ERPS network diagrams

One major ring
The network has one major ring.
Figure 27 Network diagram
One major ring connecting one subring
The network has one major ring and one subring.
Figure 28 Network diagram
Device A
Owner node
Device C
Interconnection node
Device E
Owner node
One major ring connecting multiple subrings
The network has three or more rings. Each subring is connected to the major ring by two
interconnection nodes.
RPL
Device B
Neighbor node
Major ring
Device D
Interconnection node
Subring
Device F
Neighbor node
RPL
85
RPL ports
Major ring RPL
Subring RPL
