Page 1: Index
QUICK INSTALLATION GUIDE OSD2145P SERIES 4-PORT PoE+ 10/100/1000BASE-T + 2-PORT 100/1000BASE SFP ETHERNET SWITCH... -
Page 3: Table Of Contents
OPTICAL SYSTEMS DESIGN INDEX 1 TECHNICAL SUMMARY ......................4 BRIEF DESCRIPTION ......................4 1.1.1 OVERVIEW ......................... 4 1.1.2 APPLICATIONS ........................4 1.1.3 FEATURES AND BENEFITS ..................... 4 TYPICAL CONFIGURATION ....................5 TECHNICAL SPECIFICATIONS ................... 6 INSTALLATION AND OPERATION ..................7 INTRODUCTION ........................ -
Page 4: Technical Summary
OPTICAL SYSTEMS DESIGN 1 TECHNICAL SUMMARY BRIEF DESCRIPTION 1.1.1 OVERVIEW The OSD2145P is designed to convert between 10/100/1000Base-T copper cabling and 100/1000Base fiber cabling. It has four fixed 10/100/1000Base-T PoE+ RJ45 copper ports, and two 100/1000Base SFP ports. The four PoE+ RJ45 ports can provide up to 30W output power per PoE+ port for powered devices. -
Page 5: Typical Configuration
OPTICAL SYSTEMS DESIGN TYPICAL CONFIGURATION Figure 1 below indicates possible set-ups for an OSD2145P system. FIGURE 1: OSD2145P TYPICAL CONFIGURATIONS DOC ID: 10112403 PAGE 5 OSD2145P QUICK INSTALLATION GUIDE... -
Page 6: Technical Specifications
OPTICAL SYSTEMS DESIGN TECHNICAL SPECIFICATIONS TABLE 1: TECHNICAL SPECIFICATIONS SPECIFICATION PERFORMANCE IEEE802.3i/802.3u/8023ab, 10/100/1000Base-T Ethernet Electrical Data Interface 10, 100, 1000Mbps with energy detect, auto negotiate, auto MDIX Data Rates IEEE802.3z 1000Base-Lx/Sx or IEEE802.3u 100Base-Fx Optical Data Interface Optical Data Rate... -
Page 7: Installation And Operation
OPTICAL SYSTEMS DESIGN 2 INSTALLATION AND OPERATION INTRODUCTION This section outlines the methods required to install and operate the OSD2145P successfully. It should be studied carefully if damage to the equipment or poor results are to be avoided. This equipment has been fully tested prior to dispatch and is ready for immediate operation. However it is advisable to check for external transportation damage before operation. -
Page 8: Osd2145P Drawings And Dimensions
OPTICAL SYSTEMS DESIGN 2.2.2 OSD2145P DRAWINGS AND DIMENSIONS The OSD2145P is designed to be DIN-rail mounted or wall mounted. Both DIN-rail and wall mounting brackets are included. Power connector is also included. FIGURE 2: INCLUDED ACCESSORIES (WALL MOUNTING, DIN-RAIL, POWER) -
Page 9: Power Supply Connections
OPTICAL SYSTEMS DESIGN 2.2.3 POWER SUPPLY CONNECTIONS The OSD2145P requires external 12 to 56V @ 1.5A. The OSD2145P features a second input voltage channel for redundant power operation. Power should be connected to the power socket located at the top of the case as indicated in Table 2. -
Page 10: Led Indicators
OPTICAL SYSTEMS DESIGN 2.2.4 LED INDICATORS FIGURE 5: LED FUNCTION TABLE 3: LED FUNCTION Function Blink Pwr1 When V1 connected No Power Pwr2 When V2 connected No Power When only Pwr1 or Pwr2 Both Pwr1 and Pwr2 FAULT connected connected... -
Page 11: Warranty
For warranty period, please contact your local OSD distributor. REPAIRS Optical Systems Design reserves the right to repair or replace faulty modules/units. Please obtain a “Return Material Authorisation” (RMA) form and number before returning goods. Goods must be returned in adequate packing material to Optical Systems Design, Warriewood or its nominated authorised representative, for all repairs. - Page 12 OPTIC L Optical Systems Design Pty. Ltd. 7/1 Vuko Pl. Warriewood 2102 SYSTEMS P.O. Box 891 Mona Vale N.S.W. Australia 2103 Telephone: +61 2 9913 8540 Facsimile: +61 2 9913 8735 DESIGN Email: sales@osd.com.au Web Site: www.osd.com.au PTY LTD A.B.N. 83 003 020 504...
