Summary of Contents for Sony PCG-SR27K Primary
-
Page 1: Service Manual
PCG-SR27/SR27K SERVICE MANUAL US Model Canadian Model S400 Illust : PCG-SR27K Includes PCG-SR33/SR33K Difference Manuals NOTEBOOK COMPUTER 9-872-215-11... - Page 2 Information in this document is subject to change without notice. Sony and VAIO are trademarks of Sony. Intel logo and Intel Inside logo are registered trademarks of Intel Corporation. Pentium MMX is a trademark of Intel Corporation. Microsoft, MS-DOS, Windows, the Windows 95 and Windows 98 logo are trademarks of Microsoft Corporation.
-
Page 3: Table Of Contents
Section Title CHAPTER 1. REMOVAL 1-1. Flowchart ... 1-1 1-2. Main Electrical Parts Location Diagram ... 1-1 1-3. Removal ... 1-2 1. Keyboard Unit, Parm Assy ... 1-2 2. Touch pad, Speaker (R), SWX-61 Board ... 1-2 3. HDD ... 1-3 4. -
Page 4: Chapter 1. Removal
1-1. Flowchart POWER KEYBOARD PARM ASSY P1-2 TOUCH PAD SPEAKER (R) • P XX means pages that appears in this manual. • Remember that hard disk drives are easily damaged by vibration. Always handle with care. 1-2. Main Electrical Parts Location Diagram Keyboard Unit V/L Rechargeable Battery Speaker... -
Page 5: Removal
1-3. Removal 1. Keyboard Unit, Parm Assy 8 Housing (Parm Rest) Assy 7 FFC (MBX-34-SWX-55) 1 Lock Ace (M2X6) (X7) (Silver) 2. Touch pad, Speaker (R), SWX-61 Board Window MS ql Housing (Parm Rest) Assy 7 FFC (MBX-34-SWX-55) 4 Tapping Screw (M2X4) (Black) q;... -
Page 6: Hdd
3. HDD 6 Bracket (F) 5 Screw (M3X4) 4. Speaker (L), IFX-125 Board 7 Lock Ace (M2X3.5) (X2) (Gold) 8 Shield MS 9 Speaker Holder q; Speaker qa Duct (L) 7 FPC (HDD) 4 Bracket (B) 1 Lock Ace (M2X3.5) (Gold) 3 Screw (M3X4) (X2) (Gold) 8 HDD (X2) (Gold) -
Page 7: Frame Assy, Dc Fan, Cooling
5. Frame Assy, DC Fan, Cooling qd Lock Ace (M2X3.5) (X4) (Gold) 7 Lock Ace (M2X3.5) (Gold) qa Lock Ace (M2X3.5) (Gold) 6 +BTP 2X6 (X2) (Black) qs Escutcheon (LB) 8 Heatsink NT2 qf Cooling (1) q; DC Fan 1 Blind, Screw (X2) qg Bushing (FAN) 2 Lock Ace 4 Claw... -
Page 8: Board, Ifx-124 Board, Ddc-3 Board V/L Rechargeable Battery
7. MBX-44 Board, IFX-124 Board, DDC-3 Board, V/L Rechargeable Battery Order of releasing the SO-DIMM A → C q; Hex Screw (MBX) (Silver) 8 Insulator (MBX) 7 DDC-3 Board 5 Lock Ace (M2X2.5 Special Flat) (Silver) 6 Insulator DDC-2 8. CNX-107 Board 3 FFC (MBX-34-CNX-96) 5 CNX-107 Board 6 Lock Ace (M2X3.5) (Gold) -
Page 9: Display Assy
9. Display Assy 3 Lock Ace (M2.6X4) (Silver) 7 Display Assy 4 Lock Ace (M2.6X4) (X2) (Silver) 5 Plate 2 Lock Ace (M2X3.5) (Gold) Confidential PCG-SR27/SR27K (UC) -
Page 10: Lcd Section - Made By Ts
10. LCD Section – Made by TS – 1. Housing (Bezel) Assy 2 Lock Ace (M2X4) (X2) (Silver) Two Claws 6 Screw Blind 7 Lock Ace (M2X4) (Silver) 8 Cover (L) 2. Microphone, LCD Assy, Inverter Unit, ANL-24 Board qs +B 2.6X2.5 (X2) (Gold) qh Lock Ace (M2.6X4) (X2) (Silver) qg Lock Ace... -
