- Page 1 NX/NXP /NXP NVR Series Quick Start Guide Quick Start Guide Version 1.0.1...
-
Page 2: Table Of Contents
Table of Contents Unit .............................. 3 Check Unit ......................... 3 Product Label ........................3 Front Panel ........................3 Rear Panel ......................... 4 Unit Operation ..........................6 Unit Login .......................... 6 Camera Setup ........................7 Schedule Setup ........................7 Playback ..........................8 Remote Web Access ........................ -
Page 3: Package Contents
Phone: 1-800-645-5516 option 3 Email: techsupport@specotech.com Important Safeguards and Warnings Speco Technologies assumes no liability or responsibility for any fires or electrical shock caused by improper handling or installation. Speco Technologies is not liable for any problems caused by unauthorized modifications or attempted repair, which will void the warranty. -
Page 4: Unit
Check that the model number and serial number that’s listed on the label on the unit are the same as w listed on the package label. 1.3 Front Panel The front panels are shown in Figure Figures 1-1 (N32NX), 1-2 (N16NXP), and 1-3 (N8NXP). Figure1-1 Figure1-2 Figure 1-3... -
Page 5: Rear Panel
1.4 Rear Panel The N8NXP and N16NXP rear panels are shown in Figure 2-2 and Figure 2-2 for reference. The N32NX rear panel is shown in Figure 2-3 Figure 2-2 Figure 2-2 Figure 2-3 Please refer to the following sheet for detailed information. - Page 6 RS232 RS232 port Communication port (N16NXP/N32NX only) RS485 Control port for PTZ keyboards, etc (N16NXP/N32NX only) 1 – 4 (N8NXP) Sensor Input Sensor input ports 1 – 16 (N16NXP/N32NX) Relay output Normally open terminal Common terminal CTRL 12V Relay output / Used as the last relay output.
-
Page 7: Unit Operation
5 incorrect login attempts within 30 minutes will result in a lock on the account. Once the unit is locked, please wait for 30 minutes before attempting to log in again. To reset the password, please contact Speco Technologies Technical Support. Figure 3-2... -
Page 8: Camera Setup
2.2 Camera Setup The NVR supports plug and play for IP cameras through the built-in PoE ports. In addition, the NVR can scan for IP cameras that are on the same local network through the EZ Camera feature. To add cameras, right click and then click on Main menu->Setup->Camera->Site Locate. See Figure 3-3. Figure 3-3 Click Device Search to find cameras on the local network. -
Page 9: Playback
Figure 3-4 2.4 Playback Right click and select Main Menu->Search to bring up the playback interface as shown in Figure 3-6. From this screen, you can access EZ Search as well as searching by timeframe. Figure 3-6... -
Page 10: Remote Web Access
3 Remote Web Access Open Internet Explorer and enter the NVR’s IP address in the address bar. Follow the instructions to install the plug-in. After installation, the login interface is shown as below. See Figure Please enter the user name and password. Figure 4-1 For detailed operation information, please refer to the user’s manual.
