Moultrie M-Series Instructions Manual

Digital game cameras
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Enlarged version
FCC Statements
Moultrie Products
MCG-13181
M-40
M-40i
Note: changes and modifications not expressly approved by the party responsible could void the user's authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE: This device complies with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device
does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- lncrease the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
www.moultriefeeders.com
PRADCO Outdoor Brands • 3280 Highway 31, Ste B • Calera, AL 35040
Moultrie Products
MCG-13182
09282016 / MCG-13181 • MCG-13182
Instructions for M-Series Digital Game Cameras
THANK YOU for your purchase of an M-Series Digital Game Camera. Please read this booklet before using the unit. If you should
have any questions about this product or any other Moultrie product, please contact us using the information on the back of
this booklet. Please register your camera at www.moultriefeeders.com/warranty to activate your warranty.
Motion Sensor
Light Sensor
LCD Display
Mode Selector Switch
Release for
Battery Compartment
External Power Port
Infrared LED Flash
Camera Lens
Menu Button
Status Indicator
SD Card Slot
Navigation Buttons
Micro USB Port

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Moultrie M-Series

Summary of Contents for Moultrie M-Series

  • Page 1 Moultrie Products MCG-13181 MCG-13182 THANK YOU for your purchase of an M-Series Digital Game Camera. Please read this booklet before using the unit. If you should M-40 M-40i have any questions about this product or any other Moultrie product, please contact us using the information on the back of this booklet.

  • Page 2: Troubleshooting

    M OTI ON F REEZ E MOULTRIE MOBILE® COMPATIBILITY OP T ION S Your camera is compatible with our Moultrie Mobile® cellular service when combined with the Field Modem MV1. Please visit www.moultriemobile.com for more information. M EM ORY ERAS E AL L IM AG ES...
  • Page 3 MENU MAP SYSTEM OPTIONS (cont.) Upgrade Firmware U P G R A D E F I R M W A R E The firmware version is displayed. 4 M 4 0 - 1 3 0 9 0 3 P IR YES - To upgrade firmware.

  • Page 4: Camera Overview

    Download still pictures and video onto your computer by connecting a micro-B to USB cable (not included) to the USB port. EXTERNAL POWER PORT Accepts the Moultrie power accessories (sold separately) only. Refer to www.moultriefeeders.com for more information. NOTE: The use of any other power source will void your warranty and possibly harm your camera.

  • Page 5: Quick Start Instructions

    SETTING PHOTO/VIDEO OPTIONS (cont.) QUICK START INSTRUCTIONS Use the steps below as a guide to quickly set up your camera so it will function using the factory default settings. Setting Video Length V I D E O L E N G T H STEP 1 Choose between 5 video length settings (5, 10, 30, 60 or 90 seconds).

  • Page 6: Capture Modes

    CAPTURE MODES SETTING PHOTO/VIDEO OPTIONS Setting Capture Mode Setting Photo Quality P H O T O Q U A L I T Y Use the Up/Down buttons to choose between operating modes. This camera has 3 modes. Choose between 4 image resolution settings: H I G H ( 4 M P ) 1.
  • Page 7 Event Delay Setting SETTING INFOSTRIP OPTIONS D E T E C T I O N D E L A Y Detection Delay determines the number of minutes between pictures when an S E C O N D S animal is detected and remains in range. Choose between (NONE, 10 sec, 30 sec, Infostrip Active 1 min, 5min, 10min, or 30 min).
  • Page 8 Setting Photo or Video Setting Program Stop P H O T O V I D E O T . L . P R O G R A M Choose between Photo, Video or Both. “Both” will take a photo, then a video. When start time is set, the camera will automatically move to the Stop option.
