Download this manual See also: Troubleshooting Manual, Supplemental User's Manual
Part No. 060183-10, Rev. D
December 2004
OmniSwitch 8800
Hardware Users Guide
www.alcatel.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OmniSwitch 8800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel OmniSwitch 8800

Summary of Contents for Alcatel OmniSwitch 8800

  • Page 1 Part No. 060183-10, Rev. D December 2004 OmniSwitch 8800 Hardware Users Guide www.alcatel.com...
  • Page 2 The specifications described in this guide are subject to change without notice. Copyright © 2004 by Alcatel Internetworking, Inc. All rights reserved. This document may not be repro- duced in whole or in part without the express written permission of Alcatel Internetworking, Inc.

  • Page 3: Table Of Contents

    1375 Watt DC-to-DC Power Supply ..............2-15 DC Power Supply Connection ................2-16 Connecting the DC Cable Harness to the Chassis Power Supply ....2-16 Connecting the DC Cable Harness to the DC Power Source ......2-16 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 4 Serial Connection to the Console/Modem Port ..........3-5 Configuring X-ON/X-OFF Protocol ................3-7 Converting the Console Port to a Modem Port ..........3-7 CMM Redundancy ......................3-9 CMM Failover Sequence ..................3-9 Synchronizing the Primary and Secondary CMMs ..........3-10 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 5 SFM Power Commands ....................4-13 Powering On an SFM .....................4-13 Powering Off an SFM ....................4-13 Setting an SFM to Standby ..................4-13 Monitoring SFM Modules .....................4-14 Front Panel LEDs ....................4-14 Accessing General SFM Information ..............4-15 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 6 Using the Grounding Wrist Strap and Chassis Grounding Lug ......5-29 Module Types and Slot Positions ................5-30 Removing a Module ....................5-30 Adding a Module ....................5-32 Pinouts ...........................5-34 Handling Fiber and Fiber Optic Connectors ..............5-35 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 7 Leer “información importante de seguridad” ..........A-12 Advertencia de acceso restringido ..............A-12 Advertencia de pulsera antiestática ..............A-12 Clase de seguridad ..................A-12 Advertencia de fuentes de poder ..............A-12 Index ........................Index-1 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 8 Contents viii OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 9: About This Guide

    This information in this guide applies to the following products: • OmniSwitch 8800 The OmniSwitch 8800 includes 18 slots for high performance 10/100 Ethernet, 1 Gbps Gigabit Ethernet, and 10 Gbps Gigabit NI modules. Unsupported Platforms The information in this guide does not apply to the following products: •...

  • Page 10: When Should I Read This Manual

    CLI commands that pertain directly to hardware configuration, but it is not intended as a software users guide. There are several OmniSwitch 8800 users guides that focus on switch software configuration. Consult those guides for detailed information and examples for configuring your switch software to operate in a live network environment.

  • Page 11: How Is The Information Organized

    Pertinent Documentation: OmniSwitch 8800 Getting Started Guide Release Notes A hard-copy OmniSwitch 8800 Getting Started Guide is included with your switch; this guide provides all the information you need to get your switch up and running the first time. This guide provides informa- tion on unpacking the switch, rack mounting the switch, installing NI modules, unlocking access control, setting the switch’s IP address, and setting up a password.
  • Page 12 CLI-to-MIB variable mapping information for all CLI commands supported by the switch. This guide can be consulted anytime during the configuration process to find detailed and specific information on each CLI command. page xii OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 13: Related Documentation

    The following are the titles and descriptions of all the OmniSwitch 8800 user manuals: • OmniSwitch 8800 Getting Started Guide Describes the hardware and software procedures for getting an OmniSwitch 8800 up and running. Also provides information on fundamental aspects of OmniSwitch software architecture. •...

  • Page 14: User Manual Cd

    Additionally, with 24-hour-a-day access to Alcatel’s Service and Support web page, you’ll be able to view and update any case (open or closed) that you have reported to Alcatel’s technical support, open a new case or access helpful release notes, technical bulletins, and manuals. For more infor- mation on Alcatel’s Service Programs, see our web page at www.ind.alcatel.com, call us at 1-800-995-...

  • Page 15: The Omniswitch 8800

    1 The OmniSwitch 8800 The 18-slot OmniSwitch 8800 (OS8800) switch offers high performance 10/100 Ethernet and Gigabit Ethernet capabilities, as well as embedded server load balancing for enterprise requirements. It provides non-blocking Gigabit Ethernet connectivity, carrier-class availability, multi-layer security, and intelligent switching and routing services—all at wire speed.

  • Page 16: Application Example

    Application Example The OmniSwitch 8800 Application Example The following application example shows one of the many ways OmniSwitch 8800 switches can be used in an Enterprise network setting. • Core Switch. In this example, an OS8800 is used as the core switch. Because the example network has a high-speed 10 Gigabit Ethernet backbone, the Network Interface (NI) cards in the chassis will use 10 Gigabit Ethernet Network Interface (10GNI) modules.

  • Page 17: Availability Features

    (CMM).” For detailed information on SFM redundancy, refer to Chapter 4, “Switch Fabric Module (SFM).” For information on power supply and fan redundancy, refer to Chapter 2, “Chassis and Power Supplies.” OmniSwitch 8800 Hardware Users Guide December 2004 page 1-3...

