PCG-SR9G/SR9G / T
SERVICE MANUAL
Illust : PCG-SR9G
9-872-097-41
International Model
S400
NOTEBOOK COMPUTER
Advertisement
Table of Contents
Related Manuals for Sony VAIO PCG-SR9G
Summary of Contents for Sony VAIO PCG-SR9G
-
Page 1: Service Manual
International Model S400 Illust : PCG-SR9G This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. NOTEBOOK COMPUTER English Sony Corporation 2000G1605-1 Printed in U.S.A. - Page 2 Caution Markings for Lithium/Ion Battery - The following or similar texts shall be provided on battery pack of equipment or in both the Sony and VAIO are trademarks of Sony. Intel logo and Intel Inside operating and the service instructions.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page CHAPTER 1. REMOVAL 1-1. Flowchart ................. 1-1 1-2. Main Electrical Parts Location Diagram ......1-1 1-3. Removal ................1-2 1. Keyboard Unit, Parm Assy ..........1-2 2. Touch pad, Speaker, SWX-55 Board ....... 1-2 3. -
Page 4: Chapter 1. Removal
CHAPTER 1. REMOVAL 1-1. Flowchart HOUSING POWER DISPLAY MICRO FRAME KEYBOARD (BEZEL) DC FAN ASSY PHONE UNIT ASSY ASSY P1-6 P1-6 P1-7 P1-2 P1-4 P1-4 MAIN BOARD MBX-34 COOLING ASSY ASSY BOARD P1-4 P1-4 P1-5 P1-7 CNX-96 IFX-108 INVERTER PARM ASSY BOARD BOARD UNIT... -
Page 5: Removal
1-3. Removal 1. Keyboard Unit, Parm Assy q; Keyboard Unit 8 Parm Assy 7 FFC (MBX-34-SWX-55) Clip or the like 1 +B 2X6 (X7) Latch (Key) 2. Touch pad, Speaker, SWX-55 Board 7 Escutcheon (Pad) 9 Touch Pad Window MS qf Housing (Parm Rest) Assy 7 FFC (SWX-55-Touch Pad) q;... -
Page 6: Hdd
3. HDD 7 FPC (HDD) 4 Bracket (B) 6 Bracket (F) 1 +B 2X4 3 +P 3X4 (X2) 8 HDD 5 +P 3X4 (X2) 4. Speaker, IFX-109 Board 1 +B 2X4 (X2) 5 IFX-109 7 +B 2X4 (X2) Board 4 FFC (10p) 8 Speaker Holder 9 Speaker 0 Duct (L) -
Page 7: Dc Fan, Heatsink
5. DC Fan, Heatsink 5 +B 2X6 (X2) qa +B 2X4 (X4) 9 +B 2X4 6 Heatsink NT 0 Escutcheon (LB) 8 DC Fan qs Cooling (1) 1 Blind, Screw (X2) 2 +B 2X6 (X2) qd Bushing (FAN) 3 +B 2X6 (X2) 4 Frame Assy 6. -
Page 8: Mbx-34 Board, Ifx-108 Board, Ddc-2 Board V/L Rechargeable Battery
7. MBX-34 Board, IFX-108 Board, DDC-2 Board, V/L Rechargeable Battery Order of releasing the 8 Nut M2 SO-DIMM A → C qs MBX-34 Board 4 Hex Screw (MBX) Memory Module 3 IFX-108 Board 2 Insulator IFX-108 qa V/L Rechargeable Battery 9 Hex Screw (MBX) 1 +B 2X4 7 DDC-2 Board... -
Page 9: Display Assy
9. Display Assy 3 +B 2X4 6 Display Assy 4 +B 2.6X4 (X2) 2 +B 2X4 10. Housing (Bezel) Assy 1 Cover (Screw)(X2) 2 +B 2X4 (X2) Three Claws 3 Cover (Screw)(X2) Two Claws 4 +B 2X4 (X2) 6 Cover (Screw) 5 Housing (Bezel) Assy Two Claws 7 +B 2X4... -
Page 10: Inverter Unit, Anl-22 Board, Microphone, Lcd Assy
11. Inverter Unit, ANL-22 Board, Microphone, LCD Assy qs +B 2.6X2.5 (X2) qf LCD Assy qs +B 2.6X2.5 (X2) 1 Holder (Microphone) qh +B 2X4 (X2) 4 +B 2X4 ql Tilt (L) qg +B 2X4 3 Electret Condenser qk Bushing Microphone 5 Bushing (PC Board) 7 ANL-22 Board... -
