Summary of Contents for Portsmith PSA5BT1E
-
Page 1: User Guide
Bluetooth to Ethernet Adapter Model PSA5BT1E User Guide Portsmith, LLC 850 East Franklin Rd Suite #401 Meridian, ID 83642 Phone: (208) 888-5813 www.portsmith.com... - Page 2 Copyright© 2015 Portsmith, LLC. All rights reserved. Disclaimer Portsmith, LLC assumes no responsibility for any damage or loss resulting from the use of this user guide. Portsmith, LLC assumes no responsibility for any loss or claims by third parties that may arise through the use of this product.
-
Page 3: Table Of Contents
Bluetooth to Ethernet Adapter User Guide Contents ..........................ONTENTS .......................... 4 NTRODUCTION About the PSA5BT1E Bluetooth to Ethernet Adapter ................4 Box Contents ............................. 4 PSA5BT1E B ..............5 SING THE LUETOOTH TO THERNET DAPTER Connection and LED display layout ......................5 New Installation/Startup .......................... -
Page 4: Introduction
Bluetooth PAN device will have the ability to pair and connect to the PSA5BT1E. The PSA5BT1E is shipped in INSECURE mode, i.e. without a PIN programmed at the factory. The end user installing may deploy the PSA5BT1E in INSECURE or SECURE mode depending on requirements. -
Page 5: Using The Psa5Bt1E Bluetooth To Ethernet Adapter
Using the PSA5BT1E Bluetooth to Ethernet Adapter Connection and LED display layout The PSA5BT1E has two user viewable LED’s for indicating conditions and status for the adapter. Do not confuse these with the amber and green Ethernet activity LEDs below the Ethernet port. Further details are described in the manual. -
Page 6: New Installation/Startup
Since devices do not require a PIN in this mode, it is referred to as INSECURE as any device could request to pair and connect, gaining access to the network . Note: If the PSA5BT1E has been previously set up with PIN and is rebooted or restarted it will retain its programmed PIN. -
Page 7: Set Pin
Bluetooth to Ethernet Adapter User Guide Set Pin After successfully programing the PSA5BT1E with a PIN the device with be in SECURE mode. Device will operate without a PIN, but the use of a PIN is strongly advised. It is possible to reset the PSA5BT1E PIN code subsequently using the Portsmith PortDox Device Manager utility (see below). -
Page 8: Pairing Devices To Psa5Bt1E
6. If the PSA5BT1E is INSECURE no PIN will be asked for 7. If the PSA5BT1E is secure Android will ask for the PIN assigned to the adapter in the set PIN section. 8. If successful Android will show that the PSA5BT1E and hand-held are paired 9. -
Page 9: Connection Process
Device successfully paired to PSA5BT1E Procedure: 1. Ensure that the devices to connect are within 10 feet /(3M) line of sight to the PSA5BT1E 2. Click settings, Bluetooth 3. Locate the paired PSA5BT1E and click the icon. 4. The devices should connect. -
Page 10: Setup Psa5Bt1E With A Static Ip Address
Portsmith PortDox Device Manager utility installed and running on the Windows PC Procedure 1. Open PortDox Device Manager on the Windows PC 2. Click “List” - PortDox Device Manager will search and list PSA5BT1E’s running on the network 3. A PSA5BT1E will identify itself as “dptaPtBt_XXXXX” 4. Highlight the PSA5BT1E. -
Page 11: Other Product Information
1004. When contacting technical support, please provide the following information: Your name, email address and phone number. Portsmith adapter model and serial number (from the label on the underside of the adapter). Bluetooth equipment model Detailed problem description...