  • Page 18: Smart Continuous Switching

    For detailed information on the software rollback feature, as well as the switch’s /flash/working and /flash/certified directories, refer to the “Managing CMM Directory Contents” chapter in the OmniSwitch 7700/7800/8800 Switch Management Guide. page 1-4 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 19: Hot Swapping

    The user enters “show” commands that output information to the console. Show commands for all features are described in detail in the OmniSwitch CLI Reference Guide. OmniSwitch 8800 Hardware Users Guide December 2004 page 1-5...

  • Page 20: Power Checking Sequence

    If the number of power supplies installed in the chassis can provide sufficient power, the CMM turns on the incoming module. If the number of installed power supplies cannot provide sufficient power, the incoming NI will remain powered off. page 1-6 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 21: In This Chapter

    2 Chassis and Power Supplies The 18-slot OmniSwitch 8800 (OS8800) chassis provides 16 slots for Network Interface (NI) modules, 2 slots for Chassis Management Modules (CMMs), five slots for Switch Fabric Modules (SFMs), 4 slots for power supplies, two slots for chassis-cooling fan trays, and one slot for a fabric-cooling fan tray. OS8800 chassis provide important availability features, such as hardware redundancy and hot swapping.
  • Page 22 In This Chapter Chassis and Power Supplies / MO / MO OmniSwitch 8800 Chassis page 2-2 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 23: Chassis Specifications

    Chassis Specifications Chassis Specifications The OmniSwitch 8800 is a high performance switch offering 16 slots for Ethernet, Gigabit Ethernet, and/ or 10 Gigabit Ethernet Network Interface (NI) modules. An additional two slots are reserved for primary and redundant Chassis Management Modules (CMMs).
  • Page 24 FAIRE LA REPARATION. 230V 230V 230V 230V 50/60Hz, 8.0 A 50/60Hz, 8.0 A 50/60Hz, 8.0 A 50/60Hz, 8.0 A Airflow Intake Vents (for power supplies) Power Supplies OmniSwitch 8800 Back View page 2-4 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 25 Operating Temperature 32 ~ 113 °F (0 ~ 45 °C) Maximum heat dissipation 12564 BTU per hour Humidity 0 to 95% (Non-condensing) Operating Altitude Sea level to 10000 feet (3 km) OmniSwitch 8800 Hardware Users Guide December 2004 page 2-5...

  • Page 26: Chassis Slot Numbering

    Fan-5 Fan-6 Fan-7 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PS-3 PS-1 PS-2 PS-4 Front View Back View OmniSwitch 8800 Slot Numbering page 2-6 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 27: Viewing Chassis Slot Information

    Serial Number: 2146008P, Manufacture Date: APR 11 2002, Firmware Version: Admin Status: POWER ON, Operational Status: Power Consumption: Power Control Checksum: 0x808, MAC Address: 00:d0:95:77:4b:f4, ASIC - Physical: 0x1901 0x001e 0x001e 0x001e OmniSwitch 8800 Hardware Users Guide December 2004 page 2-7...

  • Page 28: Mounting The Switch

    Clearance is not required at the top and bottom of the chas- sis. Power Supply Considerations The power source socket-outlet must be installed near the chassis and must be easily accessible. page 2-8 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 29: Rack-Mounting

    Chassis and Power Supplies Mounting the Switch Rack-Mounting Refer to the important guidelines below before installing the OmniSwitch 8800 chassis in a rack. • Be sure that all modules and power supplies are removed before rack-mounting the switch. For instruc- tions on removing CMM or NI modules, refer to Chapter 5, “Network Interface (NI) Modules.”...
  • Page 30 Using two people, lift and position the chassis until the rack-mount brackets are flush with the rack post. Align the holes in the brackets with the rack holes you marked in step 1. page 2-10 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 31 Note. Be sure to install the screws in the bottom hole of each bracket, as shown, before proceeding. Once the screws at the bottom of each bracket are secure, install the remaining screws. Be sure that all screws are securely tightened. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-11...

  • Page 32: Stand-Alone

    Chassis and Power Supplies Stand-Alone The OmniSwitch 8800 can be installed unmounted as a stand-alone unit. Be sure that the installation loca- tion is a stable, flat surface that can accommodate the fully-populated weight of all switches being installed. One fully-populated OmniSwitch 8800 weighs approximately 220 pounds (100 kilograms).

  • Page 33: Power Supplies

    Chassis and Power Supplies Power Supplies Power Supplies The OmniSwitch 8800 supports a total of four power supplies (refer to page 2-15 for important redun- dancy information). The OS8-PS-1375A power supplies are installed in the power supply bays located at the bottom of the rear side of the chassis.
  • Page 34 4853 Watts Output Power 60 Amps at 24 Volts (1375 Watts) Warning. In North America, OmniSwitch 8800 power supplies require 220 Volt power cords connected to 220 Volt power receptacles. Do not use 110 Volt power cords or receptacles. page 2-14...

  • Page 35: 1375 Watt Dc-To-Dc Power Supply

    Power Switch. to ground the OS8800 chassis. indicates on position; indicates off position. For information on properly connecting the safety ground, refer to page 2-26. DC Power Supply Front Panel OmniSwitch 8800 Hardware Users Guide December 2004 page 2-15...

