Microcare Pure Sine Wave Bi-Directional Inverter 10Kw Manual

Pure sine wave bi-directional inverter
Hide thumbs

Advertisement

Quick Links

10Kw / 15Kw
PURE SINE WAVE
BI-DIRECTIONAL
INVERTER MANUAL
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Pure Sine Wave Bi-Directional Inverter 10Kw and is the answer not in the manual?

Questions and answers

Related Manuals for Microcare Pure Sine Wave Bi-Directional Inverter 10Kw

Summary of Contents for Microcare Pure Sine Wave Bi-Directional Inverter 10Kw

  • Page 1 10Kw / 15Kw PURE SINE WAVE BI-DIRECTIONAL INVERTER MANUAL...

  • Page 2: Table Of Contents

    Contents 1. INTRODUCTION ........... 2 2. SAFETY INSTRUCTION ....... 3 3. SYSTEM DESCRIPTION ......6 4. INVERTER OPERATION ......10 4. INVERTER PROGRAMMING...... 15 6. SPECIFICATIONS OF INVERTERS ... 27...

  • Page 3: Introduction

    1. INTRODUCTION GENERAL DESCRIPTION The Microcare Pure Sine Wave Inverters deliver true clean sine wave output power. The Power is applicable for any kind of load, such as air-conditioners, home appliances, consumer electronics and office equipment. This series features a durable and continuous 24 hour operation.

  • Page 4: Safety Instruction

    2. SAFETY INSTRUCTION POSITIONING 2.1.1 Do not put the Inverter on a rugged or inclined surface. 2.1.2 Do not install the Inverter near water or in damp environments. 2.1.3 Do not install the Inverter where it would be exposed to direct sunlight. 2.1.4 Keep the Inverter far away from heat emitting sources.
  • Page 5 – Connect to Chassis Earth. The Microcare inverter is designed primarily for Grid / Mains connection to include charging. When Mains is connected to the inverter the Neutral connection is Earthed via the Mains. If the Inverter is connected as a stand-alone inverter with no Mains Connection, The Neutral is required to be earthed using an earth spike.
  • Page 6 2.3.5 Inverter Neutral Connection The inverter has a floating neutral so the neutral voltage will be close to 110v. In this case the live voltage with respect to the earth will also be around 110v. If you use your inverter for a standalone application you need to bridge the neutral input with the earth terminal on the inverter (these two are next to each other for this purpose).

  • Page 7: System Description

    MAINTENANCE AND SERVICE 1. Caution – Risk of Electric Shock. 2. Batteries may cause electric shock and have a high short-circuit current. Please take the precautionary measures specified below and any other measures necessary when working with batteries. • Remove wristwatches, rings and other metal objects. •...
  • Page 8 3.1.2 System Right View. (10Kw Inverter.) 3.1.3 System Left View. (10Kw Inverter.)
  • Page 9 3.1.4 System Front View. (15Kw Inverter.) 3.1.5 System Right View. (15Kw Inverter.)
  • Page 10 FRONT PANEL DESCRIPTION 3.2.1 LCD Display: This indicates the UPS’s operational information, including output voltage, battery voltage, output load and inside temperature. 3.2.2 UP–Key: Use to move the display up. 3.2.3 DOWN–Key: Use to move the display down. 3.2.4 ENTER–Key: It is pressed with the UP–Key to turn on the UPS. Push the ENTER button to confirm or store DATA.

  • Page 11: Inverter Operation

    Display shows writing then turn on the BATTERY CIRCUIT BREAKER while holding the RED PRECHARGE BUTTON Once the BATTERY CIRCUIT BREAKER has been turned on then the PRECHARGE BUTTON can be released. MICROCARE MICROCARE …PLEASE WAIT… Inverter Error...
  • Page 12 The display then changes to: MICROCARE UPS TURNED OFF Inverter Error ENTER Menu Up Menu Down Then Push the ENTER Button and the display will change to: MICROCARE MICROCARE 15KW INVERTER Inverter Error ENTER Menu Up Menu Down By pressing the Enter-key and the UP-key simultaneously for 3 seconds, the UPS will start up and the OK LED will light up to indicate the power is being supplied from the inverter to the load and the MAINS / FAIL LED comes ON.
  • Page 13 By turning on a load the OUTPUT % will change to indicate the amount of LOAD as a % of the unit being used in KW. Above 5% of load is displayed. MICROCARE MICROCARE 15KW INVERTER Inverter Error ENTER Menu Up...
  • Page 14 Using the UP arrows the following details can be checked: This shows the battery voltage and the amps that the UPS is drawing from the battery. MICROCARE BATT VOLT 54.2 BATT AMPS Inverter Error ENTER Menu Up Menu Down If the battery Amps changes to CHR AMPS...
  • Page 15 Shows the Grid Volts and power draw from the grid power supply: MICROCARE GRID VOLTS GRID AMPS 10.0 Inverter Error ENTER Menu Up Menu Down This shows the internal temperature of the UPS. MICROCARE TEMPERATURE 26.3 deg/cel Inverter Error ENTER...

