Summary of Contents for TechnoKom AUTOGRAPH GSM SL

Page 3: Table Of Contents
CAN Bus (SAE J1939 / FMS) ........................Indication of Operation ........................... Installing the Drivers ............................Connection of Controller to PC ........................Transportation and Storage of Controller ....................Appendix 1. Warranty Provisions (summary) ..................Appendix 2. Certificates of Conformity ....................TechnoKom © 2015...
Page 4: Software Copyright Notice
TechnoKom or third parties. Laws of the Russian Federation and other countries secure certain exclusive rights of TechnoKom and third parties to the software, which is subjected to copyright, for example, exclusive rights for distribution or reproduction.
Page 5 User Manual is based on current data (at time of writing) and is deemed to be valid as of the IMPORTANT date of publication. TechnoKom reserves the right to modify the information or specifications without prior notice or commitment. Some functions of AutoGRAPH-GSM/SL controllers depend on capacities and configuration of the existing mobile network operator (MNO).
Page 6: Safe Operation And Exposure To Electromagnetic Fields
• GOST R Certificate of Conformity: GOST quency Electromagnetic Fields in the Fre- R № ROSS RU.MN11.H07574. quency Range from 3 kHz to 300 GHz, 1999. • TR CU Certificate of Conformity: TS RU • Australian Communications Authority Ra- D-RU.AI30.B.00059. diocommunications (Electromagnetic Ra- TechnoKom © 2015...
Page 7 In order to avoid interference with blasting institutions or petrol stations. operations, SWITCH OFF the device in blasting areas or in any locations marked with “Two-way radio-communication is prohibited” signage. Observe the signage instructions and rules. TechnoKom © 2015...
Page 8: Basic Information
Autonomous A-GPS Differential GPS (D-GPS) Communication GSM (GPRS / SMS) SIM holders Type of antennas (GPS/GLONASS, GSM) External Connection to PC USB 2.0 Internal FLASH memory, records > 270,000 Digital inputs, total number High-impedance digital inputs, total number TechnoKom © 2015...
Page 9 Time to first position fix (typ.), s Position accuracy*: – Position (typ.), m – Velocity (typ.), m/s 0.02 Operating temperature, °С -40…+85 Dimensions, mm 65 х 50 х 20 Weight, kg 0,05 Average life time, years * With nominal GNSS signal levels -130dBm. TechnoKom © 2015...
Page 10: Scope Of Supply
АвтоГРАФ-GSM/SL • USER MANUAL Scope of Supply No. Description AutoGRAPH-GSM/SL on-board controller Interface cable GPS/GLONASS antenna GSM antenna Fuse with a holder Warranty certificate TechnoKom © 2015...
Page 11: Components Of Autograph-Gsm/Sl Controller
3. GPS/GLONASS LEDs. 4. GPS/GLONASS antenna connector. 5. Mounting bracket. 6. Fastening screw of a back cover (x4). 7. Manufacturer’s label. 8. Interface connectors. TechnoKom Ltd. Made in Russia Model: AutoGRAPH-SL 2345678 DC 10...15 V 50 mA WWW.TK-CHEL.RU TechnoKom © 2015...
Page 12: Interface Connectors
Open collector output 1 White Digital input 2 (active high) Orange with a white stripe RS-485 (А) Yellow with a white stripe CAN (L) Additional connectors Assignment Micro USB connector (programming / data reading / GPS mouse) TechnoKom © 2015...
Page 13: Structure Diagram Of Autograph-Gsm/Sl
POWER SUPPLY DRIVER RS-485 CENTRAL PROCESSING UNIT FLASH MEMORY ACCELEROMETER INPUTS / OUTPUTS DIGITAL HIGH DIGITAL HIGH DIGITAL INPUTS DIGITAL INPUTS DIGITAL INPUTS DIGITAL INPUTS DIGITAL IMPEDANCE IMPEDANCE active low active low active high active high OUTPUTS INPUT INPUT TechnoKom © 2015...
Page 15 The tracker has one active low and one active high digital inputs. Logic of the discrete inputs operation is shown in the table below: Logic state Physical state of the input Active low input Active high input High (connected to supply voltage) Open-Circuit Low (connected to ground) TechnoKom © 2015...