  • Page 36: Dc Power Supply Connection

    Power Supplies Chassis and Power Supplies OmniSwitch 8800 DC Power Supply Technical Specifications Input Voltage -48VDC to -60VDC Ambient Temperature 0–70 degrees Celsius (operating) -40–85 degrees Celsius (non-operating) Humidity 5%–95% relative humidity, non-condensing Altitude 10,000 feet above sea level and 32 degrees Celsius ambient air...

  • Page 37: Power Supply Redundancy

    (N+1). The minimum switch requirement is based on the number of CMM, SFM, and NI modules installed. The OmniSwitch 8800 supports up to a maximum of four power supplies per chassis. Three power supplies will provide N+1 resiliency to support configuration with up to eight NIs installed;...

  • Page 38: Permanently Removing A Power Supply

    Otherwise, switch operations may be disrupted. Additional Information. For instructions on installing and removing power supplies, refer to pages 2-19 through 2-22. For important information on power supply redundancy, refer to page 2-15. page 2-18 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 39: Installing A Power Supply

    S EL S D' TI ON TI ON M PO . AF TI ON W IT E RI L PO W ER W ER M AY LI E /6 0 /6 0 OmniSwitch 8800 Hardware Users Guide December 2004 page 2-19...
  • Page 40 Plug the power cord into the power supply’s socket. Make sure that the power cord is attached securely to the outlet. Note. The power cord must be Pluggable Type B, minimum 16AWG. page 2-20 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 41 Phillips-head screws. Once the power cord is secured in the retainer, plug the other end of the power cord into an easily- accessible, properly grounded outlet. Do not use an extension cord. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-21...

  • Page 42: Removing A Power Supply

    A FI TI O N AV W IT A LL IS K E LE M AY C TR IT . LI E U IP E FO D IS /6 0 /6 0 page 2-22 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 43 To install a blank cover panel, place it over the empty power supply bay and align the panel’s four captive screws with the threaded holes in the chassis. Once the screws are aligned, fasten the blank cover panel to the chassis. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-23...

  • Page 44: Power Cords

    CEI 23-16/VII (16 Amps) Attention. Do not use standard 18-gauge (18/3) cords such as those supplied with personal computers. DC-to-DC Power Cords For DC-to-DC connections, refer to page 2-16 for additional guidelines and information. page 2-24 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 45: Redundant Ac Circuit Recommendation

    AC Circuit 2 is unaf- fected. 230V 230V 230V 230V 50/60Hz, 8.0 A 50/60Hz, 8.0 A 50/60Hz, 8.0 A 50/60Hz, 8.0 A AC Circuit 1 Redundant AC Circuit Example OmniSwitch 8800 Hardware Users Guide December 2004 page 2-25...

  • Page 46: Grounding The Chassis

    Temperature Fabric Danger Threshold (deg C) = 75, Temperature CPU Danger Threshold (deg C) = 62 For more information about these displays, see the “Chassis Management and Monitoring Commands” chapter in the OmniSwitch CLI Reference Guide. page 2-26 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 47: Temperature Errors

    Checking for a chassis air flow obstruction • Checking the ambient room temperature • Checking the fan tray status using the command. See page page 2-30 for more information. show fan OmniSwitch 8800 Hardware Users Guide December 2004 page 2-27...

  • Page 48: Chassis Fan Trays

    Power for the fabric (back) and 386 Watts (maximum) both chassis (front) fan trays Important. The chassis fan trays are a required component. Never attempt to operate the switch without these fan trays installed. page 2-28 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 49 Important. The fabric fan tray is a required component. Never attempt to operate the switch without this fan tray installed. (However, the loss of one of the three fans in the tray will not prevent switch operation.) OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 50: Monitoring Fan Tray Status

    Storing Backup Fan Trays. It is a good idea to keep at least one backup chassis (front) fan tray and at least one backup fabric (back) fan tray in your data facility or other hardware storage area. page 2-30 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 51: Hot Swapping A Fan Tray

    “Installing the New Back Fan Tray” on page 2-34. Removing a Front Fan Tray Begin by turning both locking levers (latches) one-quarter turn counterclockwise. S TA Pull the fan tray straight out and away from the switch. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-31...

  • Page 52: Installing A New Front Fan Tray

    Installing a New Front Fan Tray Push the fan tray straight against the switch chassis. When the attachment brackets are flush against the chassis’ rear panel, turn the two locking levers (latches) clockwise one-quarter turn. page 2-32 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 53: Removing The Back Fan Tray

    Begin by loosening the four captive screws located at the four corners of the fan tray. Use a flat-head screwdriver if necessary. After the captive screws have been loosened (i.e., disengaged from the threaded holes in the chassis), pull the fan tray straight out and away from the switch. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-33...

  • Page 54: Installing The New Back Fan Tray

    When the attachment brackets are flush against the chassis’ rear panel, tighten the captive screws. Be sure not to overtighten the captive screws. If you use a screwdriver, the torque used to tighten the screws must not exceed 2.3 inch pounds. page 2-34 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 55: Chassis Airflow

    SFM boards. 1. Air Intake. The fan trays pull air from the three air intake vents located at the bottom of the chassis. Air Intake Vents Chassis (Front) Airflow for OS8800 Switches OmniSwitch 8800 Hardware Users Guide December 2004 page 2-35...
  • Page 56 Fan Tray 1. Air Intake. The fan tray pulls air from the middle- right side of the chassis. Air Intake Vent Chassis (Back) Airflow for OS8800 Switches page 2-36 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 57: Power Supply Fans

    Airflow for Power Supplies page 2-13 for detailed power supply front panel and LED information. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-37...

