Please read the user's manual carefully before the installation and the first operation
of the amplifier.

SPECIFICATIONS

Output Power RMS
Output Power Max.
Loudspeaker impedance (stereo)
Frequency Response
Total Harmonic Distortion
Signal-to-Noise Ratio
Input Sensitivity
Input Impedance
High Pass Filter / Low Pass Filter
Operating Voltage
Fuse Rating
Dimensions (B x H x L)
All Specifications are subject to change

WARRANTY

This product meets the current EU minimum warranty requirements, if purchased in countries of the EU. To en-
sure your warranty policy keep your original receipt proofing the date of purchase. Any damage to the product
as a result of misuse, abuse, accident, incorrect wiring, improper installation, alteration of date code or barcode
labels, revolution, natural disaster, or any sneaky stuff because someone messed up, repair or alteration out
side of our factory or authorized service centers and any thing else you have done that you should not have
done is not covered. This warranty is limited to defective parts and specifically excludes any incidental or con-
sequential damages connected therewith.
8
QM-TWO
2 x 80 W @ 4 Ohms
2 x 120 W @ 2 Ohms
1 x 240 W @ 4 Ohms bridged
2 x 160 W @ 4 Ohms
2 x 240 W @ 2 Ohms
1 x 480 W @ 4 Ohms bridged
2 – 8 Ohm
5 – 40 000 Hz (-3 dB)
< 0,5 % (1 kHz)
> 90 dB
0,3 – 12 V
100 kOhm
50 – 250 Hz @ 12 dB/Octave
+12 V (9 – 15 V), negative ground
1 x 20 A (external, included in delivery)
75 x 33 x 120 mm