Page 16 (from 1 to 10 seconds) to switch the output on for the pulse duration. Furthermore, the discrete output may serve to indicate cases of exceeding speed limits, acceleration, entry to and exit from control points, enabling of security functions etc. TechnoKom © 2015...
Page 17 Google Earth Plus/Pro, 2GIS for PC 3.0, Garmin, Navitel and many others. For details please refer to “Using the GPS mouse” document. For detailed information on GPS mouse mode see “AutoGRAPH-GSM controller: GPS mouse mode” NOTE document. TechnoKom © 2015...
Page 18 RS- 232/RS-485 converters, etc. The RS-485 port of the AutoGRAPH-GSM/SL controller supports MODBUS protocol that enables the users to connect the controller to the thermal sensors, which transmit data via this protocol. TechnoKom © 2015...
Page 19: Brief Description Of Vehicle Tracking System Operation
GLONASS+GPS VEHICLES equipped with AutoGRAPH-GSM Mobile Internet VOICE CALL & SMS 3G/GPRS (GSM) WI-FI DATA BASE DATA SERVER Internet & local area network MOBILE APP. DESKTOP SOFTWARE WEB-SERVICE DATA EXPORT & REPORTS HTML TIFF Dropbox GoogleDrive SkyDrive TechnoKom © 2015...
Page 20 АвтоГРАФ-GSM/SL • USER MANUAL AutoGRAPH-GSM/SL controllers installed official website of TechnoKom: http://www. on vehicles constantly receive coded signals tk-chel.ru. from Global Positioning System (NAVSTAR) and GLONASS satellites. These signals are Mobile users can easily track vehicle used to determine exact coordinates of the movement in real-time using WEB based vehicle location.
Page 21 SL, which may support some specific functionality. To obtain detailed information on the implementation of particular features for customization NOTE of the monitoring system in accordance with your needs, please contact your regional authorized representative of TechnoKom and the manufacturer’s technical support service. TechnoKom © 2015...
Page 22: Connection Of Autograph-Gsm Controller
The following sections focus on basic connection diagrams of various interfaces, inputs and outputs of the AutoGRAPH-GSM/SL controller. TechnoKom © 2015...
Page 23: Installation Of Sim-Cards
GPRS / SMS / USSD services are enabled and operate properly, the PIN code matches the code preset IMPORTANT in the controller (in order to prevent locking), and a personal account associated with the SIM card has the sufficient balance for successful operation of the services. TechnoKom © 2015...
Page 24: Installation Of A Gps/Glonass Antenna
Do not fix antenna before you make settings and configure your system, it is highly recommended to determine its final position and install only when you are absolutely sure that the system is configured and operates properly. Do not splice or cut the antenna cable. IMPORTANT TechnoKom © 2015...
Page 25: Installation Of A Gsm Antenna
Do not splice or cut the antenna cable. IMPORTANT In order to avoid cross-talk effects place the GSM and GPS antennas at least 50 cm away from each IMPORTANT other. TechnoKom © 2015...
Page 26: Power Supply Connection
GPRS and web traffic. The fuse should be placed as close as possible to the point where the AutoGRAPH-GSM/SL is IMPORTANT connected to the vehicle power system. TechnoKom © 2015...
Page 27: Connection Of Digital Input 1 (Active Low)
For example, “Skip the coordinates” filter when the engine is shut down reduces traffic and filters coordinate drift at stops when the engine is not running. TechnoKom © 2015...
Page 28 1 correctly. Connection Diagram for Active Low Digital Input “Before Disconnect Switch” Option: Connection Diagram for Active Low Digital Input “After Disconnect Switch” Option: TechnoKom © 2015...
Page 29 Use may use safety relays designed for switching of direct current circuits with voltage rating NOTE compatible with the vehicle system voltage. For example, relays of 901.3747 type manufactured by AVAR, AO, (www.ellink.ru/co/avar) for a vehicle system voltage of 24 V. TechnoKom © 2015...
Page 30: Connection Of Digital Input 2 (Active High)
(‘ g round’), while all voltage levels above 6 V shall be considered to be logical “1” (‘+’). If the input is open-circuit it shall denote logical “0”. Internal Connection Diagram for Active Low Digital Input External Connection Diagram for High Active Digital Input TechnoKom © 2015...
