Description of the device
4.2
Overview
1
2
W C
Quit
Men u
8
1
Controller
2
Venting grille
3
"ST" dirt trap
4
"DV" degassing valve
5
"CD" 3-ways motor ball valve for the hydraulic regulation
of system and make-up degassing
10 — English
3
Error
Auto
Ok
Auto
Man ual
Stop
D C
Vacuum spray degassing — 03.11.2014
D C
7
6
"PIS" pressure transducer
7
"PU" vacuum degassing pump
8
Removable front shell
WC
Connection for the make-up with fresh water
DC
Degassing connection
•
Gas-rich water inlet.
•
Degassed water outlet.
4
5
6
