FMUser SDA-01A User Manual

www.fmuser.net
1. Attention before use
1).Only professional technicians are allowed to do maintainence of the transmitter
2).Please set anti-thunder protections during bad weather(thunder, storm.etc)
3). Please don't turn on the transmitter without connecting the antenna well.
4).Please don't use the transmitter in the explosive environment(gas station, steam, etc)
5).Pleae don't use the transmitter in very damp/dusty/high temperature environment.
6). Please use the transmitter following the local wireless adminitration regulations.
2. Menu
1) Features
2) Configurations
3) The picture of front and back panel
4) Knob and buttons description
5) Operation Steps
6) Technical Specification
7) Troubleshooting
8) PC control software description
3.Product Features
SDA-01A is a new advanced FM transmitter with excellent and stable performance, easy operation,
high definity sound quality and other outstanding features. It has exquisite design and professional
look.
Main Features:
1). Wide frequency range: 76~108MHZ
2). Optional Channels: STEREO/MONO
3). Count down Power ON/OFF function
4). Power output is adjustable from 0~1w.
5). One button to control all the functions. Easy to operate.
6). Adopting several protection methods, it has strong empty load protection ability.
7).PC control of the transmitter easily through the software SDA-01A PC CONTROL.
8). Working status lighting: When the transmitter is OFF, the backlight of the knob is red. When the
transmitter is working, the backlight of the knob is blue.
4. Product Configuration
No. Name
1 The transmitrer
2
Helical antenna
3
Power adapter
skype:rita.cai87
SDA-01A USER MANUAL
Description
SDA-01A
L/TNC connector
DC12V/1A
MSN: rita_cai_jxpx@hotmail.com
Quantity Unit
1 pcs
1 pcs
1 set
Port
NO
ANT
12.0V-1.0A
