Bedienungsanleitung
Operating Instructions
Miracord 90
Wir beglückwünschen Sie zum Kauf eines ELAC Plattenspielers, der unter strengen Qualitäts-
und Umweltauflagen hergestellt wurde. Um alle Leistungsmerkmale optimal auszunutzen, lesen
Sie bitte die Bedienungsanleitung gründlich durch. Wir raten Ihnen, diese Anleitung für späteres
Nachschlagen gut aufzubewahren.
Bitte beachten Sie die separaten Sicherheitshinweise, die der Verpackung Ihres neuen Plat-
tenspielers beigepackt sind. Bitte lesen, beachten und befolgen Sie alle diese Sicherheitshin-
weise und bewahren Sie diese ebenfalls auf. Beachten Sie alle Warnungen, die auf dem Gerät
und in der Bedienungsanleitung aufgeführt sind.
Congratulations on the purchase of your ELAC turntable that has been designed in accordance
with strict quality and environmental requirements. Please read the instruction manual carefully.
We recommend keeping it in a safe place for future reference. Please note the enclosed
safety instructions. Please follow the instructions and keep the safety instructions. Heed all warn-
ings on the appliance and in the manual.
Advertisement
Related Manuals for ELAC Miracord 90
Summary of Contents for ELAC Miracord 90
- Page 1 Sie diese ebenfalls auf. Beachten Sie alle Warnungen, die auf dem Gerät und in der Bedienungsanleitung aufgeführt sind. Congratulations on the purchase of your ELAC turntable that has been designed in accordance with strict quality and environmental requirements. Please read the instruction manual carefully.
-
Page 2: Table Of Contents
Inhaltsverzeichnis / Contents Seite page Lieferumfang Einführung / Allgemeines Vorbereitungen zur Inbetriebnahme Kurzbeschreibung der Bedien- und Anschlusselemente Deutsch Störungshilfen Service / Pflege / Fertigungskontrolle / Lautsprecherentsorgung / Recycling Gewährleistung / Werksgarantie Technische Daten Scope of delivery Introduction / General Preparation for operation English Connections and controls Troubleshooting / Warranty... -
Page 3: Scope Of Delivery
Scope of delivery Position Pcs. Description Turntable chassis Platter with felt mat Belt in carton box Tone arm counter weight Anti-skating weight Power supply adaptor Mains cable Instruction manual / Safety instructions Audio cable (RCA) -
Page 4: Introduction / General 11
8 mm ruby ball. The two axial bearings are made of sintered bronze. The Miracord 90’s frame is made of 5.5 kg solid MDF which is characterized by a high inner damping. This eliminates high frequency vibrations efficiently. What is more, thanks to the newly... -
Page 5: Preparation For Operation
Preparation for operation Before the turntable can be used some preliminary activities have to be put into effect. 1.1 How to install the platter (B): The platter has to be positioned in perfect alignment to the sub platter. Settle down the platter carefully without tilting it. -
Page 6: Connections And Controls 13
Connections and controls 2.1 Connecting the audio outputs: The two RCA jacks are directly connected to the pick-up system. So you need a (pre-) amplifier with phono input or an additional phono preamp. Next to the output jacks there is the earth connector which is con- nected to all metal parts of the turntable. -
Page 7: Troubleshooting / Warranty
The terms of warranty are regulated individually by the law in the different countries and by the terms of the international ELAC representatives respectively. If you have not bought your appliance in Germany, please check the terms with your retailer. Warranty can be given by any special retailer who has been authorized by ELAC or the respective international representative to distribute ELAC products (EU con- tract retailers). -
Page 8: Production Control / Disposal / Recycling 15
To be able to observe the tolerance limits, variations e.g. the values of the electric components must be severely restricted, since inaccuracies of single components may add up in the total system. To achieve maximum production quality, compliance with ELAC quality criteria and guidelines can be regarded as the most important duty. -
Page 9: Specifications
18 V / 18 W with Lumberg plug Colors Black Highgloss, White Highgloss, Walnut Oiled Technische Änderungen und Designänderungen vorbehalten / Technical data are subject to change. ELAC Electroacustic GmbH Fraunhoferstrasse 16, 24118 Kiel Tel. 0431/64 774-0, Fax 0431/682101 www.elac.de...