Page 31 Use may use safety relays designed for switching of direct current circuits with voltage rating NOTE compatible with the vehicle system voltage. For example, relays of 901.3747 type manufactured by AVAR, AO, (www.ellink.ru/co/avar) for a vehicle system voltage of 24 V. TechnoKom © 2015...
Page 32: Connection Of High-Impedance Digital Input
The input resistance of the high-impedance input is 1 mega-ohm (1MΩ). The cut-off frequency of the input low-pass filter is 5,000 Hz. Internal Diagram of High-impedance Input: HIGH-IMPEDANCE INPUT - PINK (6) Digital voltage output sensor + U sensor power supply TechnoKom © 2015...
Page 33: Connection Of Output
EMF, induced from disconnecting an inductive load, connect a protective diode in parallel to the relay. To select a correct diode make sure that direct current of this protective diode is at least 1.5 times greater than the relay holding current. TechnoKom © 2015...
Page 34: Rs-485 Bus (Tia / Eia-485-A)
All connections should be made when the controller and all external devices to be connected to the RS-485 bus are disconnected from power supply. IMPORTANT Be careful not to mix up connections to “А” and “В” lines. If the lines are swapped, device may not IMPORTANT operate correctly. TechnoKom © 2015...
Page 35 Pay attention to the supply voltage range of the sensors and peculiarities of their configuration. Some sensors require external supply voltage stabilization. If you have any doubts on IMPORTANT making connections or configuration, consult the representative of the sensor manufacturer or your regional TechnoKom dealer. TechnoKom © 2015...
Page 36 RS-485 bus. Up to 250 IDs can be stored in the flash memory of the Card reader. Each card can configure the output of the card reader when connected. For more information on connection and configuration of controller for operation with information NOTE display through the RS-485 bus see “AutoGRAPH-CR User Manual”. TechnoKom © 2015...
Page 37: Can Bus (Sae J1939 / Fms)
SAE J1939 CAN-H (high) SAE J1939 CAN-L (low) CAN-SHIELD (for SAE J1939-11) or No Connection (for ISO 11783-2) SAE J1708 (+) SAE J1708 (–) Proprietary OEM Use or Implement Bus CAN-H Proprietary OEM Use or Implement Bus CAN-L TechnoKom © 2015...
Page 38: Indication Of Operation
GPS / GLONASS LED lights up in red, the single-colour GPS / GLONASS LED flashes green several times, after that the bi-colour LED goes out. Number of the flashing of the single-colour LED determines an error code. TechnoKom © 2015...
Page 39 • Data reading – the single-colour GPS / GLONASS LED lights constantly. • Writing the settings – the single-colour GPS / GLONASS LED flashes. When the bi-colour GPS/GLONASS LED flashes green and red simultaneously, the customer will see NOTE a mix of the both colours. TechnoKom © 2015...
Page 40: Installing The Drivers
Windows Update website and install suitable driver for the tracker. If the Internet connection is not available, continue with the procedure outlined below. 3. Download the archived drivers folder from the official website of TechnoKom - AGUSBDriver.zip and extract files to a temporary directory on a hard drive.
Page 42: Connection Of Controller To Pc
Reading of data from the controller using the AutoGRAPH Dispatch Software is described in detail in the “AutoGRAPH Dispatch Software User Manual”. NOTE Furthermore, the AutoGRAPH Dispatch Software has functionality to delete all data from the controller storage memory. TechnoKom © 2015...
Page 43: Transportation And Storage Of Controller
GOST 15150 for group 1 (“Л” (‘L’)): Heated and ventilated warehouses, air-conditioned storage facilities located in any macroclimatic areas with relative air humidity suitable for equipment versions designed for moderately cold climate (УХЛ4 (UKhL4)). TechnoKom © 2015...
Page 44: Appendix 1. Warranty Provisions (Summary)
Customer shall have a right to repair the product in TechnoKom service centre, if any workmanship or structural defects are found in the device within the warranty period.
Page 45 • Improper functioning due to the faulty SIM cards installed in the controller or due to SIM card locking. TechnoKom disclaims any liability for claims concerned with damage or loss of data which exceed the product cost, as well as for claims concerned with accidental, intentional or consequential IMPORTANT damage* caused by use or inability to use the product to the extent permissible by law.
Page 46: Appendix 2. Certificates Of Conformity
АвтоГРАФ-GSM/SL • USER MANUAL Appendix 2. Certificates of Conformity TechnoKom © 2015...