Page 11: Chapter 2. Self Diagnostics
CHAPTER 2. SELF DIAGNOSTICS 2-1. Precautions This self-diagnostic material summarizes the items to be checked and the self-tests to be performed using the main unit, FDD & CD-ROM drives, and port replicator. 2-2. Necessary Tools • PCG-SR series main unit •... -
Page 12: Outline Of Service Diagnostics Functions
2-4. Outline of Service Diagnostics Functions • Check ROM Information... Displays the model information, serial number, BIOS and other information saved in the BIOS ROM. Does not test whether or not the personal computer is normal. • Battery test... Tests the battery as to whether the battery is attached or removed, the main power is supplied from an AC power adapter or not, and the battery is charged or discharged. - Page 13 • Main Memory test... Tests the main memory. The Main Memory test contains the following three test menus. Select the desired menu that suits your need. The test is exited automatically when the respective test items end normally. • Fast: Tests once.
- Page 14 • IEEE 1394 Interface test... Performs the 1394 communication test. Another personal computer to communicate with is necessary for this test. The models released from the year 2000 have already been confirmed that they do not cause any problems regarding the IEEE1394 interface.
-
Page 15: Chapter 3. Block Diagram
CHAPTER 3. BLOCK DIAGRAM PCG-SR Series Block Diagram CPU core Power Supply µ DIMM PentiumIII 443ZX-100M 10.4” (2slot) Inverter Internal MIC Clock Temp sensor Cooling FAN PCI bus LCD CN PCcard PIIX4M NeoMagic YAMAHA i.LINK Snowy R5C475II YFM754 Memory MS CN PCcard Stick Modem... -
Page 16: Chapter 4. Frame Harness Diagram
CHAPTER 4. FRAME HARNESS DIAGRAM DISPLAY ASSY LCD HARNESS BATTERY PACK INVERTER KEYBOARD ANL-22 BOARD Rear (SIDE A) CN1502 CN3300 CN3301 Side Side CN351 DC IN MBX-34 MODULER IFX-108 JACK CN901 BOARD BOARD CN5002 (SR9G/T Model) (SIDE A) (SIDE A) i-LINK CN401 CN3151... -
Page 17: Chapter 5. Exploded Views And Parts List
CHAPTER 5. EXPLODED VIEWS AND PARTS LIST Ref.No. Part No. Description Ref.No. Part No. Description 4-646-973-01 DUCT (L) A-8056-816-A SWX-55 COMPL 1-529-660-21 SPEAKER, (2.0CM) * 33 4-647-538-01 COOLING (1) NOTE: 4-644-492-31 ACE (M2X4), LOCK 1-792-891-11 FFC (MBX-34-SWX-55) • The mechanical parts with no reference number in the X-4622-725-1 ESCUTCHEON (LF) ASSY 4-648-320-11 TAPPING (M2) The components identified by mark 0 or... -
Page 18: Lcd Section - Made By Ts
5-2. LCD Section – Made by TS – Ref.No. Part No. Description Ref.No. Part No. Description 4-646-977-01 BLIND (LCD), SCREW ACCESSORIES 4-644-492-31 ACE (M2X4), LOCK ************ X-4622-698-2 HOUSING (BEZEL) ASSY A-8045-747-A LCD UNIT (10.4XGA) (S) 1-555-074-31 CORD, POWER 4-646-705-02 TUBE, TOP 1-575-131-61 CORD, POWER 1-757-026-11 CABLE, VGA 4-646-703-01 KNOB (LATCH) -
Page 19: Appendix
