your ISP, and ISP will provide exact IP address in your mail. - 15 - VER.

  • Page 17: Function

    2-3 Turn off your browser of IP Video 9100 and restart 6. Functions Please refer to all the function on the left side of IP Video 9100 AP; most of its configuration can only be use by Administrator. Functions: 1. IP address 2.
  • Page 18 IP VIDEO 9100 USER MANUAL 7. Configuration: System, User, Motion detection, Network, Channel, and DDNS 8. Right click function: Record, Snap, 3-1. Frequency: indoor, outdoor&50, outdoor&60 3-3: Color Adjust : Brightness Contrast, Saturation, Hue, Sharpness STD –Default color 4. Splits – 4 / 9/ 16 screen 4-1: 4 screen 4-2: 9 screen 4-3:16 screen...

  • Page 19: Motion Detection Function

    Operation Mode: Continues mode: Video will display continues Period – Video will refresh 1 - 60 per millisecond or per second 6. View Log – view which IP has been visiting your Live image Note: View/Log / Camera Window As in View Log, the video will not show on windows, to get the video back Please click Camera Window.
  • Page 20 IP VIDEO 9100 USER MANUAL 7-1 System Setting: Setup Name , Time , show on Windows, 7-1-1 : Camera name, time and date setup Note: maximum 18 English characyters 7-1-2 : Http Port setup : For customer with IP Sharer device can setup the share port Please check the setup in the IP Share device and type the port number in this area.
  • Page 21 7-2. User Management: Can choose user authorization require optional Choose if viewers need a password or not. Yes - Viewers needs a password No - Open to all viewer who logs in to users IP 7-2-2: Add user by adding a username and a password and you can add a current users list.
  • Page 22 IP VIDEO 9100 USER MANUAL 7-3-1: Choose motion detection: Disable - Enable: choose – Low / Mid / High 7-3-1-1: Motion Detection Setup: Fill sender mail and receiver mail. 7-3-1-2: When send to FTP, please fill in its FTP server address, user name, password, account and upload path, and click on Upload images when motion detected.
  • Page 23 9. When right click mouse, it can also use: View Splits Rotate Resolution Image Recording Save picture 9-1 View Resizable: adjust screen size. Actual size: default to original size. Status Bar: show ip address, and screen size. 9-2 Split 1x1, 2x2, 3x3, 4x4 Split to 1,4,9,16 continuous screen 9-3 Rotate Rotate 0...
  • Page 24 IP VIDEO 9100 USER MANUAL Rotate 0 Rotate 180 9-4 Quality: High Medium Clarity Motion 9-5 Resolution 704*576, 640*480, 352*288 320*240, 176*144, 160*120 9-5 Image Recording Record image to JPEG and AVI file. Both format can be recorded in the same time.
  • Page 25 9-5-1 Recording AVI Select save as AVI, and then select the maximum number of frame in each file. Note: If select No limit, it will continue recording until it used up all memory space. 9-6 Save current picture as - Take a snap shot on current images showed on IP Video 9100 8.
  • Page 26 IP VIDEO 9100 USER MANUAL 9. Firmware update User can update the firmware. First, click Firmware update and it will pop up Firmware Update window. Then, click Browser to select the new firmware. At last, click Upload to update the firmware. - 25 - VER.

  • Page 27: Other Functions

    7. Other Functions 1. IP Video 9100 can view 9 different IP at the same time. ８. Authorization In IP Video 9100 factory set up: factory setting Username: administrator Password: 1234 *Is recommended to change its factory setting password and user name 1.

  • Page 28: Administrator

    IP VIDEO 9100 USER MANUAL .基1-1 Adding IP address A. Add in another IP address Please add in a different IP in “ Watching and press enter” Note1: please type in http:// before your IP. Note2: when selecting different views, it will show different IP addresses in Watching.

  • Page 29: Administrator

    Users entered IP Video 9100’s AP, it will automatically request for Administrator’s Password. If user or other visitors don’t have the rights to use Administrator authorization password, press, “CANCEL” to ignore the inquiry. Note: IP Video’s AP confirming Administrator Non-administrator enter “system, user, motion detect, and net work”...

  • Page 30: Caution

    IP VIDEO 9100 USER MANUAL 9. Caution Q 1: I forgot the ID and password for the administrator account, so I cannot log into the Administration Page. A: Make sure IP Video 9100 is powered on and press the “reset” button behind IP video 9100 for at least 10 seconds, to help default camera setting to factory setting.
