- Page 1 SC100 Item ref: 178.192UK Suitcase PA User Manual Version 1.0...
- Page 2 Damage caused by misuse is not covered by the warranty Introduction Thank you for choosing the QTX SC100 Suitcase PA for your portable sound requirements. This system has been designed to offer a complete stereo PA solution for small to medium applications in a convenient, easy-to-carry format.
- Page 3 Panel Layouts Audio player & controls SD/MMC card slot USB port Channel 4/5 volume controls Channel 1 volume fader Channel 1 tone controls Channel 2 volume fader Channel 2 tone controls Channel 3 volume fader Channel 3 tone controls Channel 4/5 L/R stereo reverse mp3 playback to main output Channel 4/5 tone controls 5-band graphic equalizer...
- Page 4 Open the SC100 “suitcase” by unfastening the clips at either side of the handle and lifting the centre console lid. With the lid opened fully, it is possible to lift out each of the 2 speakers, which should be fitted to the top of the tripod stands.
-
Page 5: Master Output
DSP Effects For sound effects, such as Reverb or Echo for vocalists, the SC100 features a 16-program DSP effects section (DSP stands for Digital Signal Processor). Settings for this section are displayed in a window near to its controls (16) with a list of all 16 effect types alongside it. - Page 6 Audio player The SC100 has an audio player section (1) which can play mp3 files stored on a USB stick or SD card. To enable playback, press in the MP3 TO MAIN button (12). Control buttons are as shown below.
-
Page 7: Specifications
Specifications Power supply 100-240Vac, 50/60Hz (IEC) Fuse T1.6AL / 250V Power consumption max. 200W Output power 2 x 50Wrms @ 4 Ohms Mic/line inputs 2 x balanced XLR/jack, 1 x unbalanced jack Stereo input L+R RCA LF drivers 2 x 112mmØ (4“) per speaker HF drivers 25mmØ... - Page 8 Disposal: The “Crossed Wheelie Bin” symbol on the product means that the product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Errors and omissions excepted.