  • Page 58: Blank Cover Panels And Chassis Airflow

    For optimal airflow and chassis component protec- tion, always install blank cover panels over empty module slots and power sup- ply bays. Effects of Missing Blank Panels on Chassis Airflow page 2-38 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 59: Managing Mac Addresses On The Switch

    Managing MAC Addresses on the Switch Managing MAC Addresses on the Switch Your OmniSwitch 8800 is shipped with thirty-two (32) factory-installed MAC addresses. These MAC addresses, which are stored on an EEPROM card in the chassis, are used by the switch as unique identifi- ers for the following functions: •...

  • Page 60: Os8800 Mac Range Specifications

    MAC address. For more infor- mation on VLAN router ports and MAC address allocation, refer to page 2-41. MAC router modes supported Multiple and single Default MAC router mode Multiple page 2-40 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 61: Vlan Router Ports And Mac Address Allocation

    MAC router mode. Multiple MAC router mode provides important compatibility with Alcatel’s Omni Switch/Router (OmniS/R) products. If you have OmniS/R products in your network and are using VLAN router ports on your switch, multiple MAC router mode should remain enabled.

  • Page 62: Viewing Current Multiple Mac Router Mode Status

    It is system-generated syntax used to ensure that each new router port being assigned receives a unique MAC address. For more information about editing the boot.cfg file, see the OmniSwitch 7700/ 7800/8800 Switch Management Guide. page 2-42 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 63 EMP MAC address. The EMP MAC address is the last address in the range (in this example, 00:d0:95:6b:09:5f).Although this address is also labeled CHASSIS, it can be differentiated from the base chassis MAC address because it is given an index value of 1. OmniSwitch 8800 Hardware Users Guide December 2004 page 2-43...
  • Page 64 Managing MAC Addresses on the Switch Chassis and Power Supplies page 2-44 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 65: Chapter 3 Chassis Management Module (Cmm)

    3 Chassis Management Module (CMM) The Chassis Management Module (CMM) is the management unit for OmniSwitch 8800 switches. In its role as the management unit, the CMM provides key system services, including: • Console, modem, and Ethernet management port connections to the switch •...

  • Page 66: Cmm Slot Locations

    LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK ENET LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK LINK CMM Slot B CMM Slot Locations page 3-2 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 67: Cmm Front Panel

    CMM. For more informa- tion. Refer to the OmniSwitch CLI Reference tion on redundant CMM configurations, Guide for more information. refer to page 3-9. CMM Front Panel OmniSwitch 8800 Hardware Users Guide December 2004 page 3-3...

  • Page 68: Ethernet Management Port

    Default IP Address. The default IP address for the EMP is 192.168.1.1; the default gateway address is 192.168.1.254. For information on changing the EMP’s default IP address information, refer to the OmniSwitch 8800 Getting Started Guide. Access to the EMP By default, only devices in the same subnet as the EMP will be able to manage the switch through that port.

  • Page 69: Console/Modem Port

    Boot > boot serialbaudrate 19200 To change the parity value, enter boot serialparity, followed by the desired parity value. Options include none (default), even, and odd. For example: Boot > boot serialparity even OmniSwitch 8800 Hardware Users Guide December 2004 page 3-5...
  • Page 70 To save changes to the boot.params file, refer to step 7. Return to the CLI prompt by entering exit at the boot prompt. page 3-6 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 71: Configuring X-On/X-Off Protocol

    To remove a jumper, pull it straight up and away from the jumper block. To replace, slide the jumper over both of the specified pins and gently press down until it meets the jumper block. OmniSwitch 8800 Hardware Users Guide December 2004 page 3-7...
  • Page 72 CMM Front Panel Chassis Management Module (CMM) Note. Be sure to remove only the jumpers from the J100, J101, and J102 jumper blocks. page 3-8 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 73: Cmm Redundancy

    In redundant CMM configurations, the Ethernet Management Ports (EMPs) and Redundancy Ethernet Management Port (EMP) is only operational on the primary CMM. For additional information on the EMP, refer to page 3-4. OmniSwitch 8800 Hardware Users Guide December 2004 page 3-9...

  • Page 74: Synchronizing The Primary And Secondary Cmms

    CMM from assuming the primary role with incorrect or outdated software or configuration files in the event of a primary CMM failure. Important. In order to have effective CMM redundancy, CMMs must be synchronized at all times. page 3-10 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 75 -> copy flash-synchro For more information on CMM synchronization and managing the /flash/working and /flash/certified directories, refer to the “Managing CMM Directory Content” chapter in the OmniSwitch 7700/7800/8800 Switch Management Guide. OmniSwitch 8800 Hardware Users Guide December 2004 page 3-11...

  • Page 76: Hot Swapping Cmms

    CMMs are synchronized. Otherwise, data flow and switch management functions may be interrupted due to incorrect or outdated software when the secondary CMM takes over. For more informa- tion, refer to “Synchronizing the Primary and Secondary CMMs” on page 3-10. page 3-12 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 77: Managing Cmms

    The reloaded CMM then assumes the secondary—or redundant—role when the reload sequence is complete. Reloading the Secondary CMM If the secondary CMM is reloaded, only the secondary CMM is affected. The primary CMM continues all operations without interruption. OmniSwitch 8800 Hardware Users Guide December 2004 page 3-13...

