Programming the operator

(Note: The operator will exit programming if left for 30 seconds.)
Preparation
With the Carriage Release Lever horizontal,
move the door by hand until the Carriage engages
with the Shuttle.
Turn on the power, the Lamp comes on while the
Display runs from '99' to '11'.
The Display changes to '--'. Standby Mode.
Setting Open and Close Positions
Press and hold the SET button, until 'P1' is
displayed.
Press SET again, 'OP' is displayed.
Press and hold the UP button. While opening,
'OP' flashes.
Release the UP button when the open position is
reached.
Use the UP or DOWN buttons to adjust the open
position.
Press SET, and 'CL' is displayed.
Press and hold the DOWN button. While closing,
'CL' flashes.
Use the UP or DOWN buttons to adjust the
closed position.
Press SET, and the door will open and close
automatically to establish normal force
requirements. Finally '--' is displayed.
Adding eKey Remotes
Press the CODE button. 'Su' is displayed.
Choose and press a button on the eKey Remote.
Press the same button again to confirm.
'SU' flashes and then '--' is displayed.
Repeat the above steps for additional eKey
Remotes. A maximum of 20 may be stored. An
attempt to add another will display 'Fu'.
Deleting Remotes
Caution: This function deletes all remotes
8. Owner's Guide
Notes and Warnings:
Only operate the door when it is in full view.
Do not allow young children to play with the controls.
In the event of a malfunction, to judge where the fault may lie, use the manual over-ride and test the door by hand, and check if the
operator will function with the door disengaged.
Problem
Noisy Chain
No response from the motor
Door opens but will not close
The motor works from the push button,
but not the remote
Remote range is short
Door fails to close fully and re-opens,
or door fails to open fully
Press and hold the CODE button for 8 seconds.
'dL' is displayed
Press and hold the SET button, until 'P1' is
displayed.
99 99 99 99
11 11 11 11 Press the UP button once. 'P2' is displayed.
Press SET again. The current force setting is
-- -- -- --
displayed. Press UP or DOWN to increase or
decrease this value by one step at a time.
P1 P1
P1 P1
Maximum is 'F9'; Minimum is 'F1'. Press SET
to confirm.
OP OP OP OP
Default setting is 'F5'
OP OP
OP OP
Press and hold the SET button, until 'P1' is
displayed.
Press the UP button twice. 'P3' is displayed.
Press the SET button to show the beam Status.
'H0' means Disabled, 'H1' means Enabled.
CL CL
CL CL
Press the UP button to Enable. 'H1' is displayed.
CL CL CL CL
Press the DOWN button to Disable. 'H0' is
displayed.
NOTE: If Safety Beams are not fitted, ensure the
OP OP
OP OP
CL CL above function is Disabled, or the operator will
CL CL
open, but will not close.
-- --
-- --
Press and hold the SET button, until 'P1' is
Su Su Su Su
displayed.
Su Su
Su Su
Press the UP button three times. 'P4' is displayed.
Press the SET button to show the Auto-close
(Su Su Su Su)
Status.
-- -- -- --
'b0' means 'No Auto-close', 'b9' is maximum
Auto-close.
Fu Fu Fu Fu
Press the UP button to increase, or the DOWN button to
decrease the delay by 1 minute.
Press the SET button to confirm and exit.
Keep people, pets and property clear of the moving door.
The door operator is intended for indoor installation.
The door and operator should be serviced annually.
Trouble Shooting
Possible Cause
Chain has become loose
Mains supply/loose plug, blown
fuse
Safety Beam (if fitted) is faulty
Remote faulty or battery low
Remote battery low
Operating Force too low
Operating Force Adjustment
Safety Beam – Enabling and Disabling
Press the SET button to confirm and exit.
Auto-close
Remedy
Adjust the M8 Nut on the spring
Check the mains.
Check/replace the fuse with the same type
Test by disabling the beam (see programming)
Replace remote battery. If two or more remotes fail,
replace the control board.
Replace remote battery
Test the door by hand. Slightly increase the
Operating Force (see Programming)