Page 11: Chapter 2. Self Diagnostics
CHAPTER 2. SELF DIAGNOSTICS ATTENTION Please confirm “Self Diagnostics” method which will be informed you with distribution of “Self Diagnostics” software. Confidential PCG-SR27/SR27K (UC) (END) -
Page 12: Chapter 3. Block Diagram
CHAPTER 3. BLOCK DIAGRAM PCG-SR Series Block Diagram µ Mother PWB Large IC Cooling LCD unit INT CN EXT CN Sub PWB User I/F UNIT Confidential PCG-SR27/SR27K (UC) (END) -
Page 13: Chapter 4. Frame Harness Diagram
FRAME HARNESS DIAGRAM Side KEYBOARD DC IN CN502 CN3151 DDC-3 BOARD (SIDE A) CN351 DISPLAY CN1902 MEMORY CN2101 CN1901 STICK (CN2203) IFX-125 BOARD (SIDE A) SPEAKER CHAPTER 4. DISPLAY ASSY ANL-24 BOARD (SIDE A) LCD HARNESS INVERTER CN3300 CN3301 CN301 MBX-44 IFX-124 CN901... -
Page 14: Chapter 5. Exploded Views And Parts List
NOTE: • The mechanical parts with no reference number in the exploded views are not supplied. • Items marked “ * ” are not stocked since they are seldom required for routine service. Some delay should be anticipated when ordering these items. •... -
Page 15: Main Section
5-1. Main Section Ref.No. Part No. Description 4-646-973-02 DUCT (L) 1-529-660-21 SPEAKER, (2.0CM) 4-644-492-31 ACE (M2), LOCK 4-644-492-51 ACE (M2), LOCK X-4622-725-2 ESCUTCHEON (LF) ASSY 4-650-469-01 FOOT X-4623-153-1 HOUSING (BOTTOM) ASSY 4-650-608-01 LID (HEAT) (A) 4-647-207-01 BUSHING (FAN) 4-644-493-11 ACE (M2.6), LOCK 4-635-956-01 SPRING (B), COMPRESSION COIL 4-647-535-01 INSULATOR RJ-11 1-794-537-11 HARNESS, MODULAR... - Page 16 Included in 57 Included in 9 Supplied with 9 Included in 9 Confidential PCG-SR27/SR27K (UC)
-
Page 17: Lcd Section - Made By Ts
5-2. LCD Section – Made by TS – Confidential PCG-SR27/SR27K (UC) Ref.No. Part No. 4-646-977-01 BLIND (LCD), SCREW 4-644-492-31 ACE (M2), LOCK X-4623-481-1 HOUSING (BEZEL) ASSY A-8045-747-A LCD ASSY (S) 4-646-705-02 TUBE, TOP 4-646-703-01 KNOB (LATCH) 4-639-890-01 SCREW (+B M2.6X2.5) 4-646-704-02 LEVER (LATCH) 4-635-923-01 HOLDER (MICROPHONE) 1-542-402-21 MICROPHONE, ELECTRET CONDENSER... -
Page 18: Vaio ® Notebook Quick Start
® VAIO Notebook Quick Start PCG-SR27/PCG-SR27K Includes PCG-SR33 Update Notice... - Page 19 Contents Welcome ...5 Features... 5 Unpacking Your Notebook... 6 Notes on Use ... 7 Setting Up Your VAIO Locating Controls and Connectors ... 11 Connecting a Power Source ... 14 Starting Your Notebook ... 20 Registering Your Notebook ... 21 Shutting Down Your Notebook ...
- Page 20 ® VAIO Notebook Quick Start Troubleshooting ... 51 Troubleshooting Your Notebook ...51 Troubleshooting the LCD Screen ...55 Troubleshooting the Mouse and Touchpad ...56 Troubleshooting Drives, PC Cards, and Peripheral Devices ...57 Troubleshooting Software...59 Troubleshooting the Modem ...60 Troubleshooting Audio...61 Troubleshooting the Printer ...62 Index ...
