SerVision IVG400-N Quick Start Manual

Hide thumbs Also See for IVG400-N:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Quick Start Manual
IVG400-N
Quick-Start Guide
July
2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IVG400-N and is the answer not in the manual?

Questions and answers

Related Manuals for SerVision IVG400-N

Summary of Contents for SerVision IVG400-N

  • Page 1 IVG400-N Quick-Start Guide July 2017...
  • Page 2 © 2017 SerVision Ltd. All rights reserved. Notice Information in this document is subject to change without notice. SerVision Ltd. assumes no responsibility for any errors that may appear in this manual. Companies, names and data used in examples herein are fictitious unless otherwise noted.

  • Page 3: Table Of Contents

    Opening WebMax Connecting to WebMax through an HDMI Monitor Connecting to WebMax from a PC Overview of SVCentral Connecting a PC to the IVG400-N Unit Opening WebMax from SVCentral Configuring the IVG400-N Logging into WebMax Overview of the WebMax Interface...

  • Page 4: Introduction

    IVG400-N are included in this guide. Client software is used for accessing the IVG400-N unit remotely in order to view video and events and control the system in various ways. SerVision’s next-generation client application for PCs, SVCentral, offers a full range or features for viewing and working with digital video streams created by the IVG400-N.

  • Page 5: Peripheral Equipment

    Cameras and other peripherals (sensors, activators, an HDMI monitor, etc.) are not included in the IVG400-N package. Only cameras that support the ONVIF protocol can be used with the IVG400-N. In addition, PoE (Power over Ethernet) is supported for up to four cameras. If more cameras are required, please contact technical support for information about connecting them to the system.

  • Page 6: Diagrams Of Connectors

    Diagrams of Connectors IVG400-N has connectors on both the front and back panels, as described below. Front Panel The connectors and indicators of the front panel of the IVG400-N unit that are currently supported are described below. Audio In2 (Ain2)

  • Page 7: Installing The Ivg400-N Unit

    Installing the IVG400-N Unit The IVG400-N unit can be installed vertically or horizontally. If it is installed vertically, or it is installed on a moving platform such as a vehicle, it must be mounted using the supplied supports. If it is installed in a stationary location, it can be placed horizontally on a stable flat surface such as a table or shelf, and does not necessarily have to be secured.

  • Page 8: Installation In A Vehicle

    It should not be installed in a closed location, such as in the trunk or dashboard, or under the paneling of a car. In buses and trains, the IVG400-N can be installed in an air- conditioning duct or in the compartment above the driver's seat.

  • Page 9: Connecting The Cameras

    The unit can connect to more than one type of external network at a time. This section explains how to set up the hardware so that the IVG400-N unit can connect to these networks. In order for the unit to connect to a cellular network or a WiFi access point, it must also be configured as explained below (pp.19-20).
  • Page 10 To enable the IVG400-N unit to connect to an external LAN: • Connect one of the Ethernet connectors on the rear panel of the IVG400-N unit to a LAN connection point (a hub, wall socket, or any other connection point) using the supplied Ethernet (network) cable. It does not matter which Ethernet connector you use.

  • Page 11: Installing The Gps Antenna

    IVG400-N Quick-Start Guide Installing the GPS Antenna If you want to track the location of the vehicle in which the IVG400-N is installed, the supplied GPS antenna must be installed in the vehicle, as follows: To install the GPS antenna: 1.

  • Page 12: Connecting To Webmax From A Pc

    The easiest way to open WebMax from a PC is to connect to the unit through the SVCentral client application and open it from there. Since you will most likely be using SVCentral to connect to the IVG400-N itself after it is installed and configured, in order to view video and other data, it is worthwhile installing it in any case.

  • Page 13: Connecting A Pc To The Ivg400-N Unit

    Connecting a PC to the IVG400-N Unit In order to open the WebMax from a PC, the PC must be connected directly to the IVG400-N unit by means of a network cable. In addition, you must temporarily change the network settings of your PC to match those used by the IVG400-N unit.
  • Page 14 Figure 15: Network Connections window 3. Right-click the network connection you are using to connect to the IVG400-N, and then select Properties. The Connection Properties window opens. Opening WebMax...
  • Page 15 SerVision IVG400-N Quick-Start Guide Figure 16: Connection Properties window 4. In the list of items, double-click Internet Protocol Version 4 (TCP/IPv4). The Internet Protocol Version 4 (TCP/IPv4) Properties window opens. Figure 17: Internet Protocol Version 4 (TCP/IPv4)Properties window 5. Select Use the following IP address, and then, under IP address, enter xxx.

  • Page 16: Opening Webmax From Svcentral

    Figure 18: Gateway Info dialog box with the IP address and port of the IVG400-N entered 3. Click OK. The IVG400-N is added to the list, and SVCentral attempts to connect to it. When it succeeds, the IP and port are replaced with the name of the unit, as it appears in its configuration, and an Expand button ( ) appears to the left of the name.

  • Page 17: Configuring The Ivg400-N

    IVG400-N Quick-Start Guide Configuring the IVG400-N Once the IVG400-N unit and its peripheral equipment are installed and set up as described above, you must configure the unit to work as required. This chapter describes how to work with the unit’s WebMax configuration utility.

  • Page 18: Overview Of The Webmax Interface

    SerVision IVG400-N Quick-Start Guide Figure 22: System Summary WebMax page Overview of the WebMax Interface WebMax consists of screens that are displayed on the right side of the window and a main menu in a sidebar on the left side of the window. A status bar at the top of the screen displays, among other things, the name of the IVG400-N.
  • Page 19 SerVision IVG400-N Quick-Start Guide 2. Modify the settings in the screen as necessary, and then click Update to store them on the unit. Update Figure 24: Update button The changes are saved in a temporary cache on the unit. 3. To modify additional settings, in the main menu, select the relevant screen and make the changes as necessary.

  • Page 20: Setting The Time

    NOTE: In order for it to connect to WiFi, the supplied WiFi antennas must be connected to the IVG400-N (see Connecting the Unit to External Networks, page 8). To enable the IVG400-N to connect to a WiFi access point: •...

  • Page 21: Setting Up Cellular Connectivity

    IVG400-N Quick-Start Guide Setting Up Cellular Connectivity The IVG400-N can be configured to connect to a GSM cellular network if an appropriate SIM card is installed in it (see Connecting the Unit to External Networks, page 8). To enable the IVG400-N to connect to a cellular network: •...

  • Page 22: Viewing Video From The Ivg400-N In Svcentral

    Viewing Video from the IVG400-N in SVCentral Once you have set up and configured the IVG400-N unit as described in this guide, you can view video from it in SVCentral. The PC on which SVCentral is running does not have to be connected directly to the IVG400-N unit any more.
  • Page 23 POB 45205 Jerusalem 91450 Israel Tel: +972-2-535 0000 • Fax: +972-2-586 8683 www.servision.net • info@servision.net IVG400-N Quick-Start Guide...