  • Page 78: Switching The Primary And Secondary Roles

    Otherwise, data flow and switch management functions may be interrupted due to incorrect or outdated software when the secondary CMM takes over. For more information, refer to “Synchronizing the Primary and Secondary CMMs” on page 3-10. page 3-14 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 79: Monitoring Cmms

    Additional information, such as power control checksum, ASIC information, and chassis MAC Address (see page 3-17 for information on MAC address storage) For a detailed information on the show cmm command, including output table descriptions, refer to the OmniSwitch CLI Reference Guide. OmniSwitch 8800 Hardware Users Guide December 2004 page 3-15...

  • Page 80: Operating Status Of Cmm-Related Components

    Chassis Management and Monitoring Commands show system show cmm show module long show hardware info show ni show module status show chassis show module show fabric page 3-16 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 81: Chassis-Based Mac Address

    Switch Management Guide. MAC EEPROM Redundancy. A second EEPROM is provided for redundancy. An EEPROM card can be removed and replaced in the field by an authorized Alcatel Support Engineer in the unlikely event of an EEPROM failure. OmniSwitch 8800 Hardware Users Guide...

  • Page 82: Pinouts

    Not used DTR (from CMM) Ground Ground Not used DSR (to CMM) Not used RTS (from CMM) Not used CTS (to CMM) Not used Not used Shell Chassis ground Chassis ground page 3-18 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 83 CMMs will not function in SFM slots. Each Fabric Module contains two ASICs which provide the store-and-forward switching fabric function for the OmniSwitch 8800. The ASIC is bit-sliced; a group of eight ASICs operates together as a single synchronized fabric.

  • Page 84: Chapter 4 Switch Fabric Module (Sfm)

    The fabric board slots are numbered 1 to 5. In order for the switch to function, slots 1 through 4 must contain an SFM. Slot 5 is used for SFM redundancy, in the event one of the other SFMs fail. The switch will function if slot 5 is empty. page 4-2 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 85: Sfm Front Panel

    Minimum umber of SFMs required in an OS8800 Minimum umber of SFMs required in an OS8800 in a redundant configuration Current draw Approximately 2.5 amps at 24 volts Power 60 Watts (approximate) OmniSwitch 8800 Hardware Users Guide December 2004 page 4-3...

  • Page 86: Sfm Redundancy

    (Redundant SFM is slot 5) Redundant SFM Failover The OmniSwitch 8800 is running with the SFMs in slots 1 through 4 controlling traffic. The SFM in slot 5 is a redundant module. The SFM in slot 2 fails. The redundant SFM in slot 5 takes over for the SFM in slot 2. The switch is now functional again with the SFMs in slots 1, 3, 4, and 5 handling traffic.

  • Page 87: Adding And Removing Sfm Modules

    To prop- erly ground yourself, follow the steps below. Fasten the grounding strap to your wrist. (A grounding strap was provided in your OmniSwitch 8800 series ship kit.) Insert the wrist strap’s connector pin (located at the end of the strap’s tether) into the grounding lug...

  • Page 88: Module Slot Positions

    CMMs or NI modules cannot be installed the rear chassis slots. More Information on Slot Numbering. For a diagram showing the chassis layout and slot positions, refer Chapter 2, “Chassis and Power Supplies.” page 4-6 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 89: Adding A Module

    Note. The module should slide in easily. Do not force the module into the slot. If any resistance is encoun- tered, ensure the module is aligned properly in the card guide. OmniSwitch 8800 Hardware Users Guide December 2004 page 4-7...
  • Page 90 Once the notches have grasped the rail, press both extractor levers inward simultaneously until the module is firmly seated. - S F page 4-8 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 91 Once the module is firmly seated, secure the module to the chassis by tightening the two captive screws. Be sure not to overtighten the captive screws. If you use a screwdriver, the torque used to tighten the screws must not exceed 2.3 inch pounds. OmniSwitch 8800 Hardware Users Guide December 2004 page 4-9...

  • Page 92: Removing A Module

    Loosen the module’s two captive screws that secure the module to the chassis. Be sure that both captive screws are completely disengaged from the threaded holes in the chassis before continuing. - S F page 4-10 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 93 Adding and Removing SFM Modules Simultaneously pull the two module extractor levers—one to the left of the module and one to the right—until the module disengages from the chassis. - S F - S F OmniSwitch 8800 Hardware Users Guide December 2004 page 4-11...
  • Page 94 Do not force the module from the slot. - S F Note. For detailed instructions on physically installing and removing NI modules, refer to Chapter 5, “Network Interface (NI) Modules.” page 4-12 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 95: Sfm Power Commands

    The normal state of an SFM is power on, and at least four powered SFMs are necessary for the OmniSwitch 8800 to function. If a fifth SFM is installed, it is possible to change the power state of any of the SFMs in the chassis.