-
Page 21: Welcome
Portability — The high-capacity lithium-ion battery provides hours of use without AC power. ❑ Sony audio and video quality — High-quality MPEG1 digital video, which supports full-screen display (10.4-inch Active Matrix LCD screen) and enables you to take advantage of today’s advanced multimedia applications, games, and entertainment software. -
Page 22: Software Cds
Specifications — Details the hardware specifications for your notebook. Software CDs ® ❑ Microsoft Word 2002 — Allows you to reinstall Microsoft Word 2002 to the Sony computer you purchased. Power Cord Optical Drive ® Millennium Edition Getting Started document AC Adapter... -
Page 23: Ergonomic Guidelines
Recovery CDs ❑ Application Recovery CD(s) — Enables you to reinstall individual applications if they become corrupted or erased. ❑ Driver Recovery CD(s) — Enables you to reinstall individual device drivers. Use it to restore corrupted or erased device drivers. ❑... -
Page 24: Setting Up Your Notebook
® VAIO Notebook Quick Start ❑ Lighting — Choose a location where windows and lights do not create glare or reflection on the display. Use indirect lighting to avoid bright spots on the display. You can also purchase accessories for your display that help reduce glare. - Page 25 ❑ Do not place electronic equipment near your notebook. The notebook’s electromagnetic field may cause a malfunction. ❑ Provide adequate air circulation to prevent internal heat build-up. Do not place your notebook on porous surfaces such as rugs or blankets, or near materials such as curtains or draperies that may block its ventilation slots.
- Page 26 If the notebook is brought directly from a cold location to a warm one, moisture may condense inside your notebook. In this case, allow at least an hour before turning on your notebook. If any problems occur, unplug your notebook, and contact your Sony Service Center.
-
Page 27: Setting Up Your Vaio Notebook
Setting Up Your VAIO Notebook This section describes the controls and connectors on your VAIO Notebook, how to connect your notebook to a power source, and how to start and shut down your notebook Locating Controls and Connectors Front Power Indicator Battery Indicator MG Memory Stick Hard Disk Drive Indicator... - Page 28 ® VAIO Notebook Quick Start Back Battery Connector Left DC In Port Air Vent VGA Adapter Port (For Connecting an External Display) USB Port Memory Stick Memory Stick Eject Button ® Media Slot...
- Page 29 (IEEE1394) S400 Port Modem Jack * i.LINK is a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The i.LINK connection may vary, depending on the software applications, oper- ating system, and i.LINK-compatible devices. All products with an i.LINK connection may not communicate with each other.
-
Page 30: Using The Ac Adapter
® VAIO Notebook Quick Start Bottom Battery Lock Lever Battery Release Lever Connecting a Power Source You can use either AC power or a rechargeable battery pack as a power source. Using the AC Adapter Plug the cable attached to the AC adapter into the DC In port on the notebook. -
Page 31: Using Battery Power
Using Battery Power You can use a battery pack as a source of power. The battery pack that comes with your notebook is not fully charged at the time of purchase. Follow the steps below to insert and charge the battery pack. To Insert the Battery Pack You can insert or remove the battery pack without turning off the notebook when your notebook is connected to the AC adapter. - Page 32 ® VAIO Notebook Quick Start To Charge the Battery Pack Connect the AC adapter to the notebook. Insert the battery pack. The notebook automatically charges the battery (the battery indicator light flashes in a double-blink pattern as the battery charges). When the battery is 85% full, the battery indicator light turns off.
-
Page 33: Notes On Power
To Remove the Battery Pack You can insert or remove the battery pack without turning off the notebook when your notebook is connected to the AC adapter. Before inserting or removing a battery pack, close the cover. Turn off the notebook and close the cover. Slide the lock lever to the Slide the release lever to the the notebook. - Page 34 ® VAIO Notebook Quick Start Hardware Temperature ❑ The AC adapter or the bottom panel of your notebook may become warm. This is the result of CPU operation and does not indicate a malfunction of the notebook. The actual temperature varies depending on the peripherals and software you are using and the length of time that the unit is in use.
- Page 35 ❑ Keep the battery pack in the notebook while it is directly connected to AC power. The battery pack continues to charge while you are using the notebook. ❑ If your battery level falls to less than 10%, you should either attach the AC adapter to recharge the battery or shut down your notebook and insert a fully- charged battery.
