Mine Site Technologies MinePhone MP10 Configuration Manual

Hide thumbs Also See for MinePhone MP10:

Advertisement

Quick Links

Download this manual See also: User Manual
......................................................................................................................................
......................................................................................................................................
Mine Site Technologies
MP10 Configuration Guide
v. 1.1-SNAPSHOT
Ref: MP10_CG_1.1-SNAPSHOT
2012-04-22

Advertisement

loading
Need help?

Need help?

Do you have a question about the MinePhone MP10 and is the answer not in the manual?

Questions and answers

Related Manuals for Mine Site Technologies MinePhone MP10

Summary of Contents for Mine Site Technologies MinePhone MP10

  • Page 1 ............................MP10 Configuration Guide v. 1.1-SNAPSHOT Ref: MP10_CG_1.1-SNAPSHOT ............................Mine Site Technologies 2012-04-22...
  • Page 2 Table of Contents ............................Table of Contents ............Introduction .

  • Page 3: Introduction

    1 Introduction ............................The Mine Site Technologies MinePhone MP10 is a Voice over Wireless LAN (VoWLAN) phone designed for use in hazardous environments. It is an integral component in the MST ImPact Coal product suite, allowing for two way voice and text communication over underground wireless networks.

  • Page 4: Charger Installation

    ............................The MinePhone is supplied with a charging block that the handset is placed within to initiate charging. MinePhone MP10 in charging block Correctly setting up a charger for the MinePhone requires consideration of a suitable location, and ensuring power is correctly connected.
  • Page 6 2 C h a r g e r I n s t a l l a t i o n 2.3 Indicators The charger has one LEDs on the top to indicate status. Showing Meaning Charging in progress Green Charging completed successfully Neither Phone not in charger / Charger not connected to power / A problem has occurred during charging...

  • Page 7: Phone Configuration

    3 P h o n e C o n f i g u r a t i o n 3 Phone Configuration ............................MinePhones are designed to be deployed as a fleet with centralised management software, which reduces the configuration complexity operators are exposed to. Phones will by default attempt to connect to a TFTP server and download site and device specific configuration files at startup.
  • Page 8 3 P h o n e C o n f i g u r a t i o n 3.2 User Configurable Settings The majority of settings for the phone are site specific and are managed centrally. Users may however adjust volume and screen brightness during operation.
  • Page 9 3 P h o n e C o n f i g u r a t i o n Settings configuration option in the main menu Setting Value Notes Backlight Menu select: 10s, 30s, 60s, Always Defines how long the backlight will stay on without input, default is 30s Backlight Brightness Menu select: 5%, 10%, 20%, 40%,...
  • Page 10 3 P h o n e C o n f i g u r a t i o n DHCP Enabled To assist with commissioning of new phones, it is suggested that sites have a Wireless Access Point configured with the above network settings in a convenient location. This allows for new handsets to be turned on in range of this Access Point (AP) and retrieve the mine's specific network settings.
  • Page 11 3 P h o n e C o n f i g u r a t i o n 3.4.1 AP Config The AP Config settings define the wireless network the handset will attempt to connect to. Field Values Notes SSID String of up to 32 ASCII characters The phone will scan channels 1,6,...
  • Page 12 3 P h o n e C o n f i g u r a t i o n SIP Register Duration String of up to 5 digits Seconds duration between registrations, default is 120 3.4.2.2 RTP Real-time Transport Protocol settings. This settings here are specific to RTP as used by the Push to Talk functionality, and should be consistent across all phones in a fleet.
  • Page 13 3 P h o n e C o n f i g u r a t i o n Tracker Mode Menu select: Enable, Disable Default is Enabled Tracker Server Server name or IP address 3.4.3 Internet Protocol Allows for the setting of the phone's IP address via either DHCP, or manually. field Values Notes...
  • Page 14 3 P h o n e C o n f i g u r a t i o n PTT Status when Keylocked Menu select: Enabled, Disabled Defines whether the PTT button will still work if the phone has been keylocked, default is Enabled Default Settings Select to restore all Advanced...
  • Page 15 3 P h o n e C o n f i g u r a t i o n Set Date and Time Adjust using navigation buttons Date Format Menu select: Y/M/D, M/D/Y, D/M/Y Time Format Menu select: 12h, 24h Default is 12h Language Menu select: English, Chinese...

  • Page 16: Maintenance

    4 M a i n t e n a n c e 4 Maintenance ............................The MinePhone is an important communication device that is relied upon for safety and productivity. As such it should be treated with care and regularly maintained. 4.1 Pre-Use Inspection Before taking a MinePhone into a hazardous environment, it is the responsibility of the user to ensure that the hardware appears fit for use.