  • Page 16: Inverter Programming

    This indicates the serial number of the Inverter. MICROCARE SERIAL NUMBER: MCxx7777 Inverter Error ENTER Menu Up Menu Down The Serial number of the inverter needs to be noted and supplied when requesting any fault support information. 4. INVERTER PROGRAMMING There are two MENUS’...
  • Page 17 By pushing ENTER button you can change whether the inverter runs in NORMAL SENSE mode; or SOLAR CONTROL mode. MICROCARE MODE NORMAL SENSE Inverter Error ENTER Menu Up Menu Down NORMAL SENSE is to be selected when connecting a Generator to the Inverter or for any off-grid inverter installation.
  • Page 18 Push the UP button in SOLAR CONTROL mode you can then access the battery run to menu: (This allows the user to set the level the battery will go down to before switching to mains power.) MICROCARE SOLAR CONTROL BAT RUN TO 46.0v...
  • Page 19 To change the menu, push the UP button. The menu will then change to: MICROCARE TRANSFER SWITCH SOFTSTART Inverter Error ENTER Menu Up Menu Down The Settings available for this are as follows: 3mS NO 3 milli second transfer time and will restart load instantly - SOFTSTART with mains fail prediction.
  • Page 20 To change the menu, push the UP button. The menu will then change to: MICROCARE LOAD MONITORING HIGH NO RESET Inverter Error ENTER Menu Up Menu Down The sensitivity of the SHORT CIRCUIT TRIP may be changed through 5 LEVELS. Push...
  • Page 21 To change the menu, push the UP button. The menu will then change to: MICROCARE IF AC INPUT AC OUTPUT Inverter Error ENTER Menu Up Menu Down The settings available are as follows: AC OUTPUT = NOR This will allow the inverter to supply rated power.
  • Page 22 Pushing the UP button will give you 3 options to SAVE the changed data. The display will show: MICROCARE EXIT AND SAVE SETUP MENU ? Inverter Error ENTER Menu Up Menu Down MICROCARE RESTORE FACTORY SETUP MENU ? Inverter Error...
  • Page 23 If the changes to the settings need to be saved push ENTER if the enter button is pushed then the inverter may show: MICROCARE SAVING DATA PLEASE WAIT Inverter Error ENTER Menu Up Menu Down If no entry is made for 1 minute the display will return to the main menu and the back light will turn off.
  • Page 24 To change the BATTERY CHARGE menu push ENTER button: MICROCARE BATTERY CHARGE LEVEL (X) SELECTED Inverter Error ENTER Menu Up Menu Down The Settings available for this function are as follows: 50% OF RATED CHR (Default). 50% of charge rate as per list supplied below.
  • Page 25 To change the menu, push the UP button. The menu will then change to: MICROCARE INPUT POWER LEVEL (X) SELECTED Inverter Error ENTER Menu Up Menu Down This allows the UPS to extract the maximum amount of power from a generator. The UPS constantly monitors the voltage from the generator and then applies maximum charge.
  • Page 26 To change the menu, push the UP button. The menu will then change to: MICROCARE BATTERY BOOST 58.4 volts Inverter Error ENTER Menu Up Menu Down By pushing ENTER this allows the user to adjust the BATTERY BOOST voltage. To change the menu, push the UP button.
  • Page 27 To change the menu, push the UP button. The menu will then change to: MICROCARE BATTERY OFF AT 44.0 VOLTS Inverter Error ENTER Menu Up Menu Down This selects at what BATTERY LOW VOLTAGE the UPS will shut down. By pushing ENTER you can select to change the voltage.

  • Page 28: Specifications Of Inverters

    SPECIFICATIONS OF INVERTERS MODEL 36/10000 Capacity Watt 10000 Nominal Voltage 36 Vdc Acceptable Voltage Range 30 - 45 Vdc Input Maxi Input Amps 333 amps Manual Mode Power 100 watts Voltage 220 Vac Amps 45 amps Voltage Regulation < 3 % RMS for entire battery voltage range Frequency 50Hz Frequency Regulation...
  • Page 29 MODEL 48/10000 MODEL 48/15000 Capacity Watt 10000 15000 Nominal Voltage 48 Vdc 48 Vdc Acceptable Voltage Range 40-60 Vdc 40-60 Vdc Input Maxi Input Amps Manual Mode Power 100 watts 150 watts Voltage 220 Vac 220 Vac Amps 45 amps 68 amps Voltage Regulation <...
  • Page 30 Where the installation of the product makes it impractical to bring-in to our workshops, Microcare reserves the right to charge for travel time and kilometres travelled to and from the site where the product is installed.
  • Page 31 Life Support Policy: As a general policy, Microcare does not recommend the use of any of its products in life support applications where failure or malfunction of the Microcare product can be reasonably expected to cause failure of the life support device or to significantly affect its safety or effectiveness.

This manual is also suitable for:

Pure sine wave bi-directional inverter 15kw