-
Page 36: Starting Your Notebook
® VAIO Notebook Quick Start Starting Your Notebook Slide the LCD lock lever in the direction of the arrow, and lift the cover. Opening Notebook LCD Lock Lever Slide the power switch to the right until the green power indicator turns on. ✍... -
Page 37: Registering Your Notebook
The notebook automatically transfers your registration information using your built-in modem and a toll-free telephone number or a local number. ✍ You may sign up for Internet access with a Sony preferred Internet Service Provider. Registering Your Notebook... -
Page 38: Shutting Down Your Notebook
® VAIO Notebook Quick Start Shutting Down Your Notebook To avoid potential loss of data, follow these steps to shut down your notebook. Click the Start button on the Windows Click Shut Down at the bottom of the Start menu to display the Shut Down Windows dialog box. -
Page 39: Standby Mode
Power Saving Modes When you use a battery as the source of power for your notebook, you can take advantage of power management settings to conserve battery life. In addition to the normal operating mode, which allows you to turn off specific devices, your notebook has two distinct power saving modes: Standby and Hibernate. -
Page 40: Hibernate Mode
® VAIO Notebook Quick Start Hibernate Mode The state of the system is saved on the hard drive and power is turned off. The power indicator light is off in this mode. To activate Hibernate mode To activate Hibernate mode, press the key combination Fn+F12. ✍... -
Page 41: Notes On Using Power Management
Notes on Using Power Management ❑ If you find that an application exhibits unexpected behavior (such as reduced video quality) after returning from a power saving mode, you should close that application before your notebook enters a power saving mode. ❑... - Page 42 ® VAIO Notebook Quick Start...
-
Page 43: About The Software On Your Notebook
❑ An overview of the various software that come with your notebook and the activities you can perform with your software ❑ Details on your Sony application, driver, and system recovery CDs ❑ Software support information Overview Adobe Acrobat Reader Adobe Systems, Inc. - Page 44 Maximize your time online with CompuServe. ™ DVgate Sony Electronics Inc. Connect a digital video camera recorder to the i.LINK video clips and still images. You can edit the clips from your video, add others, and combine clips into new movie segments.
-
Page 45: Microsoft Internet Explorer
MovieShaker Sony Electronics Inc. Sony’s original MovieShaker software creates personal movies that have transitions, background music and text. Just import your video clips and “shake” with the click of a mouse. Your personal movies are easy to create and fun to share with family and friends. -
Page 46: Openmg™ Jukebox
Using RealJukebox, you can capture the contents of a music CD, manage and playback your music and view various music related information via the Internet. This Custom RealJukebox for Sony allows seamless check-out capabilities to a wide range of Sony personal audio devices and offers convenient links to Sony product and music service homepages. -
Page 47: Vaio Action Setup
VisualFlow™ Sony Electronics Inc. VisualFlow is a state-of-the-art Sony multimedia browser designed specifically for Memory Stick media. It displays any still picture, movie or sound files stored in a Memory Stick media in a visually pleasing, artistic manner. VisualFlow not only plays a selected movie or sound file, but also enables playback of files by other applications like PictureGear, Memory Stick Slideshow and Windows Explorer. -
Page 48: Using Your Recovery Cds
You can also use the Application Recovery CD to install Windows 2000 drivers on your notebook. ✍ You must be in Windows to run the Application Recovery CD. If you have any questions on using the Application Recovery CD, contact Sony Customer Support. ® Notebook you purchased. This CD restores... -
Page 49: Using The Driver Recovery Cd(S)
To use the Application Recovery CD(s) Turn on your notebook. If your notebook is already on, close all applications. When the Windows desktop appears, insert the Sony Application Recovery CD in the optical drive. The Application Recovery utility loads automatically. -
Page 50: Using The System Recovery Cd(S)
Sony Customer Support. To use the System Recovery CD(s) Insert the Sony System Recovery CD in the optical drive. Shut down your notebook as described in “Shutting Down Your Notebook” . Wait four seconds then turn on your notebook. -
Page 51: Recovering Microsoft ® Word 2002
Press the power button and hold it for more than four seconds to turn off the notebook. Turn on the notebook. When the Sony logo is displayed, press the F2 key. The BIOS setup menu screen appears. Press the arrow keys to select the Exit menu. -
Page 52: Software Support Information
® VAIO Notebook Quick Start Software Support Information ® Acrobat Reader, Adobe Photoshop Elements, (Adobe Systems, Inc.) Web site http://www.adobe.com/ phone 206-628-2746 (fee-based support) 206-628-5737 e-mail techdocs@adobe.com hours M-F, 6 AM-5 PM PT ® America Online (America Online, Inc.) Web site http://www.aol.com phone 800-827-3338... - Page 53 * Support from 1-888-4SONYPC is free of charge for 90 days after the original date of purchase. Sony Service Center For the Sony Service Center nearest you, call 1-888-4SONYPC (1-888-476-6972) or find Sony Customer Service on the Web at http://www.sony.com/pcsupport/. Software Support Information ®...
- Page 54 ® VAIO Notebook Quick Start...