PCG-SR9G / SR9G / T APPENDIX... - Page 20 TABLE OF CONTENTS Section Title Page CHAPTER 1. SPECIFICATIONS ......... 1-1 CHAPTER 2. OVERVIEW 2-1. Locating Controls and Connectors ........2-1 CHAPTER 3. SERVICE INFORMATION 3-1. Install Procedure after the Hard Disk is Replaced ..... 3-1 — 2 — PCG-SR9G SR9G/T (I)
-
Page 21: Chapter 1. Specifications
CHAPTER 1. SPECIFICATIONS Extracted from PCG-SR9G Series User Guide (4-647-720-11 (1)). LCD display mode Specifications 1024 × 768 dot (approx. 16,770,000 colors.) 800 × 600 dot (approx. 16,770,000 colors.) 640 × 480 dot (approx. 16,770,000 colors.) Processor based on graphic accelerator dithering ®... - Page 22 Storage humidity PC card slot 10% to 90% (not condensed), provided that humidity is less than 20% at 140°F (60°C) Type I/ II, Cardbus compatible (1) (hygrometer reading of less than 95°F (35°C)) Dimensions Memory Stick slot Approx. 259 × 23.7-32.1 × 209 mm (W × H × D) 10pin (1) Weight Approx.
- Page 23 Battery Output voltage 11.1V, 3,600 mAh Operating temperature 41°F to 95°F (5°C to 35°C) (temperature gradient less than 18°F (10°C)/hour) Operating humidity 20% to 80% (not condensed), provided that humidity is less than 65% at 95°F (35°C) (hygrometer reading of less than 84°F (29°C)) Storage temperature -4°F to 140°F (-20°C to 60°C) (temperature...
-
Page 24: Chapter 2. Overview
CHAPTER 2. OVERVIEW 2-1. Locating Controls and Connectors Extracted from PCG-SR9G Series User Guide (4-647-720-11 (1)). Locating Controls and Connectors Refer to the pages indicated in parentheses for related information. Front 1 1 Power indicator (page 16) 9 LCD Screen (page 30, 61) Battery indicator q;... - Page 25 Left DC IN connector (page 15) 2 Air vent External display connector USB connector 5 MEMORY STICK slot 6 MEMORY STICK eject button PCG-SR9G SR9G/T (I)
- Page 26 Right 1 i Headphone connector S400 i.LINK (IEEE1394) connector 2 m Microphone / o Line in connector Modular connenctor (PCG-SR9G/T only) 3 Jog Dial control 4 PC card eject button 5 PC card slot PCG-SR9G SR9G/T (I)
- Page 27 Back 1 Battery connector Bottom 1 Battery lock lever (page 14) 2 Battery release lever 3 Air vent PCG-SR9G SR9G/T (I) (END)
-
Page 28: Chapter 3. Service Information
• If you recover the hard disk, it means that you remove all the data on the hard disk drive. Before you start to recover, create the backup copy of important data. • The second Sony Product Recovery CD-ROM (Vol.2 of 2) contains software drivers and others. It is not required for reconfiguring your computer. - Page 29 See “ Using the CD-ROM Drive” in the online manual for details. CD-ROM drive PCGA-CD51 Series To PC card slot (optional) SONY logo side Connect the AC adapter to your computer. Power switch AC adapter DC IN To AC wall oulet...
- Page 30 When the recovery is complete, follow the screen messages to shut down your computer, then restart it. The second Sony Product Recovery CD-ROM (Vol.2 of 2) contains software drivers and others. It is not required for reconfiguring your computer. PCG-SR9G...