  • Page 96: Monitoring Sfm Modules

    System software (OK2). Software Status. Blinks green when the SFM is operational. Displays solid amber when a system software failure occurs. Displays blinking amber when the SFM unit is a redun- dant unit. page 4-14 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 97: Accessing General Sfm Information

    SFM hardware information as well as the current operating status. show fabric command allows you to view the operating parameters of the SFMs currently installed in the OmniSwitch 8800. A display for each SFM is given, including the redundant SFM. For example: -> show fabric Fabric Number 1...
  • Page 98 Each of the modules in the switch chassis has its own display. If there are only four modules in the chas- sis, only four displays appear. The redundant SFM is known by the word SECONDARY in the Opera- tion Status field. page 4-16 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 99: Chapter 5 Network Interface (Ni) Modules

    Several Ethernet Network Interface (ENI), Gigabit Network Interface (GNI), and 10 Gigabit Network Interface (10GNI) modules are currently available for OmniSwitch 8800 switches. These modules come in a variety of port speeds, including auto-sensing 10/100 Mbps Ethernet, Gigabit Ethernet (1 Gbps), and 10 Gigabit Ethernet (10 Gbps).
  • Page 100 In This Chapter Network Interface (NI) Modules Note. You can also manage and monitor ENI, GNI, and 10GNI modules with WebView, Alcatel’s embed- ded web-based device management application. WebView is an interactive and easy-to-use GUI that can be launched from OmniVista or a web browser. Please refer to WebView’s online documentation for more information.

  • Page 101: Eni Modules

    5-28 for more information. • LED-based monitoring. Refer to page 5-27 for more information. • NI support during CMM failover. Refer to “Smart Continuous Switching” on page 5-26 for details. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-3...

  • Page 102: Os8-Eni-C24 Front Panel

    10BaseT or 100BaseTX. The ports use RJ-45 connectors. Refer to the Technical Specifications table on page 5-5 for more information. LED Location Ethernet Port OS8-ENI-C24 Front Panel page 5-4 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 103 100BaseTX: unshielded twisted-pair (UTP), Category 5, EIA/TIA 568 or shielded twisted-pair (STP), Category 5, 100 ohm Maximum cable distance 100 meters Current draw 1.8 amps at 24 volts Power 44 watts (approximate) OmniSwitch 8800 Hardware Users Guide December 2004 page 5-5...

  • Page 104: Gni Modules

    A MiniGBIC is a Gigabit Ethernet port module that is hot-pluggable—i.e., it can be installed or removed while the GNI is powered on and operating without the risk of damage to the MiniGBIC module or the host circuitry. Alcatel MiniGBICs are Small Form-factor Pluggable (SFP) MSA (Multi Source Agree- ment) compliant.

  • Page 105: Os8-Gni-C8 Front Panel

    Giga- bit Ethernet port. LINK LINK. Link Integrity Status. Displays solid green when a fiber cable connection exists at the corresponding Gigabit Ethernet port. OS8-GNI-C8 Front Panel OmniSwitch 8800 Hardware Users Guide December 2004 page 5-7...
  • Page 106 1000BaseT connection to backbone or server Cable supported 1000BaseT: unshielded twisted-pair (UTP), Category 5e Maximum cable distance 100 meters, Category 5 Current draw 5.96 amps at 24 volts Power 143 watts (approximate) page 5-8 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 107: Os8-Gni-U8 Front Panel

    70 km); uses LC connectors. at the corresponding Gigabit Ethernet port. LINK Note page 5-35 for information on LINK proper handling of LC connectors and fiber-optic cable. OS8-GNI-U8 Front Panel OmniSwitch 8800 Hardware Users Guide December 2004 page 5-9...
  • Page 108 Note. Connector and cable information in the above table is dependent on the type of MiniGBIC(s) installed in the OS8-GNI-U8 module. For a technical breakdown of each MiniGBIC type, refer to “MiniG- BIC Specifications” on page 5-13. page 5-10 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 109: Os8-Gni-U24/Os8-Gni2-U24 Front Panel

    MINIGBIC-LX—1000BaseLX Single mode fiber, supports distances up to 10 km; uses LC connectors. • MINIGBIC-LH-70— 1000BaseLH Long haul fiber, supports distances up to 70 km; uses LC connectors. OS8-GNI-U24 Front Panel OmniSwitch 8800 Hardware Users Guide December 2004 page 5-11...
  • Page 110 Note. Connector and cable information in the above table is dependent on the type of MiniGBIC(s) installed in the OS8-GNI-U24 or OS8-GNI2-U24 module. For a technical breakdown of each MiniGBIC type, refer to “MiniGBIC Specifications” on page 5-13. page 5-12 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 111: Minigbic Specifications

    Fiber optic cable supported Single mode Wavelength 1550 nm (typical) Output optical power 0 to +5 dBm Input optical power -23 to -3 dBm ≈ Cable distances Long reach single mode fiber 70 km OmniSwitch 8800 Hardware Users Guide December 2004 page 5-13...

  • Page 112: Installing Minigbic Connectors

    Note. To remove a MiniGBIC, you must first open the MiniGBIC’s hinged face to approximately ninety degrees. Then, grasp the hinged face and carefully pull the MiniGBIC straight out of the slot. page 5-14 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 113: Removing Minigbic Connectors

    Then, grasp the hinged face and carefully pull the MiniGBIC straight out of the slot Slide the MiniGBIC out of the module’s port. Store the MiniGBIC in a secure, static-free location. Placing the MiniGBIC in an anti-static bag is recommended. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-15...

