Instruction INFOCAL 8

10.0 Display

To show the data generated by the calculator in the display, various
windows are provided as loop functions that can be called up in
succession to display the system information associated with each
window (e.g. energy amounts, water volume, running days, water
amounts, current temperatures). The energy calculator has 6 differ-
ent display loops.
Informative Displays (Standard)
Loop Sequence
1.1
1.2
1.3
1.4
"1"
1.5
Main loop
1.6
1.7
1.8
1.9
1.10
Loop Sequence
2.1
2.2
2.3
"2"
2.4
Accounting
2.5
date loop
2.6
...
2.14
Loop Sequence
3.1
3.2
3.3
3.4
3.5
"3"
3.6
Info loop
3.7
3.8
3.9
3.10
Loop Sequence
"4" 4.1
Pulse input
4.2
loop
Loop Sequence
"5"
Only in a heat meter with cooling tariff.
Tariff loop
Loop Sequence
6.1
6.2
"6"
Monthly value 6.3
loop
...
6.24
Danfoss District Energy
Window 1
Accumulated energy
Volume
Accumulated energy (cooling)
Flow
Power
Forward / - return temperature
Temperature difference
Operating days
Error status
Display test
Window 1
Accounting date 1
‚Accd 1'
Accounting date 1 previous year
Accounting date 2
‚Accd 2'
Accounting date 2 previous year
Accounting date 2 previous year
Window 1
Current date
,SEC_Adr'
,Pri_Adr 1'
,Pri_Adr 2'
Installation position
Pulse input 0
,Port 1'
,Port 2'
Status integrated radio
software version
Window 1
,In1'
,In2'
Window 1 Window 2
Window 1 Window 2
,LOG' date last month
,LOG' date month - 1
,LOG' date month - 2
,LOG' date month - 23
The various display windows comprise up to several displays that
change at intervals of 2 – 4 s. The loops in the display are numbered 1,
2, ... and 6 to help the user find his way around quickly. The main loop
is programmed with the current data as default setting, e.g. for energy,
volume and flow rate.
Window 2
(Sequence will be shown only
in a heat meter with cooling tariff)
Error hours
Window 2
Accounting date 1 energy
Future accounting date 1
Accounting date 1
previous year energy
Accounting date 2 energy
Future accounting date 2
Accounting date 2
previous year energy
Pulse input 2
Window 2
Current time
Secondary address
Primary address 1
Primary address 2
Volume
No. of the mounted module at port 1
No. of the mounted module at port 2
(Sequence will be shown only in
meters with integrated radio)
Checksum
Window 2
Accumulated value pulse input 1
Accumulated value pulse input 2
Window 3 Window 4
Window 3 Window 4
energy volume
energy volume
energy volume
...
energy volume
VI.SH.L1.02
Window 3
Window 3
‚Accd 1A'
‚Accd 1L'
‚Accd 2A'
‚Accd 2L'
Pulse input volume 2
Window 3
Window 3
,PPI' pulse value 1
,PPI' pulse value 2
Window 5 Window 6
Window 5 Window 6
max. flow rate max. power
max. flow rate max. power
max. flow rate max. power
max. flow rate max. power
DEN-SMT/PL