-
Page 55: Getting Help
This service, which requires a fax machine or your fax software, provides answers to commonly asked questions. You can use this automated service to request a list of available topics then select the topics that you want to receive. To contact the Sony fax- on-demand service, call:... -
Page 56: Using The Quick Fix Wizard
These diagnostics protect and store information in a retrievable format that enables you to restore your software to a previous working state. Sony has identified the software items that are protected by the VAIO Support Agent utility. - Page 57 To use the Quick Fix Wizard, follow these steps: From the VAIO Support Agent main window, click the Quick Fix Wizard button. The Welcome window appears. Click Next. The “Quick Fix Wizard: Begin VAIO Support Agent Diagnostics” dialog box appears. Select the “Diagnose and fix my software”...
-
Page 58: Using Common Solutions
Common Solutions dialog box (1st level) ✍ Connect to the Internet before attempting to view the category, “Vaio Support Local Server (http://sdcglobal4.sel.sony.com...).” This category is unavailable without an Internet connection. Click the resize arrows next to the SupportAction categories to expand or... - Page 59 Common Solutions dialog box (2nd level) Select the appropriate SupportAction from the list. Click Run or double-click the desired SupportAction. The available SupportActions are shown in bold type. ✍ You cannot undo One-Click Fixes. VAIO Support Agent...
-
Page 60: Using Support Central
® VAIO Notebook Quick Start Using Support Central The Support Central feature uses Internet resources to help you fix your software. Support Central searches the Internet for answers to your questions, additional information from knowledge base systems, and the latest software updates for your protected software. - Page 61 VAIO Support Agent ✍ Support Central retains your registration information, so you are only required to register once. If you log on to your notebook with a different user name or have recovered your system using the System Recovery CDs, Support Central may require you to register again.
- Page 62 ® VAIO Notebook Quick Start Support Central: Current Issues page When you log on to Support Central, the Current Issues page displays, enabling you to continue working on your open issues or to close them if you are finished. Support Central has a tracking feature that stores your current issues, enabling you to return and work on them later.
-
Page 63: About Automatic Updates
About Automatic Updates The VAIO Support Agent is dormant as a background process. Every 24 hours, the Agent self-activates to contact the Sony Support Server to check for new updates or fixes needed for your system. This updating action only occurs while you are connected to the Internet and when more than 24 hours has passed since the last update. - Page 64 You can choose from four response options: ❑ Give the Agent your permission to contact the Sony Support Server for any updates or fixes that are available specifically for your notebook. The Agent continues to prompt you for your permission to retrieve updates.
- Page 65 VAIO Support Agent Properties To control the VAIO Support Agent automatic update feature, follow these steps: In the VAIO Support Agent main screen, select Tools, then select Properties. The VAIO Support Agent Properties dialog box appears. Select one of three options to customize the automatic update feature. Click OK.
- Page 66 ® VAIO Notebook Quick Start...
-
Page 67: Troubleshooting
Troubleshooting This section describes how to solve common problems you may encounter when using your notebook. Since many problems have simple solutions, try these suggestions before you contact Sony PC Support (http://www.sony.com/pcsupport). Troubleshooting Your Notebook (Windows Me only) When starting your notebook for the first time, the VAIO InitManager dialog box will appear. - Page 68 Turn off the notebook. Remove any peripheral devices connected to the notebook. Turn on the notebook. Press the F2 key when the Sony logo appears. The BIOS setup menu screen appears. Press the directional arrow keys to select the Exit menu.
- Page 69 10 Select Yes, then press Enter. The notebook restarts. If your notebook continues to display the message “Operating system not found”, and Windows does not start, contact Sony Customer Support. My notebook stops responding or does not shut down. It is best to shut down your notebook using the Shut Down command on the Windows Start menu.
- Page 70 If you are connecting an optical disc drive with a PC card, disconnect it by stopping the PC card. Use the Sony Notebook Setup utility to disable devices that you are not currently using. See “Removing a PC card” for more information.
-
Page 71: Troubleshooting The Lcd Screen
The sound of my notebook’s fan is too loud. Use the PowerPanel utility to change the Thermal Control Strategy setting to Quiet. This setting slows down the CPU speed. See PowerPanel Help for more information. Troubleshooting the LCD Screen My LCD screen is blank. ❑... -
Page 72: Troubleshooting The Mouse And Touchpad
See “Connecting a Universal Serial Bus (USB) Device” for details. ❑ If you are using an optional Sony USB mouse PCGA-UMS1 series, verify that the mouse is plugged into the USB connector, and restart your notebook. My touchpad does not work properly. -
Page 73: Troubleshooting Drives, Pc Cards, And Peripheral Devices
Troubleshooting Drives, PC Cards, and Peripheral Devices Troubleshooting Drives, PC Cards, and Peripheral Devices My (optional) floppy disk drive can not write to a floppy disk. ❑ If the floppy disk is write-protected, disable the write-protect feature or use a floppy disk that is not write-protected. - Page 74 ® VAIO Notebook Quick Start ❑ Click Start, point to Settings, point to Control panel, then double-click System. The System Properties dialog box appears. ❑ Click the Device Manager tab. ❑ Verify that the correct drivers are installed properly. ❑ Do not use adhesive labels to identify the CD.