  • Page 114: Os8-Gni-C24/Os8-Gni2-C24 Front Panel

    Flashes green as data is transmitted or received on the port. Refer to diagram on the bottom of the NI for locations of the two (10/100 or Gigabit) LEDs. 10/100 10/100 1000 1000 OS8-GNI-C24 Front Panel page 5-16 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 115 (STP), Category 5, 100 ohm 1 Gigabit Cable supported 1000BaseT: unshielded twisted-pair (UTP), Category 5e Maximum cable distance 100 meters, Category 5 Current draw 4.58 amps at 24 volts Power 110 watts (approximate) OmniSwitch 8800 Hardware Users Guide December 2004 page 5-17...

  • Page 116: 10Gni Modules

    Xenpaks are 10 Gigabit Ethernet port modules that are hot-pluggable—i.e.,they it can be installed or removed while the 10GNI is powered on and operating without the risk of damage to the Xenpak module or the host circuitry. Alcatel Xenpaks are MSA (Multi Source Agreement) compliant. For information on Xenpaks, refer to page 5-23.

  • Page 117: Os8-10Gni-Ur1 Port Redundancy

    OS8-10GNI-UR1 in the current release: • Group mobility • Authenticated VLANs (AVLANs) • Link aggregation • Learned Port Security (LPS) • Port mirroring • Hardware-based multicast routing • High-availability VLANs OmniSwitch 8800 Hardware Users Guide December 2004 page 5-19...

  • Page 118: Os8-10Gni-Ur1 Front Panel

    Xenpak module plugged up to 10 km; uses SC connectors. into the port. • OM-10GNI-ER—10GBASE-E Long-haul single mode fiber, supports distances up to 40 km; uses SC connectors. Link OS8-10GNI-UR1 Front Panel page 5-20 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 119 Note. Connector and cable information in the above table is dependent on the type of Xenpak(s) installed in the OS8-10GNI-UR1 module. For a technical breakdown of each Xenpak type, refer to “Xenpak Speci- fications” on page 5-22. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-21...

  • Page 120: Xenpak Specifications

    Single mode Transceiver type Serial Wavelength 1550 nm (typical) Power budget 15.0 dB Output optical power -4.7 to 4.0 dBm Input optical power -15.8 to -1.0 dBm ≈ Cable distances 40 km page 5-22 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 121: Installing Xenpak Connectors

    10GNI Modules Installing Xenpak Connectors If you are installing an OS8-10GNI-UR1 module, you must install Xenpaks as required. Alcatel OS8- 10GNI-UR1 modules provide slots for up to 2 Xenpak submodules, which act as a single 10 Gigabit port. These Xenpaks are packaged separately. To install a Xenpak follow the steps below.
  • Page 122 Tighten the two captive screws by turning them clockwise. Be sure not to overtighten the captive screws. If you use a screwdriver, the torque used to tighten the screws must not exceed 2.3 inch pounds. page 5-24 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 123: Removing Xenpak Connectors

    Note. If you do not replace the Xenpak module with another one attach the blank slot cover plate to the OS8-10GNI-UR1’s front face with the screws supplied with your NI module. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-25...

  • Page 124: Smart Continuous Switching

    -> reload ni 3 For detailed information on the no power ni, power ni, and reload ni commands, refer to the “Chassis Management and Monitoring Commands” chapter in the OmniSwitch CLI Reference Guide. page 5-26 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 125: Monitoring Ni Modules

    0x1901 0x0201 0x0201 0x001e 0x001e 0x001e For more information about this display and other NI monitoring commands, see the “Chassis Management and Monitoring Commands” chapter in the OmniSwitch CLI Reference Guide. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-27...

  • Page 126: Hot Swapping Ni Modules

    Note. Although presence signalling is designed to maintain data flow on the switch during the hot swap procedure, uninterrupted data flow cannot be guaranteed. As a result, you should not hot swap CMM or NI modules during critical network activity. page 5-28 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 127: Removing And Adding Modules

    Chassis Management Modules (CMMs), you must always ground yourself properly before removing or adding a module. For this purpose, Alcatel provides a grounding wrist strap and a grounding lug located near the bottom-right of the chassis. To properly ground yourself, follow the steps below.

  • Page 128: Module Types And Slot Positions

    First, loosen the module’s two captive screws that secure the module to the chassis. If necessary, use a flat-blade screwdriver to loosen the screws. Be sure that both captive screws are completely disengaged from the threaded holes in the chassis before continuing. page 5-30 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 129 Holding the module in both hands, carefully slide it out of the chassis along the card guide. The module should slide out easily. Do not force the module from the slot. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-31...

  • Page 130: Adding A Module

    The module should slide in easily. Do not force the module into the slot. If any resistance is encoun- tered, ensure the module is aligned properly in the card guide. Also, see the important note regarding chas- sis card guides on page 5-32. page 5-32 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 131 Once the module is firmly seated, secure the module to the chassis by tightening the two captive screws. Be sure not to overtighten the captive screws. If you use a screwdriver, the torque used to tighten the screws must not exceed 2.3 inch pounds. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-33...