-
Page 75: Troubleshooting Software
Use the Sony Notebook Setup utility to disable devices you are not currently using. ❑ If you are using two PC cards, use the Sony Notebook Setup utility to disable the devices you are not currently using. Troubleshooting Software My software program stops responding or crashes. -
Page 76: Troubleshooting The Modem
Verify that the phone number the program is dialing is correct. ❑ Verify that the software you are using is compatible with the notebook’s modem. (All preinstalled Sony programs are compatible.) My modem connection is slow. Your notebook is equipped with a 56K/V.90 compatible modem. Many factors may influence modem connection speed, including telephone line noise or compatibility with telephone equipment (such as fax machines or other modems). -
Page 77: Troubleshooting Audio
Troubleshooting Audio My speakers have no sound. ❑ If the built-in speakers are turned off, press Fn+F3 or use the Jog Dial control to turn on the speakers. ❑ If the speaker volume is turned to the minimum, press Fn+F4, then press ➜... -
Page 78: Troubleshooting The Printer
The default setting for the printer port mode is correct for most printers. If you cannot print, try changing the printer port mode. In Sony Notebook Setup, select the Printer tab. If the printer port mode is set to ECP, change it to bi-directional. -
Page 79: Index
Index AC adapter 14, 17 AC power 14 air circulation 9 Application Recovery CD 32 Batteries 18 battery pack 15, 18 charging 16 connector 12 indicator lights 11, 16 inserting 15 loading 15 power status 16 rechargeable 14 removing 17 battery power 14 brightness adjusting 20... - Page 80 See LCD Scroll Lock 11 selecting power source 14 setting up your PC support 39 Shut Down Windows dialog box 22 Sony Fax-on-Demand service 39 speakers built-in 11 troubleshooting 61 Standby mode 23 Start button 22 starting computer 20...
- Page 81 Using Batteries 18 VAIO Support Agent 40 ventilation 9 Windows 53 Start button 22 taskbar 22 Index...
- Page 83 User Guide installed on your notebook. © 2001 Sony Electronics Inc. Reproduction in whole or in part without written permission is prohibited. All rights reserved. Sony, VAIO, and the VAIO logo are trademarks of Sony. Microsoft and Windows are registered trademarks of Microsoft Corporation.
- Page 84 Reproduction in whole or in part without permission is prohibited. All rights reserved. Sony, VAIO, and the VAIO logo are trademarks of Sony. All other trademarks are trademarks of their respective owners. http://www.sony.com/vaio Printed in USA © 2001 Sony Electronics Inc.
-
Page 85: Notebook Computer
SERVICE MANUAL Lineup : PCG-SR33 Basic performances of PCG-SR33 are the same as those of PCG-SR27. Therefore, this manual describes the differences from PCG-SR27. Refer to the following manual that is already issued for repair and inspection. PCG-SR27/SR27K SERVICE MANUAL (9-872-215-11) COMPARISON OF SPECIFICATIONS Items Mobile Pentium III 750MHz... - Page 86 : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. Sony Corporation — 2 — Published by MNC IT Planning & Control Dept.
- Page 87 SERVICE MANUAL Ver 1-2001J All the supplementary information are attached at the end of data files. Update List Lineup : PCG-SR33K Basic performances of PCG-SR33K are the same as those of PCG-SR27K. Therefore, this manual describes the differences from PCG-SR27K. Refer to the following manual that is already issued for repair and inspection.
- Page 88 9-872-297-01 : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. Information Technology Company Sony Corporation — 2 — Printed in USA...
- Page 89 : Additional Models This manual and the constituent data may not be replicated, copied nor reprinted in whole or in part without prior written authorization of Sony Corporation. Sony Corporation — 30 — Published by MNC IT Planning & Control Dept.
- Page 90 Revision History Suffix Contents QM No. Ver. Date First Ver. 1 2001.10.15 Edition Remarks [Conf i denti al ] SR33K (UC)