  • Page 132: Pinouts

    10/100 Ethernet Port – RJ-45 Pinout Pin Number Description not used not used not used not used Gigabit Ethernet Port – RJ-45 Pinout Pin Number Description BI_DB+ BI_DB- BI_DA+ BI_DD+ BI_DD- BI_DA- BI_DC+ BI_DC- page 5-34 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 133: Handling Fiber And Fiber Optic Connectors

    It can also damage the fiber, although fiber is much tougher than most would assume. Still, it is highly recommended to buy only jumper cables with 3mm Kevlar jacketing, which offer superior protection and longer life. OmniSwitch 8800 Hardware Users Guide December 2004 page 5-35...
  • Page 134 Inline attenuators eliminate the need for additional jumper cables and thus reduce the number of connec- tion interfaces. This increases the integrity of the optical path resulting in a more accurate test. page 5-36 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 135: Regulatory Compliance And Safety Information

    73/23/EEC und des 89/336/EEC, wie von Directive 93/68/EEC geändert. Español: Este directivo equipo está en conformidad con los requisitos esenciales y otras provisiones 73/23/EEC y 89/336/EEC según la enmienda prevista por Directive 93/68/EEC. OmniSwitch 8800 Hardware Users Guide December 2004 page A-1...

  • Page 136: Standards Compliance

    ETS 300 019 Stationary Use Class 3.1 All hardware switching modules used in an OmniSwitch 8800 comply with Class A and Class B standards for digital devices per the FCC Part 15, ICES-003, EN 55022, CISPR 22, AS/NZS 3548, and VCCI stan- dards.

  • Page 137: Fcc Class A, Part 15

    CISPR22 Class A warning This is a Class A product. In a domestic environment, this product may cause radio interference. Under such circumstances, the user may be requested to take appropriate countermeasures. OmniSwitch 8800 Hardware Users Guide December 2004 page A-3...

  • Page 138: Vcci

    This is a Class A Information Product. When used in a residential environment, it may cause radio frequency interference. Under such circumstances, the user may be requested to take appropriate counter- measure. page A-4 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 139: Translated Safety Warnings

    Kabel angeschlossen oder gelöst werden, ferner keine Installation, Wartung oder Rekonfiguration durchgeführt werden. Español: Para evitar peligro de descargas, no conecte o desconecte ningun cable, ni realice ninguna insta- lación, maintenimiento o reconfiguratión de este producto durante una tormenta eléctrica. OmniSwitch 8800 Hardware Users Guide December 2004 page A-5...

  • Page 140: Installation Warning

    Al quitar los cables no mire fijamente en las aberturas abiertas. Además, instale las cubi- ertas protectoras de la abertura a los accesos de la fibra sin el cable conectado. page A-6 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 141: Lithium Battery Warning

    Disponga de las baterías usadas según las instrucciones del fabricante. Las instrucciones del fabri- cante son como sigue: Vuelva el módulo con la batería del litio a Alcatel. La batería del litio será substituida en la fábrica de Alcatel.

  • Page 142: Power Disconnection Warning

    El cable de alimentación debe estar conectado a una toma de alimentación adecuadamente cableada y con toma de tierra. • Cualquier equipo al cual se conecte este producto debe estar también conectado a tomas de aliment- ación adecuadamente cableadas. page A-8 OmniSwitch 8800 Hardware Users Guide December 2004...

  • Page 143: Read Important Safety Information Warning

    Español: Este equipo se debe instalar en una localización que restrinja el acceso. Una localización restricta del acceso es una donde está seguro y limitado el acceso al personal de servicio que tiene un clave especial, o a otros medios de la seguridad. OmniSwitch 8800 Hardware Users Guide December 2004 page A-9...

  • Page 144: Wrist Strap Warning

    Because electrostatic discharge (ESD) can damage switch components, you must ground yourself prop- erly before continuing with the hardware installation. For this purpose, Alcatel provides a grounding wrist strap and a grounding lug located near the top-right of the chassis. For the grounding wrist strap to be effective in eliminating ESD, the power supplies must be installed in the chassis and plugged into grounded AC outlets.

  • Page 145: Instrucciones De Seguridad En Español

    Deseche las baterías usadas según las instrucciones del fabricante. Las instrucciones del fabricante son como sigue: Devuelva el módulo con la batería del litio a Alcatel. La batería del litio será substituida en la fábrica de Alcatel.

  • Page 146: Advertencia Sobre Una Apropiada Conexión A Tierra

    Debido a que la descarga electrostática (ESD) puede dañar componentes del interruptor, usted debe conec- tarse a tierra correctamente antes de continuar con la instalación del equipo. Para este propósito, Alcatel proporciona una pulsera antiestática y un terminal que pone a tierra situados cerca de la parte superior derecha del chasis.
  • Page 147 3-3, 3-5 Ethernet Management Port 3-3, 3-4 failover hardware monitoring front panel automatic hot swapping 3-12 LEDs 1-5, 3-3, 4-3, 5-4, 5-7, 5-9, 5-11, 5-16, 5-20 LEDs user-driven managing 3-13 OmniSwitch 8800 Hardware Users Guide December 2004 Index-1...
  • Page 148 2-24 power checking power ni command 5-26 powering on or off 5-26 reloading 5-26 removing and adding 5-29 technical specifications 5-5, 5-8, 5-10, 5-12, 5-17, 5-21 no power ni command 5-26 Index-2 OmniSwitch 8800 Hardware Users Guide December 2004...
  • Page 149 5-27 show power command 2-17 show running-directory command 3-14 show temperature command 2-26, 2-27 slot numbering Smart Continuous Switching 1-4, 5-26 software rollback OmniSwitch 8800 Hardware Users Guide December 2004 Index-3...

  • Page 150: Index

    Index Index-4 OmniSwitch 8800 Hardware Users Guide December 2004...

Table of Contents
